Calibration Functions: V – Hz
Setting the Interval Parameters
ZERO/SEL
300 mV  15 V   1nt
seleCt range
ESC
02.000 V
1nt start
Initial value:
10.000 V
Final value: 1nt end
03.0
Steps: 1nt steps
00.05 min.s
1nt t1
Dwell time:
auto
Repetition: 1nt mode
(Auto = automatic sequence, MAnuAL = manual sequence)
Manually Controlled Interval Sequence
After entering all parameters for the "manual interval sequence"
= manual) and starting the function with
output function ( 1nt mode
the
OUT
ENTER
key, the individual steps are triggered with the  and  keys.
The relationship between the output signal and each of the key
operations is depicted with the help of the following example.
54
–  – Temp – mA
– mA
MEAS/CAL
SETUP
OUT
  
ENTER
OUT
  
ENTER
OUT
  
ENTER
OUT
  
ENTER
OUT
 manual
ENTER
Example of a Manually Controlled Interval Sequence
I
Source
[mA]
Manual
20
16
12
8
4
      
➀ ➁
The time intervals depend on the operator
(they're only identical in the automatic mode).
Key
1 When 1nt
ready appears at the display
Start the sequence by pressing
2 The sequence is continued in the corresponding direction by
pressing the  or  key.
3 Stop the interval sequence by pressing the
Stop
t [s]

ESC
➂
OUT
ENTER
ZERO/SEL
key.
ESC
