ASROCK Rack 1U8S4E Series User Manual

Server/workstation motherboard
Hide thumbs

Advertisement

Quick Links

Download this manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the 1U8S4E Series and is the answer not in the manual?

Questions and answers

Related Manuals for ASROCK Rack 1U8S4E Series

Summary of Contents for ASROCK Rack 1U8S4E Series

  • Page 2: Copyright Notice

    In no event shall ASRock Rack, its directors, officers, employees, or agents be liable for any indirect, special, incidental, or consequential damages (including damages for loss of profits, loss of business, loss of data, interruption of business and the like), even if ASRock Rack has been advised of the possibility of such damages arising from any defect or error in the documentation or product.
  • Page 3 “Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/ perchlorate” ASRock Rack’s Website: www.ASRockRack.com Setting up the Server in a Restricted Access Location/Restricted Access Area • Access can only be gained by service persons or by users who have been instructed about the reasons for the restrictions applied to the location and about any precautions that shall be taken.

  • Page 4: Replaceable Batteries

    Replaceable Batteries CAUTION RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS Warning When removal of the chassis lid required for servicing: - Turn off power and unplug any power cords/cables, and - Reinstall the chassis lid before restoring power.

  • Page 5: Table Of Contents

    Contents Chapter 1 Introduction Shipping Box Contents Specifications Chapter 2 Server System Overview System Components Internal Features System Front Panel System Rear Panel Front Control Panel Buttons and LEDs Drive Tray LEDs PSU LED Chapter 3 Hardware Installation and Maintenance Server Top Covers Hard Drive Power Supply...

  • Page 7: Chapter 1 Introduction

    1U8S4E Series Chapter 1 Introduction Thank you for purchasing 1U8S4E Series, a reliable barebone system produced under ASRock Rack’s consistently stringent quality control. It delivers excellent performance with robust design conforming to ASRock Rack’s commitment to quality and endurance. This guide provides the instructions of insertion and extraction of chassis components, such as chassis covers, system fans, power supplies, hard disk drive trays, and other main components this system supports.

  • Page 8: Shipping Box Contents

    1.1 Shipping Box Contents Item Quantity 1U8S4E- GENOA/2T EGS/2T 1U8S4E Series (1U Barebone) System Board (MB) Power Supply Unit System Fan HDD Backplane (BPB) Front Panel Board (FPB) Riser Board (PCIe x16) Accessory Box 1U Cooler/Heatsink Slide Rail If any items are missing or appear damaged, contact the authorized dealer.

  • Page 9: Specifications

    1U8S4E Series 1.2 Specifications 1U8S4E Series System Physical Status Form Factor 1U Rackmount Dimension 676.5 x 438 x 43.4 mm (26.6'' x 17.2'' x 1.7'') (D x W x H) Support MB 1U8S4E-GENOA/2T : GENOAD8UD-2T/X550 1U8S4E-EGS/2T : SPC741D8UD-2T/X550 Front Panel Buttons •...

  • Page 10: Chapter 2 Server System Overview

    Chapter 2 Server System Overview This chapter provides diagrams showing the location of important components of the server system. 2.1 System Components Add-in card x16 (for PCIE slot on the server board) 2 x Power Supply Units 6 x System Fans Server Board Front Control Panel Buttons 1U8S4E-GENOA/2T : 1 Type-A (USB3.2 Gen1)

  • Page 11: Internal Features

    1U8S4E Series 2.2 Internal Features From Add-in card x16(for PCIE slot on the server board) Server Board 2 x Power Supply Units (PSU) 1U8S4E-GENOA/2T : System Fan 1 1U8S4E-EGS/2T : System Fan 6...
  • Page 12 From 1U8S4E-GENOA/2T : System Fan 2 1U8S4E-EGS/2T : System Fan 5 1U8S4E-GENOA/2T : System Fan 3 1U8S4E-EGS/2T : System Fan 4 1U8S4E-GENOA/2T : System Fan 4 1U8S4E-EGS/2T : System Fan 3 1U8S4E-GENOA/2T : System Fan 5 1U8S4E-EGS/2T : System Fan 2 1U8S4E-GENOA/2T : System Fan 6 1U8S4E-EGS/2T : System Fan 1 2.5"...

