EcoDesign
Disclosures
Ultrastar® Data60 3000 Series
Regulatory Model H4060-J
Document D018-000830-000
Revision 01
June 2024

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EcoDesign Ultrastar Data60 3000 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Western Digital EcoDesign Ultrastar Data60 3000 Series

Summary of Contents for Western Digital EcoDesign Ultrastar Data60 3000 Series

  • Page 1 EcoDesign Disclosures Ultrastar® Data60 3000 Series Regulatory Model H4060-J Document D018-000830-000 Revision 01 June 2024...

  • Page 2: Table Of Contents

    EcoDesign Disclosures Table of Contents Table of Contents Revision History........................................ii Notices............................................iii Points of Contact......................................iv Chapter 1. EU EcoDesign Disclosures................1 EcoDesign Overview....................................2 Data60 3000 Series EcoDesign Specifications........................2 Instant Secure Erase / Secure Erase............................2 Data60 3000 Series Disassembly..............................5 IOM Disassembly......................................60 HEM Disassembly....................................

  • Page 3: Revision History

    EcoDesign Disclosures Revision History Revision History Date Revision Comment June 2024 Initial release...

  • Page 4: Notices

    Per Western Digital Terms and Conditions of Sale, the user of Western Digital products in life support applications assumes all risk of such use and indemnifies Western Digital against all damages.

  • Page 5: Points Of Contact

    Points of Contact Points of Contact For further assistance with a Western Digital product, contact Western Digital Datacenter Platforms technical support. Please be prepared to provide the following information, as applicable: part number (P/N), serial number (S/N), product name and/or model number, software version, and a brief description of the issue.

  • Page 6: Chapter 1. Eu Ecodesign Disclosures

    EU EcoDesign Disclosures This document provides information and instructions related to the Data60 3000 Series disclosures for the EU's ecodesign requirements. In This Chapter: - EcoDesign Overview....................... 2 - Data60 3000 Series EcoDesign Specifications...........2 - Instant Secure Erase / Secure Erase............... 2 - Data60 3000 Series Disassembly................

  • Page 7: Ecodesign Overview

    Secure Erase (SE) features included with Western Digital drives. Data Erasure Options Western Digital provides several options for securely erasing data from its drives. The appropriate method depends upon many factors, including the following: • Erase Configuration (ISE or SE) •...
  • Page 8 Western Digital technical support, or download the following whitepaper for details: https://documents.westerndigital.com/content/dam/doc-library/en_us/assets/public/western-digital/ collateral/tech-brief/tech-brief-instant-secure-erase... ISE / SE Overview Instant Secure Erase (ISE) is Western Digital’s implementation of the industry standard T10 (SAS)/T13 (SATA) command, allowing users to instantly erase both user-accessible data and hidden user sanitize data from Western Digital drives.
  • Page 9 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.3 Instant Secure Erase / Secure Erase • ISE - Crypto Erase - HDD/SSD: # sg_sanitize --crypto --quick <dev> • SE - Overwrite - HDD: # sg_sanitize --overwrite --quick --zero <dev> • Block Erase - SSD: # sg_sanitize --block --quick <dev>...

