FRENCH FITNESS FF-X9LP Assembly Manual

Functional multi gym system w/leg press
Hide thumbs Also See for FF-X9LP:

Advertisement

Quick Links

Download this manual
FF-X9LP
Functional Multi Gym System w/Leg Press
ASSEMBLY MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the FF-X9LP and is the answer not in the manual?

Questions and answers

Related Manuals for FRENCH FITNESS FF-X9LP

Summary of Contents for FRENCH FITNESS FF-X9LP

  • Page 1 FF-X9LP Functional Multi Gym System w/Leg Press ASSEMBLY MANUAL...

  • Page 2: Tech Specs

    FEATURES • • • • with ease • bearings • TECH SPECS • 190 lb Weight Stack • Lat Pulldown: Feels like 280 lbs Due to pulley ratio • Dimensions: 82"D x 91 "W x 83.9"H WARRANTY • Lifetime Parts and 1 Year Labor Warranty...
  • Page 3 Name Name Under Frame Incline support Pollex Frame Guide Road M 12x75 outer hex bolt Rubber Cushion Pedal Board Ф Washers M 10x85 outer hex bolt M10x20 outer hex bolt Pulley M8x50 outer hex bolt Pulley Spacer Flat washers Steel wire rope M8 Lock nuts M 10x45 outer hex bolt Lifting Rod...

  • Page 4: Parts Diagram

    Parts Diagram...
  • Page 5 Parts Diagram...
  • Page 6 I n s t a l l i n g S t e p 1 E x p l o d e d V i e w...

