- Page 1 FFS-CSMP / FFT-CSMP FRENCH FITNESS SHASTA / TAHOE CHEST/SHOULDER MULTI PRESS (NEW) ASSEMBLY MANUAL...
-
Page 2: Tech Specs
F E AT U RE S 11 Gauge Steel • 50 x 100 mm thickness 3mm Steel tube • ASTM A36 steel frame ensures maximum structural integrity • Each frame receives an electrostatic powder coat finish to ensure maximum • adhesion and durability Standard rubber feet protect base of the frame and prevent the machine from •... - Page 3 T AB L E OF CONT E NT S CAUTIONS .................. 4 PARTS LIST ................5 ASSEMBLY INSTRUCTIONS ............6...
- Page 4 CAU T I ONS Security precautions To ensure your safety, please read the following notes before using this product read, study and understand the instructions and all warning labels before use. 1. It is recommended to be familiar with the normal operation and usage of the apparat us before using this product.
- Page 5 PART S L I ST...
- Page 6 ASSE MB L Y I NST RU CT I ONS STEP 1. Assemble the COUNTERWEIGHT FRAME : Connect A1, A3 and A4 with corresponding screws...
- Page 7 STEP 2. Install the counterweight: Insert into the hole corresponding to and sIide into 10, 11, 12, 13 B2, B3, B4 STEP 3. at the corresponding hole position of with corresponding screws...
- Page 8 STEP 4. Install the cabIe lnstall 11 on B1, and the other end passes through each pulley in turn, and then insert it into the hole oiB as shown in the figure and lock it with hexagon socket head screws.
- Page 9 STEP 5. I nstall the counterweight frame safe board: lnstall 10 to C1 with corresponding screws at each hole position as shown 1n the figure STEP 6. I nstall the counterweight frame safe board lnstalI with corresponding screws at each hole position as shown in the figure...
- Page 10 STEP 7. Install the sports sign: Uncover the double-sided adhesive tape on the counterweight frame and stick C2 at the position shown in the figure.