  • Page 10: Data60 3000 Series Disassembly

    1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Data60 3000 Series Disassembly 1.4  Data60 3000 Series Disassembly This procedure provides instructions for disassembling a Data60 3000 Series storage enclosure. This procedure assumes the enclosure is installed in a rack. Note: Table 3: System Disassembly Information Category Details 2 –...
  • Page 11 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Data60 3000 Series Disassembly Figure 1: Unlatch the Elbow-Side of the CMA Arms b. Open both CMA arms to expose the rear of the enclosure. Figure 2: Open the CMA Arms Remove the CMA. Step 2 :...
  • Page 12 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Data60 3000 Series Disassembly a. Power down the enclosure by unplugging both power cables from the PSUs. Then, unplug the power cables from their power distribution unit (PDU). b. Unplug the SAS and management cables from the HEMs. c.
  • Page 13 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Data60 3000 Series Disassembly Figure 5: Remove the CMA Arms Remove the cable tray. Step 3 : a. Use a T15 Torx screwdriver to loosen the cable tray's four (4) captive screws. Figure 6: Loosen the Cable Tray Captive Screws b.
  • Page 14 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Data60 3000 Series Disassembly Figure 7: Remove the Pins From the Slots Figure 8: Remove the Cable Tray Step 4 : Remove the system fans. a. Using your thumb and forefinger, press the latches on the top and bottom of the system fan, and pull to remove it from the system fan housing.
  • Page 15 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Data60 3000 Series Disassembly Figure 9: Press the System Fan Latches Figure 10: Remove the System Fan b. Repeat these steps to remove the remaining system fans. Step 5 : Remove the PSUs. a. If needed, rotate the PSU handle outward.
  • Page 16 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Data60 3000 Series Disassembly Figure 11: Rotate the PSU Handle b. Using your thumb and forefinger, grasp the PSU handle and depress the latch. Then remove the PSU from its slot. Figure 12: Depress the PSU Latch...
  • Page 17 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Data60 3000 Series Disassembly Figure 13: Remove the PSU c. Repeat these steps to remove the remaining PSU. Remove the HEMs. Step 6 : a. 2. Use a #2 Phillips screwdriver to loosen the HEM's captive screw. Alternately, loosen the captive screw by hand.
  • Page 18 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Data60 3000 Series Disassembly Figure 15: Lower the HEM Latch Bar c. Use the latch bar to pull the HEM out of the enclosure. Figure 16: Remove the Old HEM d. Repeat these steps to remove the remaining HEM. e.
  • Page 19 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Data60 3000 Series Disassembly Figure 17: Loosen the Rack-Ear Screws b. Grasp both enclosure handles and rotate them outward. This will disengage the enclosure latches from the rack brackets, allowing the enclosure to be pulled out of the rack.
  • Page 20 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Data60 3000 Series Disassembly Figure 19: Pull the Enclosure Out The chassis cover is secured to the rack and will remain in place, exposing the interior of the enclosure. Step 8 : Remove the IOM(s). a.
  • Page 21 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Data60 3000 Series Disassembly Figure 21: Rotate the Handles Figure 22: Remove the IOM b. If you are working with the SAS chassis, repeat these steps to remove the remaining IOM. c. Set asside the IOM(s) for further disassembly. Remove the IOM Fan.
  • Page 22 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Data60 3000 Series Disassembly Figure 23: Squeeze the Latches Figure 24: Remove the IOM Fan Step 10 : Remove the drive assemblies. a. Using your thumb and forefinger, squeeze the drive carrier's latches inward to release the drive assembly from its slot.
  • Page 23 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Data60 3000 Series Disassembly Figure 25: Remove the Drive b. Repeat these steps to remove the remaining drive assemblies. Step 11 : Remove the enclosure from the rack. Warning: The following steps for removing the enclosure from the rack require two people.
  • Page 24 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Data60 3000 Series Disassembly Figure 26: Unlock the Safety Latches b. With the assistance of another person, pull the enclosure away from the rack until the inner rails (attached to the chassis) are separated from the outer rails (attached to the rack). Set the enclosure on an ESD-safe work surface.
  • Page 25 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Data60 3000 Series Disassembly Figure 28: Remove the Inner Rail Screws b. Pull to release the inner rail latch. This will allow each rail to slide forward, freeing the alignment pins on the chassis from the keyholes on the rail. Figure 29: Release Inner Rail Latch c.