  • Page 7: Installation Instruction

    Installation Instruction 1. Put Φ10 washer (4) over M10*20 outer hexagonal bolts (5), and fasten the guiding rod assembly (2) to the underframe weldment (1). 2. Install the cushion (3) on the guiding rod assembly (2) Note: The outer hexagonal bolts need to be tightened...
  • Page 8 I n s t a l l i n g S t e p 2 E x p l o d e d V i e w...
  • Page 9 I n s t a l l i n g S t e p 2 A f t e r I n s t a l l a t i o n Installation Instruction 1. Place 11 PCS cast iron counterweight lowerpiece (12) and cast iron counterweight top piece (11) in sequence on the upper end of the guiding rod assembly (2).
  • Page 10 I n s t a l l i n g S t e p 3 E x p l o d e d V i e w...
  • Page 11 I n s t a l l i n g S t e p 3 A f t e r I n s t a l l a t i o n Installation Instruction 1. Fasten the inclined support beam (14) to the chassis assembly with 12*70 outer hexagonal bolts (19), 12 at washers (17), and M12 lock nuts (18).
  • Page 12 I n s t a l l i n g S t e p 4 E x p l o d e d V i e w...
  • Page 13 Installation Instruction 1. Fix the shield suppor tframe (24) and the upper beam (20) together with M10*60 outer hexagonal bolts (23), Φ10 washers (4) and M10 lock nuts (25) 2. Connect the upper beam (20) and the guiding rod (2) together, and fasten them with M10*20 outer hexagonal bolts (5), Φ10 washers (4) M10 lock nuts (25).
  • Page 14 I n s t a l l i n g S t e p 5 E x p l o d e d V i e w...
  • Page 15 I n s t a l l i n g S t e p 5 A f t e r I n s t a l l a t i o n Installation Instruction 1. Use M12*130 outer hexagonal bolts (27), Φ12 washers (17) and M12 lock nuts(18) to fasten the decorative board (26) to the upper beam and theinclined support beam assembly.
  • Page 16 I n s t a l l i n g S t e p 6 E x p l o d e d V i e w...
  • Page 17 I n s t a l l i n g S t e p 6 A f t e r I n s t a l l a t i o n Installation Instruction 1. Use M12*70 outer hexagonal bolts (19),Φ12 washers (17) and M12 lock nuts (18) to fasten the seat supporting tube assembly (28) to the lower hole of the incluned support beam 2.
  • Page 18 I n s t a l l i n g S t e p 7 E x p l o d e d V i e w...
  • Page 19 I n s t a l l i n g S t e p 7 A f t e r I n s t a l l a t i o n Installation Instruction 1. Use the 17*123 front pushing frames shaft (36) to connect the front pushing frame (32) and the decorative board (26) together, and fasten it to both ends of the front pushing frames haft (36) with M10*20 outer hexagonal bolts (5) and Φ10*Φ30 washers (38).
  • Page 20 I n s t a l l i n g S t e p 8 E x p l o d e d V i e w 44 17...
  • Page 21 I n s t a l l i n g S t e p 8 A f t e r I n s t a l l a t i o n Installation Instruction 1. Fasten the butter y arm-left (41) to the butter y arm xing board of the inclined support beam with M10*16 outer hexagonal bolts (39) and 10* 30 washers (38).
  • Page 22 I n s t a l l i n g S t e p 9 E x p l o d e d V i e w...
  • Page 23 Installation Diagram of the Chasis and the Flat Pedal...
  • Page 24 I n s t a l l i n g S t e p 1 0 E x p l o d e d V i e w...
  • Page 25 I n s t a l l i n g S t e p 1 0 A f t e r I n s t a l l a t i o n Installation Instruction 1. Use M10*70 outer hexagonal bolts (21), Φ10 washer (4), M10 lock nut (25) to connect with the chasis horizontal tube (106) of the at pedal chasis (105).
  • Page 26 I n s t a l l i n g S t e p 1 1 E x p l o d e d V i e w...
  • Page 27 I n s t a l l i n g S t e p 1 1 A f t e r I n s t a l l a t i o n Installation Instruction 1. Pass M10*35 out hexagonal bolts (120) and 10 washer through the backrest adjusting tube (108) and fasten it to the backrest cushion (60).
  • Page 28 I n s t a l l i n g S t e p 1 2 E x p l o d e d V i e w...
  • Page 29 I n s t a l l i n g S t e p 1 2 A f t e r I n s t a l l a t i o n Installation Instruction 1. Connect the 25*112 at pedal connecting shaft (109) to the at pedal (122) and the at pedal movable tube (107), and use M1O*20 outer hexagon bolts, 10*30 at washers (121) to fasten both sides.
  • Page 30 I n s t a l l i n g S t e p 9 E x p l o d e d V i e w 17 4...
  • Page 31 I n s t a l l i n g S t e p 9 W r i t i n g D i a g r a m...
  • Page 32 In s t a l l i n g S t e p 1 3 A f t e r In s t a l l a t i o n 4240m m Installation Instruction 1. Fix the 5PCS pulley (47) at the ve points A, B, C, E, J with M10*45 outer hexagonal bolts (50), Φ10 washers (4), and M10 lock nuts (25).
  • Page 33 I n s t a l l i n g S t e p 1 0 E x p l o d e d V i e w...
  • Page 34 I n s t a l l i n g S t e p 1 0 A f t e r I n s t a l l a t i o n Transitional Rope Installation Instruction 1. Connect one end of the quick link chain (56) to the transitional rope (55),and the other end of the quick link chain to the chasis weldment.
  • Page 35 I n s t a l l i n g S t e p 1 1 E x p l o d e d V i e w...
  • Page 36 I n s t a l l i n g S t e p 1 1 R o p e W r i t i n g D i a g r a m...
  • Page 37 In s t a l l i n g S t e p 15 A f t e r In s t a l l a t i o n Upper Arm Rope Upper Arm Rope 5150mm Installation Instruction 1. Fasten the 7PCS pulley (47) to points M, N, P, Q, R, T, U with M10*45 outer hexagonal bolts (50), Φ10 washers (4), and M10 lock nuts (25).
  • Page 38 I n s t a l l i n g S t e p 1 2 E x p l o d e d V i e w...
  • Page 39 I n s t a l l i n g S t e p 1 2 A f t e r I n s t a l l a t i o n Low Pull Steel Rope 3290mm Installation Instruction 1.
  • Page 40 I n s t a l l i n g S t e p 1 3 R o p e W r i t i n g D i a g r a m...
  • Page 41 I n s t a l l i n g S t e p 1 3 E x p l o d e d V i e w Installation Instruction 1. Remove the end of the low pull steel rope (104) with the ball head 2.
  • Page 42 I n s t a l l i n g S t e p 1 4 E x p l o d e d V i e w...
  • Page 43 In s t a l l i n g S t e p 1 8 A f t e r In s t a l l a t i o n Installation Instruction 1. Fasten the backrest cushion (59) on the backrest adjusting board with M10*20 outer hexagonal bolts (22) and Φ10 washer (4).
  • Page 44 L o w P u l l S t e e l R o p e...
  • Page 45 S t e e l R o p e W i r i n g D i a g r a m...
  • Page 46 W i r i n g D i a g r a m...
  • Page 47 I n s t a l l i n g S t e p 1 5 E x p l o d e d V i e w...
  • Page 48 In s t a l l i n g S t e p 1 9 A f t e r In s t a l l a t i on Installation Instruction 1. Insert the foam rod (65) into the backrest adjustment frame, and put the foam inner end cap (67), foam (66), and foam outer end cap (68) in sequence at both ends of the foam rod (65).
  • Page 49 I n s t a l l i n g S t e p 1 6 E x p l o d e d V i e w 8 71...
  • Page 50 I n s t a l l i n g S t e p 2 0 A f t e r I n s t a l l a t i o n Installation Instruction 1. Fasten the shield (70) on the shield support frame and the chasis shield xing piece with M8*16 outer hexagonal bolt (71) and Φ8 washer (8) Note: The outer hexagonal bolts need to be tightened...
  • Page 51 I n s t a l l i n g S t e p 1 7 E x p l o d e d V i e w...
  • Page 52 I n s t a l l i n g S t e p 2 1 A f t e r I n s t a l l a t i o n Installation Instruction 1. Insert the foam rod (65) into the backrest adjustment frame, and put the foam inner end cap (67), foam (66), and foam outer end cap (68) in sequence at both ends of the foam rod (65).
