- Page 1 www.wester mo.com Lynx 3510 PoE Industrial gigabit switch...
-
Page 2: Table Of Contents
Table of Contents 1. General Information ................ 3 1.1. Legal Information ..............3 1.2. About This Guide ..............3 1.3. Software Tools ..............3 1.4. License and Copyright for Included FLOSS ......... 3 1.5. WeOS ................. 3 2. Safety and Regulations ..............4 2.1. -
Page 3: General Information
Westermo reserves the right to revise this document or withdraw it at any time without prior notice. Under no circumstances shall Westermo be responsible for any loss of data or income or any special, incidental, and consequential or indirect damages howsoever caused. -
Page 4: Safety And Regulations
2. Safety and Regulations 2.1. Warning Levels Warning signs are provided to prevent personal injuries and/or damages to the product. The following levels are used: Level of warning Description Consequence Consequence personal injury material damage Indicates a potentially Possible death or major Major damage to the hazardous situation injury... -
Page 5: Safety Information
During installation, ensure a protective earthing conductor is first connected to the protective earthing terminal (only valid for metallic housings). Westermo recommends a cross-sectional area of at least 4 Upon removal of the product, ensure that the protective earthing conductor is disconnected last. - Page 6 REDUCE THE RISK OF FIRE To reduce the risk of fire, use only telecommunication line cords with a cable diameter of AWG 26 or larger. Regarding power cable dimensions, see chapter Interface Specifications. HOT SURFACE Be aware that the surface of this product may become hot. When it is operated at high temperatures, the external surface may exceed Touch Temperature Limit according to the product's relevant electrical safety standard.
-
Page 7: Care Recommendations
If the product is not working properly, contact the place of purchase, the nearest Westermo distributor office or Westermo technical support. 2.4. Product Disposal This symbol means that the product shall not be treated as unsorted municipal waste when disposing of it. -
Page 8: Fcc Part 15.105 Class A Notice
2.5.4. Simplified Declaration of Conformity Hereby, Westermo declares that this product is in compliance with applicable EU directives and UK legislations. The full declaration of conformity and other detailed information is available at www.westermo.com/support/product-support. -
Page 9: Product Description
(MTBF), maximized service life and reduced operational and life cycle costs. The switches are thoroughly tested both by Westermo and external test institutes to meet a rich selection of EMC, isolation, vibration and shock standards, all to the highest levels suitable for heavy industrial environments and rail trackside applications. -
Page 10: Hardware Overview
3.3. Hardware Overview Figure 3. Location of interface ports and LED indicators Description Description LED indicators SFP ports Ethernet TX ports (PoE+) I/O port Micro SD Console port Protective earth terminal Label with data matrix Power port The base MAC address and production date of the product is included in the front label data matrix. 3.4. -
Page 11: I/O Connection
POWER SUPPLY CONNECTION There are safety regulations governing the power source that can be used in conjunction with the product. Refer to chapter Interface Specifications. 3.4.2. I/O Connection Illustration Pin no. Product marking Direction Description Output Relay output common Output Relay output normally open DI + Input... -
Page 12: Micro Sd
3.4.4. Micro SD To insert the micro SD card correctly, turn the gold plated pins upwards towards the text "microSD". Figure 5. Insertion of micro SD card Lynx 3510 PoE... -
Page 13: Led Indicators
3.5. LED Indicators Status Description Product has no power GREEN All OK, no alarm condition Alarm condition, or until product has started up. (Alarm conditions are configurable, see WeOS5 User Guide) USR1 Configurable, see WeOS5 User Guide RING RING protocol disabled GREEN RING ok RING error... -
Page 14: Dimensions
3.6. Dimensions Dimensions are stated in mm and are regardless of model. 42 min. Figure 6. Dimensional drawing Lynx 3510 PoE... -
