Intelligent Weighing Technology IDC-12 Service Manual page 7

Setting a high resolution without providing a good input to the remote scale ADC will not
give better accuracy and may make the scale difficult to meet performance specification.
For best performance ensure a minimum of 0.1uV/d.
3. NAME AND FUNCTIONS
Key Board
Keys Press this key to
Numeric Keys. Enter to individual unit weights and the
present tare
to
Clear incorrect entries and error conditions
Decimal Point. Numeric input numbers select to the left.
Returns the display to zero.
Enter the clear tare weights, Storing the current weight as
tare value. Subtracting the tare value from the total weight
and displays the result as net weight.
Manually enter the weight of sample, also changes the unit
if they are enabled.
Enter the numbers of items, used for the unit weight.
Add the current count data aggregated. Also evokes the
memory if pressed to balance empty. Can add up to 99
values, or until it reaches the maximum displayable digits
Enter to store and recall the PLU
To set the upper limit of the number of items counted and
back light setting.
To select the local or remote scale.
- 7 -
