Installation Guide
1.1 Installation Equipment Requirements
This section lists everything that must be in place or available to perform the installation, including the
equipment and its components.
Table 2: Included Equipment and Components
Category
Components
Screws
Cables
Table 3: Additional Equipment Needed
ESD Mitigation Equipment (site specific)
Ethernet Cable w/ RJ-45 connectors
Table 4: Torque Specifications for Screws
Screw Type
T15 Torx screws
Item
Chassis w/ 2x Power Supply Units (PSU),
2x IO Modules (IOM), and System Fans
Rail Assembly kit (includes left and right rail
assemblies and rack-mounting hardware)
Drive Assembly Storage Devices
Drive Blanks
T15 Torx Flat Head screws w/ washers
3m, C13 - C14 Power Cables
Equipment
T15 Torx Screwdriver
Level
Lift Equipment
Rail Assemblies
1.1 Installation Equipment Requirements
Required or Recommended?
Where Used
3.38-3.61 Nm / 30-32 in-lbf
1. Installation
# Included
1
1
1 - 24
(depending on configuration)
0 - 23
(depending on configuration)
8
2
Required
Recommended
Recommended
Required
Required
Torque Value
2