Page 15: Installation
4. Installation 4.1. Mounting This product should be mounted on a 35 mm DIN-rail, which is horizontally mounted inside an apparatus cabinet or similar dry location. 1. To mount the product, first push the support pin down, then towards the front of the product to lock the support pin. -
Page 16: Panel Mounting
Figure 8. Removal of product by pushing the support pin Figure 9. Removal of product with screwdriver 4.3. Panel Mounting The product can be mounted to a panel with cage nuts made for 5.3 mm square holes with a 1-1.6 mm panel thickness. Lynx 3510 PoE... -
Page 17: Wall Mounting
Figure 10. Panel mounting with cage nuts 4.4. Wall Mounting The product can be mounted to a wall with screws. Figure 11. Wall mounting with screws 4.5. Cable Strap The product has loops on the right side that cable straps can be attached to, to help collecting the connector cables and lead them aside. -
Page 18: Functional Earth Connection
Figure 12. Cable straps 4.6. Functional Earth Connection For correct function, the earth connection needs to be properly connected to a designated PE rail. See the figure below. Torx: T25 and torque: 3.2 Nm. 54 V DC1 + DC2 + RING COM- USR1... -
Page 19: Cooling
4.7. Cooling This unit uses convection cooling. To avoid obstructing the airflow around the unit, use the following spacing rules. Minimum spacing 25 mm (1.0 inch) above / below and 10 mm (0.4 inches) left / right the unit. Spacing is recommended for the use of unit in full operating temperature range and service life. -
Page 20: Specifications
5. Specifications 5.1. Interface Specifications DC, Power port Rated voltage 54 VDC, Class III (SELV/PELV) Operating voltage 802.3at (PoE+): 53 to 57 VDC 802.3af: 48 to 57 VDC No PoE usage: 12 to 57 VDC Rated current Max. 4.8 A Fuse rating Denote time-delay fuse 6.3 A(T) - Page 21 I/O connection, Digital input Isolation to All other ports Connector Detachable screw terminal connector Conductor cross section 0.2-1.5 mm² (AWG 24-16). Use copper conductors only. Stripping length cable 10 mm Circuit type SELV ≤ 2.9 mA at 60 VDC Maximum voltage/current 60 VDC, I Voltage levels Logic one: >8 VDC...
- Page 22 Ethernet TX Output voltage 48-57 VDC Output power Max 30 W on one port (802.3.at; "PoE+") Total output power 240 W 150 W 40°C 60°C 70°C Max 240 W at -40°C to +60°C (-40°F to 140°F) Linear derating with 9 W/°C (5 W/°F) between +60°C to +70°C (+140°F to 158°F) Max 150 W at +70°C (+158°F) Electrical specification...
- Page 23 Console port Electrical specification USB 2.0 device interface Data rate Up to 480 Mbps (high-speed mode). Emulates UART, settings 115200 bps. Circuit type SELV Maximum supply current 100 mA Connector USB-C connector in device mode Micro SD Electrical specification Secure Digital 2.0 Circuit type SELV Maximum supply current...
-
Page 24: Type Tests And Environmental Conditions
5.2. Type Tests and Environmental Conditions Environmental Basic Description Test levels phenomena standard EN 61000-4-2 Enclosure Contact: ±6 kV Air: ±8 kV Fast transients EN 61000-4-4 Power port ± 2 kV, 5 kHz, 100 kHz Direct coupling Earth port I/O port ±... - Page 25 Environmental Basic Description Test levels phenomena standard Power supply DNVGL- Power port 1.3 x U (62.4 VDC), 0.75 x U variation CG-0339 VDC), 15 min Immunity to DNVGL- Power port 3 Vrms, 0.05 to 10 kHz conducted CG-0339 low frequency interference Insulation resistance DNVGL-...
- Page 26 Environmental Basic Description Test levels phenomena standard Temperatures EN 60068-2-1 Operational -40 to +70°C (-40 to +158°F) at EN 60068-2-2 maximum 150 W PoE budget -40 to +60°C (-40 to +140°F) at 240 W PoE budget -10 to +70 °C (14 to +158 °F) for CT- models at 150 W PoE budget -10 to +60 °C (14 to +140 °F) for CT- models at 240 W PoE budget...
-
Page 27: Revision Notes
6. Revision Notes Revision Date Change description Rev. B 2022-09 Name changed to Lynx 3510 PoE throughout the user guide Rev. A 2022-04 First revision Lynx 3510 PoE... - Page 28 Westermo • Metallverksgatan 6, SE-721 30 Västerås, Sweden Tel +46 16 42 80 00 Fax +46 16 42 80 01 E-mail: info@westermo.com www.westermo.com 6627-2210 REV B 2022 09 Westermo Network Technologies AB, Sweden...
