User Interface Symbols in the Following Sections
 
... Scroll through main menu
 
... Scroll through submenu
 
Select decimal point

Increase/decrease value
time
Submenu/parameter (7-segment font)
1nFo
Main menu (7-segment font, boldface)
Symbols on the Device
Warning concerning a source of danger
!
(attention: observe documentation!)
Ground
CAT II Overvoltage category II (see also "Measuring Categories
and their Significance per IEC 61010-1" on page 8)
Continuous, doubled or reinforced insulation
EC label of conformity
GMC-I Messtechnik GmbH
Operating Overview – Connections, Keys, Rotary Switch, Symbols
▲ IR ▼
Position of the infrared interface, window on the top of
the instrument
See also section 3.1 regarding location of the
power pack adapter socket.
5V/600mA
Fuse for current measuring ranges, see section 10.3
This device may not be disposed of with the trash.
Further information regarding the WEEE mark can be
accessed on the Internet at
www.gossenmetrawatt.com by entering the search
term WEEE (see also section 10.5).
Calibration Seal (red seal):
Consecutive number
B0730
German Calibration Service – calibration lab
DKD-K-
Registration number
19701
01-04
Date of calibration (year – month)
See also "Recalibration Service" on page 78.
