Summary of Contents for Westermo RedFox-5728-F16G-T12G-HVHV
Page 1
www.wester mo.com RedFox 5728 Series Industrial routing switches...
Page 2
Table of Contents 1. General Information ................3 1.1.
Page 3
Westermo reserves the right to revise this document or withdraw it at any time without prior notice.
Page 4
2. Safety and Regulations 2.1. Warning Levels Warning signs are provided to prevent personal injuries and/or damages to the product. The following levels are used: Level of warning Description Consequence Consequence personal injury material damage Indicates a potentially Possible death or Major damage to the hazardous situation major injury...
Page 5
(only valid for metallic housings). Westermo recommends a cross-sectional area of at least 4 mm Upon removal of the product, disconnect the product from the power supply and all other communication ports before disconnecting the protective earthing conductor.
Page 6
PROTECTIVE FUSE It must be possible to disconnect manually from the power supply. Ensure compliance to national installation regulations. Replacing the internal fuse must only be performed by Westermo qualified personnel. POWER SUPPLY CONNECTION There are safety regulations governing the power source that can be used in conjunction with the product.
Page 7
CLASS 1 LASER PRODUCT Do not look directly into a fibre optical port or any connected fibre, although the product is designed to meet the Class 1 Laser regulations and complies with 21 CFR 1040.10 and 1040.11. HANDLING OF SFP TRANSCEIVERS SFP transceivers are supplied with plugs to avoid contamination inside the optical port.
Page 8
If the product is not working properly, contact the place of purchase, the nearest Westermo distributor office or Westermo technical support. 2.4. Product Disposal This symbol means that the product shall not be treated as unsorted municipal waste when disposing of it.
Page 9
2.5. Compliance Information 2.5.1. Agency Approvals and Standards Compliance Type Approval/Compliance • EN 50121-4/IEC 62236-4, Railway signalling and telecommunications apparatus • EN/IEC 61000-6-2, Immunity industrial environments • EN/IEC 61000-6-4, Emission industrial environments • EN/IEC 61000-6-5, Immunity power station and substation environment •...
Page 10
2.5.4. Simplified Declaration of Conformity Hereby, Westermo declares that this product is in compliance with applicable EU directives and UK legislations. The full declaration of conformity and other detailed information is available at www.westermo.com/support/product-support. Figure 2. The European Conformity and the UK Conformity Assessment markings...
Page 11
3. Product Description 3.1. Product Description RedFox 5728 takes communication reliability for substations to a new level. We know that in critical substation automation applications, even the loss of a single piece of data can disturb the operations, and that is why RedFox 5728 brings the highest reliability to your network.
Page 13
3.3. Hardware Overview 11 12 21 22 23 24 27 28 NO C NC POWER 110-240 VAC / VDC Status N (-) L (+) AC/DC Digital in AC/DC Description Description I/O connection Console port Micro SD LED indicators 100/1000 Mbit/s SFP port (number 10/100/1000 Mbit/s TX ports depending on model) (number depending on model)
Page 14
Illustration Position Product Direction Description marking AC/DC1 L(+) Input Line/Phase (AC), positive (DC) N (-) L (+) AC/DC N(-) Input Neutral (AC), negative/return (DC) Input Functional earth Table 4. Power input HV Illustration Product marking Direction Description +DC1 Input Supply voltage COM +DC +DC2 Input...
Page 15
WARNING - PREVENT ACCESS TO HAZARDOUS VOLTAGE CABLE Apply the protective cap (if delivered with the product) on the power cable, according to the illustrated steps below. The number of pins on the connector plug may vary depending on product. To prevent accidentally pulling out wires, make sure the power cable and the wires are firmly attached to the protective cap.
Page 16
WeOS user documentation at www.westermo.com. An external load in series with an external DC voltage source is required for proper functionality. Unit condition Status NO- C Status NC-C Unpowered / pre-operational or Alarm active OPEN CLOSED Operational and Alarm inactive...
Page 17
Each SFP slot can hold one SFP transceiver. See "Transceiver User Guide 6100-0000" for transceiver handling instructions, which also can be downloaded from the product support pages at www.westermo.com/support/product-support. In the event of contamination, the optical connectors in the SFP transceivers should only be cleaned by the use of forced nitrogen and some kind of cleaning stick.
Page 18
3.5. LED Indicators Status Description Product has no power GREEN All OK, no alarm condition Alarm condition, or until product has started up. (Alarm conditions are configurable, see WeOS5 User Guide) RSTP/ RSTP disabled USR1 GREEN RSTP enabled BLINK Product selected as RSTP/STP root switch USR1 Configurable, see WeOS5 User Guide FRNT...
Page 19
3.6. Dimensions Dimensions are stated in mm. 482,4 DETAIL A SCALE 1 : 1 7,2 (x4) Figure 6. Dimensional drawing, illustrated by a RedFox-5728-F16G-T12G-HVHV RedFox 5728 Series...
