GVM -800D-II Manual page 11

DESCRIPTION OF PRODUCT
CONTROL KEYS
1
DC15V power input interface
1
Power switch
2
Mode control button: Change mode control
3
Change channel button: When is in master/slave mode, press this button to select
4
the channel.
Brightness adjustment button: Adjust the brightness
5
Multifunctional knob:
6
saturation. A long press for 3 seconds can activate/deactivate the scene lighting
mode. In scene lighting mode, short-pressing the knob can be used to switch
between parameter adjustments and scene types, while rotating the knob can be
used to adjust the values.
LCD screen ：displays the current lighting parameters, control modes, channel
7
values, scene number, and more.
S C : C H :
Rotate
Slave
7
Master
APP
CCT : HUE :
%
O
ms
TIM : SAT : K
5
BRG
Short press to switch between color temperature, hue, and
9
4
3
MODE
6
Battery
CCT / HUE / SAT / SCE
OFF Adapter
2
