In the field "Time" the delay in ms between two SNMP requests is defined (if "On Timer" is checked);
In the field "Position" it is possible to select the position where take/save the data from/to the internal SNMP array;
In the field "Num Bytes" it is possible to select define the dimension of the SNMP Data;
In the field "Mnemonic" a description of the data inserted in the row is defined.
Note:
If the field "On change" and "On Timer" is checked and the "Poll Time" is different from 0, the converter sends the SNMP writing
request cyclically and also when the data is changed.
Note:
If the "Trap" mode is used, the fields "On CMD", "On Change" and "On Timer" must be disabled.
OBJECTS MAP:
By Pressing the "Objects Map" button from the main window for SW67170 (Fig. 2) is possible to create a .csv document with the map of
BACnet Objects.
