Puls DIMENSION CP5.482 Manual

CP-Series
P D
RODUCT ESCRIPTION
The Dimension CP-Series are cost optimized power
supplies without compromising quality, reliability and
performance. The CP-Series is part of the DIMENSION
power supply family.
While the CP5.481 covers an additional DC-input range
up to 150Vdc, the CP5.482 features an enhanced DC
input voltage range up to 300Vdc.
The most outstanding features of these units are the
small size, the high efficiency, the electronic inrush
current limitation, active PFC and the wide operational
temperature range. The devices have a power reserve of
20% included, which may even be used continuously at
temperatures up to +45°C. Additionally, they can deliver
3 times the nominal output current for 12ms which
helps to trip fuses on faulty output branches.
High immunity to transients and power surges as well as
low electromagnetic emission, a DC-OK signal contact
for remote monitoring, and a large international
approval package for a variety of applications makes
this unit suitable for nearly every situation.
O N
RDER UMBERS
Power Supply CP5.481
CP5.482
Mechanical Accessory
ZM10.WALL Wall/Panel mount bracket
Jul. 2019 / Rev. 1.0 DS-CP5.481-EN
25°C ambient and after a 5 minutes run-in time unless otherwise noted.
Screw terminals
Enhanced DC input range
All parameters are typical values specified at 230Vac, 50Hz input voltage, 48V, 2.5A output load,
www.pulspower.com Phone +49 89 9278 0
CP5.481, CP5.482
48V, 2.5A, 120W, S
P S
OWER UPPLY
AC 100-240V Wide-range Input
Width only 32mm
Efficiency up to 93.5%
Excellent Partial Load Efficiency
20% Output Power Reserves
Easy Fuse Breaking – 3 times nominal current for 12ms
PLUS
Safe Hiccup Overload Mode
Active Power Factor Correction (PFC)
Minimal Inrush Current Surge
Full Power Between -25°C and +60°C
DC-OK Relay Contact
3 Year Warranty
S - D
HORT FORM
Output voltage DC 48V
Adjustment range 48 - 56V
Output current 3.0 – 2.6A
2.5 – 2.1A
1.9 – 1.6A
Derate linearly between +45°C and +70°C
Input voltage AC AC 100-240V
Mains frequency 50-60Hz
Input current AC 1.09 / 0.61A
Power factor 0.98 / 0.91
Input voltage DC DC 110-150V
DC 110-300V
Input current DC 1.21 / 0.43A
AC Inrush current 4 / 4A
Efficiency 92.6 / 93.5%
Losses 9.6 / 8.4W
Hold-up time 35 / 35ms
Temperature range -25°C to +70°C
Size (WxHxD) 32x124x102mm
Weight 440g / 0.97lb
M A
AIN PPROVALS
For details or a complete approval list see chapter 19.
IEC 62368-1
IEC 61010-1
IEC 61010-2-201
Germany
P I
INGLE HASE NPUT
ATA
Nominal
Factory setting 48.0V
Below +45°C ambient
At +60°C ambient
At +70°C ambient
-15%/+10%
±6%
At 120 / 230Vac
At 120 / 230Vac
±20%
For CP5.481
±20%
For CP5.482
At 110 / 300Vdc
At 120 / 230Vac
At 120 / 230Vac
At 120 / 230Vac
At 120 / 230Vac
Without DIN-rail
IND. CONT. EQ.
planned