Page 20
4. Installation 4.1. Mounting RedFox-5728 is designed for installation in 19" rack solutions, with a shallow depth of 240 millimetres. 4.1.1. Rack Mounting The product can be mounted in all directions inside a 19" apparatus cabinet. Use supplied M6x25 (Philips no. 3) or 1/4x1" screws. Statu s Digit al in Figure 7.
Page 21
High-power SFPs 11 12 21 22 23 24 27 28 NO C NC POWER 24-48 VDC Status COM +DC Digital in Low-power SFPs (or non-populated) Figure 9. SFP placement Generally, singlemode (SM) and bi-directional (BiDi) SFPs have higher current consumption than multimode (MM) SFPs. Copper (Cu) SFPs can have a power consumption of up to 1.2 W with an active 1000BASE-T link.
Page 22
5. Specifications 5.1. Interface Specifications NOTE - USE OF ANTISTATIC ARM-WRIST BAND To minimize the risk of exposing the unit to unintentional large static electric fields - if service and maintenance need to be performed during operation, always use an antistatic arm-wrist band. RedFox 5728 Series...
Page 23
Power port Rated voltage LV and LVLV models: 24-48 VDC HV and HVHV models: 110-240 VAC, 50-60 Hz, 110-240 VDC Operating voltage LV and LVLV models: 18-60 VDC HV and HVHV models: 85-264 VAC, 47-63 Hz, 85-264 VDC b.c. Rated current RedFox-5728-(E-)F4G-T24G-LV 1.08 A at 24 VDC and 0.54 A RedFox-5728-(E-)F4G-T24G-LVLV...
Page 24
Power port Tightening torque, screw 0.34 Nm flange For LV and LVLV models, only compliant Class I or Class II power supplies with SELV/PELV output shall be used with the product For HVHV models, AC/DC1 shall be regarded as the primary supply input, which gives the highest efficiency.
Page 25
I/O connection, Relay output Contact resistance Maximum 30 Ω Isolation to All other ports Connector Detachable screw terminal Conductor cross section 0.08-1.5 mm² (AWG 28-16). Use copper conductors only. (flexible) Stripping length cable 7 mm Cable temperature rating Minimum temperature rating of the cable to be connected to the field wiring terminals is +77 °C Tightening torque, 0.22-0.25 Nm...
Page 26
SFP ports Optical/Electrical IEEE std 802.3 specification Data rate 100 Mbit/s, 1 Gbit/s Duplex Full or half, manual or auto Transmission range Depending on transceiver Connector SFP slot holding fibre transceiver SFP ports are: RedFox-5728-F4G-T24G-HV, -HVHV, -LV and -LVLV: 1-4 RedFox-5728-F16G-T12G-HV, -HVHV, -LV and -LVLV: 1-6, 11-14, 19-22, 27-28 RedFox-5728-F24G-T4G-LV and -LVLV: 1-22,27-28 Console port...
Page 27
5.2. Type Tests and Environmental Conditions Environmental Basic Description Test levels phenomena standard EN 61000-4-2 Enclosure Contact: ±8 kV Air: ±15 kV Fast transients EN 61000-4-4 AC power port ±4 kV, direct coupling DC power port Earth port I/O port ±4 kV, capacitive coupling clamp Ethernet ports Surge EN 61000-4-5...
Page 28
Environmental Basic Description Test levels phenomena standard Radiated RF EN 61000-4-3 Enclosure 20 V/m, 80% AM (1 kHz) at 80 MHz to 2 immunity IEEE Std GHz, Spot freq.: 80, 160, 380, 450, 900, C37.90.2 1600, 1850 MHz 10 V/m, 80% AM (1 kHz) at 2 to 6 GHz, Spot freq.: 2150, 3800 MHz 20 V/m, pulse keying (2 Hz) at 80 MHz to 1 GHz, Spot freq.: 1732, 1800 MHz...
Page 29
Environmental Basic Description Test levels phenomena standard Temperatures EN 60068-2-1 Operational -40 to +70°C (-40 to +158°F) EN 60068-2-2 Storage and -50 to +85°C (-58 to +185°F) transport 60068-2-14 Humidity Operational 5-95% relative humidity 680068-2-30 Storage and transport 60068-2-78 Altitude Operational 2000 m/80 kPa Service life...
Page 30
Environmental Basic Description Test levels phenomena standard Vibration Operational Class 2, 10 to 60 Hz at ±0.075 mm, 60255-21-1 60 to 150 Hz at 1g 1 sweep cycle in each axis, 1 octave/ min. Non- Class 2, 10 to 150 Hz at 2g operational, 20 sweep cycles in each axis, 1 octave/ endurance test...
Page 31
Environmental Basic Description Test levels phenomena standard Location EN/IEC/UL Indoor use 61010-1 Table 11. Environmental and mechanical conditions RedFox 5728 Series...
Page 32
6. Revision Notes Revision Date Change description Rev. H 2024-12 2.2. Safety Information; Warning - Prevent access to hazardous voltage cable updated, 2.4 Product Disposal updated, 2.5.1 Agency Approvals and Standards Compliance updated, 3.2 Available Models updated, 3.4.2. I/O Connection updated, 4.3 Cooling;...
