Summary of Contents for FRENCH FITNESS SM200
- Page 1 FF-SM200 FRENCH FITNESS SM200 STAIR MILL CLIMBER ASSEMBLY MANUAL...
- Page 2 FE AT U RE S California Residents see Prop 65 WARNINGS • T E CH SPE CS Display Readouts: Calories (0- Number of Resistance Levels: 15 • • 999 (Kcal)) Power Cord Included: Standard • Total Number of Steps Climbed 110V, 3 Prong Outlet •...
-
Page 3: Table Of Contents
T ABL E OF CONT E NT S CAUTION ......................... 4 TECHNICAL STANDARDS ..................5 THE WHOLE MACHINE DIAGRAM ................6 THE INSTALLATION PROCESS ................... 7 STAIR CLIMBER OPERATING INSTRUCTIONS ............12 ROUTINE MAINTENANCE ..................14... -
Page 4: Caution
CAUT I ON Read all precautions and instructions in this manual before using this equipment. 1.The machine is suitable for commercial fitness clubs, clubhouse fitness, bodybuilding training, sports training, physical education and so on. The stair climber is suitable for indoor use, not for outdoor or high humidity, does not allow water or other liquids to be splashed on the machine, does not allow the placement or insertion of any foreign objects on the stair climber Use the Stair climber should ensure its 4 feet on the ground, and placed a... -
Page 5: Technical Standards
The stair climber is strictly prohibited to be used under the condition of less than ac180v and voltage instability, to ensure that the voltage is ac110± 10%, otherwise the need to install the regulator to maintain the voltage in the demand voltage;... -
Page 6: The Whole Machine Diagram
T HE WHOL E MACHI NE D I AGRAM Head (TZ-7037B is 13.3 inch LED meter) Screen support Armrests External shell Photoelectric switch Auxiliary pedal Cyclic steps... -
Page 7: The Installation Process
T HE I NST AL L AT I ON PROCE SS Assembly instructions: So that assembly is the principle All of this section is intended to ensure that the stair machine can be assembled correctly and easily. Because the size of the stair machine is large, please select the assembly ●... - Page 8 Step 1 Fixed auxiliary pedal Assembly instructions: (1) Remove the left and right auxiliary pedal packaging materials (2) Fix the auxiliary pedal in the position shown in the figure, pay attention to distinguish between left and right pedals.
- Page 9 Step 2 Connecting communication lines, assembling armrests Assembly instructions: (1) docking the screen support tube communication line with the stair plane main frame communication line (2) Fix the screen support tube to the corresponding position on the main frame. (3) Fix the left and right handrails in the corresponding positions...
- Page 10 Step 3 Assemble monitor and connect communication line Assemble details: Connect the screen support tube communication line to the display communication line After docking the communication line, place the meter on the joint with the support frame and fasten it. Connect ccommunic ation line...
- Page 11 Step 4 Fixed rear cover Assemble details: After the head is fixed, all the wires are fixed in place, and it is judged that there is no obstruction in operation. Then, the back cover of the stair machine is inserted into the inner side from the bottom up, so that the two sides of the casing are pressed against the back cover and fastened by screws.
-
Page 12: Stair Climber Operating Instructions
ST AI R CL I MBE R OPE RAT I NG I NST RU CT I ONS The stair machine panel adopts the capacitive touch principle, and the user can use only one touch at a time, and the touch effect is comparable to the mobile phone screen. - Page 13 9. 6."Left LED display area window" This area displays the current motion mode indicator； 10. 7“ . Right number key” is the level direct selection button, you can directly input the required level, click to confirm.； Second, Keyboard Function： 11. 1."PRO" is the program key: in standby mode, press this button to cycle through “BIM”...
-
Page 14: Routine Maintenance
ROUT I NE MAI NT E NANCE 1, clean every day It is recommended that you clean the equipment before and after each training session. To remove dust from the equipment, use a soft cloth to wet the following cleaning agents and then wipe all exposed surfaces; Note: Before using any cleaning agent to clean the fitness equipment, read and follow the manufacturer's instructions, especially the dilution instructions.
