FUNCTION INSTRUCTION &
INSTRUCTION FOR USE
① LCD screen ：
The display screen shows the current brightness, control mode, lighting parameters,
channel values, and battery level of the light.
Channel numerical
Scene number
(lights only when the
light mode is a scene)
Brightness
Current Adjustable
Parameters
② Mode types and functions ：
• Press the mode button to change the control mode, such as: Rotate, slave, master,
or APP.
Rotate Control mode:
Slave Control mode:
the channel of the slave machine is the same as that of the master machine, they
can also be synchronized and controlled.
Master Control mode:
knob, and the slave machines with the same channels will also be adjusted
synchronously.
APP Control mode:
• The multifunctional knob can be used to switch between color temperature, hue,
and saturation, while a long press of 3 seconds can activate/deactivate the scene
lighting mode.
CCT mode: Adjusts the color temperature within a range of 3200K~5600K.
HUE mode: Adjusts the hue within a range of 0°~360°.
SAT mode: Adjusts the saturation within a range of 0%~100%.
SC mode: Can simulate 18 different scene lighting effects, including Lightning, Cop
Car, Candle, TV, Bad Bulb, Party, Disco, Paparazzi, Explosion, Pulsing, Fire, Fireworks,
Welding, CCT Loop, Hue Loop, Ambulance, Fire Engine, and SOS.
S C : C H :
CCT : HUE :
TIM : SAT :
the lighting effect is adjusted by the dimming knob.
the channels can only be adjusted by the ▲ ▼ buttons, and if
the lighting effect and channels are adjusted by the dimming
the lighting effect is adjusted by the APP.
10
Battery power
Rotate
Control mode
Slave
(Only display the current
control mode)
Master
APP
Correlated Color
Temperature / HUE /
%
O Saturation / Time
ms
K
parameter
(Only currently adjustable
parameters are displayed.)
