- Page 1 www.wester mo.com RedFox 5528 Series Industrial routing switches...
- Page 2 Table of Contents 1. General Information ................3 1.1.
- Page 3 Westermo reserves the right to revise this document or withdraw it at any time without prior notice.
- Page 4 2. Safety and Regulations 2.1. Warning Levels Warning signs are provided to prevent personal injuries and/or damages to the product. The following levels are used: Level of warning Description Consequence Consequence personal injury material damage Indicates a potentially Possible death or Major damage to the hazardous situation major injury...
- Page 5 (only valid for metallic housings). Westermo recommends a cross-sectional area of at least 4 mm Upon removal of the product, disconnect the product from the power supply and all other communication ports before disconnecting the protective earthing conductor.
- Page 6 PROTECTIVE FUSE It must be possible to disconnect manually from the power supply. Ensure compliance to national installation regulations. Replacing the internal fuse must only be performed by Westermo qualified personnel. POWER SUPPLY CONNECTION There are safety regulations governing the power source that can be used in conjunction with the product.
- Page 7 If the product is used in a manner not according to specification, the protection provided by the equipment may be impaired. If the product is not working properly, contact the place of purchase, the nearest Westermo distributor office or Westermo technical support. RedFox 5528 Series...
- Page 8 2.4. Product Disposal This symbol means that the product shall not be treated as unsorted municipal waste when disposing of it. It needs to be handed over to an applicable collection point for recycling electrical and electronic equipment. Proper disposal of the product helps minimize hazardous substances and prevents potential negative impacts on both the environment and human health.
- Page 9 Table 3. EN/IEC/UL 62368-1 notice 2.5.4. UL 62368-1 DC Mains Notice In accordance with UL 62368-1, Annex DVD and DVH then Westermo does not recommend using the mechanical enclosure/chassis (PE) as a conductive part of the sourced earthed DC power system in a DC mains distribution networks. If so, the...
- Page 10 This product generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the user manual, may cause harmful interference to radio communications. Operation of this product in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at the users own expense.
- Page 11 2.5.8. Simplified Declaration of Conformity Hereby, Westermo declares that this product is in compliance with applicable EU directives and UK legislations. The full declaration of conformity and other detailed information is available at www.westermo.com/support/product-support. Figure 2. The European Conformity and the UK Conformity Assessment markings...
- Page 12 3. Product Description 3.1. Product Description The RedFox 5528 series is designed for the core of large high-performance industrial networks and has been developed to cater to the needs of current and future industrial data networks, combining outstanding performance, durability and reliability.
- Page 13 AC/DC 3641-4520 RedFox-5528-F16G-T12G-LV 24-48 3641-4420 RedFox-5528-E-F16G-T12G-LV 3641-4528 RedFox-5528-F16G-T12G-HV 110-240 V 3641-4428 RedFox-5528-E-F16G-T12G-HV AC/DC 3641-4600 RedFox-5528-F24G-T4G-LV 24-48 3641-4700 RedFox-5528-E-F24G-T4G-LV 3.3. Hardware Overview 11 12 21 22 23 24 27 28 NO C NC POWER 110-240 VAC / VDC Status N (-)
- Page 14 3.4. Connector Information 3.4.1. Power Input Illustration Product marking Direction Description +DC1 Input Supply voltage COM +DC +DC2 Input Supply voltage -COM Input Common -COM Input Common Table 4. Power input LV models Illustration Position Product Direction Description marking AC/DC1 L(+) Input Line/Phase...
- Page 15 The Status output is a potential free, opto-isolated, alternation (Form-C) solid-state relay. This can be configured to monitor various alarm events within the product, see WeOS user documentation at www.westermo.com. An external load in series with an external DC voltage source is required for proper functionality. ...
- Page 16 Figure 4. Insertion of micro SD card 3.4.5. SFP Transceivers The product supports UL and IEC certified transceivers only. See Westermo's modular transceivers datasheets 100 Mbit and 1 Gbit for supported SFP transceivers, which can be downloaded from the product support pages at www.westermo.com/support/...
- Page 17 3.5. LED Indicators Status Description Product has no power GREEN All OK, no alarm condition Alarm condition, or until product has started up. (Alarm conditions are configurable, see WeOS5 User Guide) RSTP/ RSTP disabled USR1 GREEN RSTP enabled BLINK Product selected as RSTP/STP root switch USR1 Configurable, see WeOS5 User Guide FRNT...
- Page 18 3.6. Dimensions Dimensions are stated in mm. 482,4 7,2 (x4) Figure 5. Dimensional drawing RedFox 5528 Series...
- Page 19 4. Installation 4.1. Mounting RedFox is designed for installation in 19" rack solutions according to ETSI standard, with a shallow depth of 240 millimetres. It can also be wall mounted as an installation option. 4.1.1. Rack Mounting The product can be mounted in all directions inside a 19" apparatus cabinet. Use supplied M6x25 (Philips no.