  • Page 13: System Front Panel

    1U8S4E Series 2.3 System Front Panel Description Control Panel (depends on the specification of the server board) 4 x Hot-swap 2.5" NVMe (PCIe5.0 x4) drive bays 8 x Hot-swap 2.5" SATA drive bays 1U8S4E-GENOA/2T : 1 Type-A (USB3.2 Gen1) 1U8S4E-EGS/2T : 1 Type-A (USB2.0) 2.4 System Rear Panel...

  • Page 14: Front Control Panel Buttons And Leds

    2.5 Front Control Panel Buttons and LEDs RST NMI Description System Reset Button NMI (Nonmaskable Interrupt) Button Power Button and LED ID Button and LED Hard Drive Status LED System Status LED LAN1 Activity LED LAN2 Activity LED *Please be noted that the functions are supported depending on the type of the server board.

  • Page 15: Power Button

    1U8S4E Series System Reset Button When the system is completely unresponsive, press the system reset button to reboot the server without shutting it off and initialize the system. ID Button Press the ID button to toggle the front panel ID LED and the baseboard ID LED on and off.

  • Page 16: Drive Tray Leds

    LEDs Hard Drive Tray Description Hard Drive Tray Status LED Hard Drive Tray Activity LED LED Definitions Activity (No.2) Status (No.1) Description Drive Not Present Drive Present(no active) Solid Green Solid Blue Drive Present(active) Green Blinking at 4Hz Solid Blue Locate Solid Green Blue Blinking at 4Hz...

  • Page 17: Psu Led

    1U8S4E Series 2.7 PSU LED PSU LED PSU LED PSU Status LED Status Description Green Output ON and OK No AC power to all power supplies Green blinking at 1Hz AC present / Only AUX on (PS off) or PSU in Cold...

  • Page 18: Chapter 3 Hardware Installation And Maintenance

    Chapter 3 Hardware Installation and Maintenance This chapter helps user to assemble the chassis and install components. Before You Begin Before working with the server, pay close attention to the “Important Safety Instructions” at the beginning of this manual. 1. Make sure the server is powered off. Power down the server if it is still running.

  • Page 19: Server Top Covers

    1U8S4E Series 3.1 Server Top Covers Removing the Server Top Covers 1. Before removing the top covers, power off the server and unplug the power cord. 2. The system must be operated with all the chassis top covers installed to ensure proper cooling.
  • Page 20 Installing the Server Top Covers 1. Then lower the top rear cover on the chassis, making sure the side latches align with the cutouts. Slide the top rear cover toward the FRONT of the chassis. 2. Secure the top rear cover in place with a screw. 3.

  • Page 21: Hard Drive

    1U8S4E Series 3.2 Hard Drive Removing 2.5” Hard Drive 1. Press the locking lever latch on the drive tray to unlock the retention lever. 2. Rotate the lever out and away from the module bay and pull the hard drive out of the Hard Drive tray.
  • Page 22 Installing a 2.5” Hard Drive to the Hard Drive Tray 1. Engage the one side of hard drive into the tray by aligning the side bracket. 2. Carefully push down the other side of the hard drive until it is locked into place Front Panel-Installing the HDD assembly 1.

  • Page 23: Power Supply

    The 1U8S4E Series system supports single PSU only. The 1U8S4E Series system can accommodate two AC or two DC power supplies in the bay at the rear of the chassis. Each unit provides up to 750 Watts of power.
  • Page 24 Removing the Power Supply Unit To remove a failed power supply, identify the failed power supply by checking the power supply LEDs on the PSU. 1. Hold onto the power supply handle while pressing the locking lever towards the power supply handle.* *The illustration is for references only.

