CHARACTERISTICS:
The HD67170 is a BACnet Slave / SNMP Manager - Converter.
It has the following characteristics:
Up to 1440 bytes in reading and 1440 bytes in writing;
Isolation between Power Supply – Ethernet, Ethernet – Serial, Power Supply - Serial.
Two-directional information between BACnet bus and SNMP bus;
Mountable on 35mm Rail DIN;
Wide power supply input range: 8...24V AC or 12...35V DC;
Wide temperature range: -40°C / 85°C [-40°F / +185°F].
CONFIGURATION:
You need Compositor SW67170 software on your PC in order to perform the following:
Define the parameter of SNMP line;
Define the parameter of BACnet line;
Define the SNMP requests to send to the SNMP Agents;
Define the BACnet Objects in reading and in writing;
Update the device.