- Page 20 4.3. Cooling This product relies on convection cooling. To avoid obstruction of the airflow around the product, follow the spacing recommendations. For mounting in 19" apparatus cabinet without forced ventilation, a minimum spacing of 1U according to IEC 60297 or 45 mm (1.75") above and below is recommended. With forced ventilation, no minimal spacing is required as long as the temperature of the rear cooling plates does not exceed +85ºC (+185ºF).
- Page 21 SFP type Max. number of SFPs Total SM/BiDi All MM: 4 x SM/BiDi: 8 x SM/BiDi: 4 x Cu: Table 9. Guidelines on recommended SFP population schemes for some typical use cases RedFox 5528 Series...
- Page 22 5. Specifications 5.1. Interface Specifications Power port Rated voltage For LV models: 24-48 VDC For HV models: 110-240 V AC/DC Operating voltage For LV models: 18-60 VDC For HV models: 85-264 VAC 47-63 Hz, 85-264 VDC Rated current RedFox-5528-(E-)T28G-LV: 0.95 A at 24 VDC 0.49 A at 48 VDC RedFox-5528-(E-)T28G-HV: 0.12 A at 240 V AC/DC...
- Page 23 Power port Cable temperature rating Minimum temperature rating of the cable to be connected to the field wiring terminals is +77 °C Tightening torque, 0.34 Nm terminal screw Tightening torque, screw 0.34 Nm flange Shielded cable Not required Measured for 1 second at startup Recommended external supply current capability for proper startup I/O connection, Digital input Isolation to...
- Page 24 I/O connection, Relay output Contact resistance Maximum 30 Ω Isolation to All other ports Connector Detachable screw terminal Conductor cross section 0.08 - 1.5 mm² (AWG 28-16). Use copper conductors only. Stripping length cable 7 mm Cable temperature rating Minimum temperature rating of the cable to be connected to the field wiring terminals is +77 °C Tightening torque, 0.22 - 0.25 Nm...
- Page 25 SFP ports Optical/Electrical IEEE std 802.3 specification Data rate 100 Mbit/s, 1000 Mbit/s Duplex Full or half, manual or auto Transmission range Depending on transceiver Connector SFP slot holding fibre transceiver SFP ports are: RedFox-5528-(E-)F4G-T24G-LV/HV: 1-4 RedFox-5528-(E-)F16G-T12G-LV/HV: 1-6, 11-14, 19-22, 27-28 RedFox-5528-(E-)F24G-T4G-LV: 1-22, 27-28 100 Mbit/s or 1000 Mbit/s tranceiver supported Console port...
- Page 26 5.2. Type Tests and Environmental Conditions Environmental Basic Description Test levels phenomena standard EN 61000-4-2 Enclosure Contact: ±6 kV Air: ±8 kV Fast transients EN 61000-4-4 Power port ± 2 kV I/O ports Earth port Surge 1.2/50 µs EN 61000-4-5 Power port LV models: L-E: ±...
- Page 27 Environmental Basic Description Test levels phenomena standard CISPR 22 Ethernet ports LV models: Class B HV models: Class A Dielectric strength EN/IEC/UL Power port to all LV models: 1500 VAC rms, 60 s 62368-1 other ports I/O port to all other ports Ethernet ports to all other ports...
- Page 28 Environmental Basic Description Test levels phenomena standard Temperatures EN 60068-2-1 Operational For LV models: -40 to +74°C (-40 to EN 60068-2-2 +165°F) For HV and (E-)F24G-T4G-LV models: -40 to +70°C (-40 to +158°F) Storage and -50 to +85°C (-58 to +185°F) transport Humidity Operational...
- Page 29 Environmental Basic Description Test levels phenomena standard Degree of EN 60529 Enclosure IP40 protection Cooling Convection Pollution degree EN/IEC/UL HV models: PD2 Macro and Micro 61010-1, EN Environment 50124-1, EN/IEC/UL 62368-1 Overvoltage EN/IEC/UL HV models: OVC II category 61010-1, EN/IEC/UL 62368-1 Insulation class EN/IEC/UL...
- Page 30 4.1.2 Wall Mounting, illustration updated, 5.1 Interface Specifications updated (Power) Rev. G 2020-10 Westermo logo updated, illustrations throughout user guide updated with blue colour, 2.2 Safety information; warnings updated, 2.3 Care Recommendations; text updated, 2.5.1 Agency Approvals and Standards Compliance; table updated, 2.5.2 new chapter, 2.5.3 FCC Part 15.105 Class B Notice;...
- Page 31 Revision Date Change description chapter, 5.1 Interface Specifications table updated (name change HV to MV) Rev. E 2019-10 1.5 WeOS text updated, 3.2 Available Models table updated (name change HV to MV), 3.3 Hardware Overview Figure 3 text updated (name change HV to MV), 3.6 Dimensions text updated (name change HV to MV), 4.1 Mounting text updated, 5.1 Interface Specifications table updated (name change HV to MV), 5.2 Type Test and Environmental Conditions table updated (name change HV to...
- Page 32 6641-22820 REV N 2024 12 @ Westermo Network Technologies AB, Sweden...
