V/Hz, , Temperature,
and A/Hz Measurements
5.6 Temperature Measurement
Temperature measurement is performed with a thermocouple
(accessory, not included), which is connected to the voltage input.
Alternatively, a resistance thermometer can be used.
Selecting the Unit of Measure for Temperature
MEAS / CAL
1nFo   setup
...
SETUP
OUT
temp unit 
°C / °F
ENTER
(°C = default setting)
5.6.1 Measurement with Thermocouples, Temp TC
➭ Set the rotary switch to "Temp

Note
The last selected temperature sensor remains in memory
and is accordingly displayed.
➭ The reference temperature is measured at the internal
reference junction. It is shown in the right-hand auxiliary display
or else can be queried (see parameter "1tEMP" in section 7.3
regarding querying).
34
OUT
time  
...
ENTER
OUT
ENTER
".
TC

Note
The internal reference temperature (temperature of the
internal reference junction) is measured by a temperature
sensor inside of the instrument. This may be somewhat
above room temperature as a result of internal heat-up, or
moving from warmer to colder surroundings or vice versa.
➭ Connect the sensor to the two accessible jacks. The
instrument displays the measured temperature using the
selected unit of measure.
Temp
TC
1 : 23.5
TC
100.5
TC
C
+ – +
TE (TC)