  • Page 25: Replacing The System Fan

    1U8S4E Series 3.4 System Fan Replacing the System Fan 1. Press and hold the clip on the fan. Align the mounting holes on the fan bar with the fan mount on the replacement fan. Please be aware of the mount location of each fan.

  • Page 26: Add-In Card (Riser Card For Bpb Connections)

    3.5 Add-in Card (Riser Card PCIe x16) 1. Install an add-in card to the chassis only when having a riser card installed on the server board. 2. Before installing the add-in card, power off the server and unplug the power cord. Removing the Riser-Card Bracket from the Chassis 1.
  • Page 27 1U8S4E Series Installing the Add-in Card 1. Install the add-in card to the riser-card bracket assembly. 2. Secure the add-in card to the assembly with a screw.
  • Page 28 3. Align the riser-card assembly with the openings of the chassis. 4. Hand-tighten the thumbscrew to secure the assembly to the chassis.
  • Page 29 1U8S4E Series Appendix A Installing the CPU (LGA 4677 Socket) 1U8S4E-EGS/2T : SPC741D8UD-2T/X550 Unplug all power cables before installing the CPU. Socket Dust Cover CPU Carrier...
  • Page 31 1U8S4E Series...
  • Page 32 CPU Carrier...
  • Page 33 1U8S4E Series Heatsink CPU Carrier Socket...
  • Page 35 1U8S4E Series Installing the CPU (LGA 6096 Socket) 1U8S4E-GENOA/2T : GENOAD8UD-2T/X550 1. Before inserting the CPU into the socket, please check if the PnP cap is on the socket, if the CPU surface is unclean, or if there are any bent pins in the socket. Do not force to insert the CPU into the socket if above situation is found.
  • Page 37 1U8S4E Series Carr ier Frame with CPU Rail Frame Please make sure that the carrier frame with CPU is closely attached to the rail frame while inserting it. Install the carrier frame with CPU. Don’t separate them.
  • Page 39 1U8S4E Series Set your torque wrench to 1.54 in-lb. One fourth a turn each time. Tighten the screws in a sequential order 1 > 2 > 3 > 4 > 5 > 6. Loosen the screws in a reverse order.

  • Page 40: Installation Of Memory Modules (Dimm)

    Appendix B Installation of Memory Modules (DIMM) The DIMM only fits in one correct orientation. It will cause permanent damage to the motherboard and the DIMM if you force the DIMM into the slot at incorrect orientation. For more information about DIMM installation, please refer to the User Manual that comes with the server board used.
  • Page 41 1U8S4E Series Type B (Two Clips)
  • Page 42 Appendix C Block Diagram (SPC741D8UD-2T/X550) 2T/X550 R5.00 topology DDR5 CHE DDR5 CHA DDR5 CHF DDR5 CHB DDR5 CHG DDR5 CHC DDR5 CHH DDR5 CHD SPR(HBM) PE0 PE1 PE2 PE3 MCIO 1-2 PCIe x16 Gen5 PCIE7 PCIE5 PCIe x16 Gen5 PCIe x16 Gen5 PCIE4 PCIE6 PCIe x16 Gen5...
  • Page 43 1U8S4E Series Block Diagram (GENOAD8UD-2T/X550) DDR5 RDIMM/RDIMM-3DS DDR5 RDIMM/RDIMM-3DS DDR5 RDIMM/RDIMM-3DS DDR5 RDIMM/RDIMM-3DS DDR5 RDIMM/RDIMM-3DS DDR5 RDIMM/RDIMM-3DS DDR5 RDIMM/RDIMM-3DS MAC1 Video UART Ethernet DDR5 RDIMM/RDIMM-3DS 10/100/1000...

  • Page 44: Contact Information

    Contact Information Contact ASRock Rack or want to know more about ASRock Rack, you’re welcome to visit ASRock Rack’s website at http://www.asrockrack.com; or contact the dealer for further information. For technical questions, please submit a support request form at https://event.

This manual is also suitable for:

1u8s4e-genoa/2t1u8s4e-egs/2t