  • Page 26 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Data60 3000 Series Disassembly Figure 30: Remove the Inner Rails Remove the chassis cover. Step 13 : a. At the front of the rack, use a T15 Torx screwdriver to loosen the two (2) captive screws of the chassis cover (one on each side).
  • Page 27 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Data60 3000 Series Disassembly b. Pull the chassis cover forward to free its alignment pins from the alignment brackets, and continue pulling it forward to remove it from the rack. Figure 32: Remove theChassis Cover Step 14 : Remove the rail assembly's stabilizer bar.
  • Page 28 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Data60 3000 Series Disassembly Figure 34: Open the Stabilizer Bar c. Slide the bar backward to remove it from the rail assembly. Figure 35: Remove the Stabilizer Bar Step 15 : Remove the alignment brackets. a.
  • Page 29 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Data60 3000 Series Disassembly Figure 36: Loosen the Alignment Bracket Screws b. Slide the alignment bracket forward to remove it from the rack.
  • Page 30 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Data60 3000 Series Disassembly Figure 37: Remove the Alignment Bracket c. Repeat these steps to remove the other alignment bracket. Remove the screwplates. Step 16 : a. Loosen the bottom three (3) screws of the screwplate.
  • Page 31 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Data60 3000 Series Disassembly Figure 38: Loosen the Bottom Screws b. Pull the screwplate backward to remove it from the rack.
  • Page 32 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Data60 3000 Series Disassembly Figure 39: Remove the Screwplate c. Repeat these steps to remove the other screwplate. Step 17 : Remove the outer rails from the rack. a. At the front of the rack, unlock the safety latches of the outer rails and push the rails back into the rack.
  • Page 33 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Data60 3000 Series Disassembly Figure 40: Push Outer Rails Back In b. At the front of the rack, use a T15 Torx screwdriver to remove the three (3) screws securing each latch bracket to the rack (6 screws total). Figure 41: Remove Latch Bracket Screws c.
  • Page 34 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Data60 3000 Series Disassembly Figure 42: Remove the Latch Brackets d. At the rear of each outer rail, press the release latch. Then, slide the rail toward the front of the rack to remove the outer rail pins from their locations on the rack.
  • Page 35 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Data60 3000 Series Disassembly Figure 43: Press the Release Latch Figure 44: Slide the Outer Rail Forward...
  • Page 36 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Data60 3000 Series Disassembly e. At the front of each outer rail, press the release latch outward. Then, slide the rail toward the rear of the rack to remove the outer rail pins from their locations on the rack. Figure 45: Press the Release Latch Figure 46: Slide the Outer Rail Backward The outer rails are now removed from the rack.
  • Page 37 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Data60 3000 Series Disassembly Figure 47: Remove the Plenum Cover Screws b. Pull the plenum covers upward to remove them from the chassis. Figure 48: Remove the Plenum Covers Step 19 : Remove the power distribution board (PDB) cover. a.
  • Page 38 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Data60 3000 Series Disassembly Figure 49: Remove the PDB Cover Screws b. Pull the PDB cover upward to remove it from the chassis.
  • Page 39 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Data60 3000 Series Disassembly Figure 50: Remove the PDB Cover Step 20 : Remove the rear bulkhead assembly. a. At the left-rear of the chassis, use a T7 Torx screwdriver to remove the six (6) screws securing the rear bulkhead assembly to the chassis.
  • Page 40 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Data60 3000 Series Disassembly Figure 51: Remove the Left-Rear Bulkhead Assembly Screws b. At the right-rear of the chassis, use a T7 Torx screwdriver to remove the six (6) screws securing the rear bulkhead assembly to the chassis.
  • Page 41 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Data60 3000 Series Disassembly Figure 52: Remove the Right-Rear Bulkhead Assembly Screws c. At the rear of the chassis, use a T7 Torx screwdriver to remove the six (6) screws securing the rear bulkhead assembly to the chassis. Figure 53: Remove the Rear Bulkhead Assembly Screws d.
  • Page 42 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Data60 3000 Series Disassembly Figure 54: Remove the Rear Bulkhead Assembly e. The fan cables and system LED cable run from the rear bulkhead assembly to connectors on the baseboard of the chassis. Unclip the two (2) fan cable connectors from the baseboard. Then unclip the one (1) LED cable connector from the baseboard.
  • Page 43 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Data60 3000 Series Disassembly Figure 55: Unclip the Fan Connectors Figure 56: Unclip the LED Connector f. Remove the rear bulkhead assembly.
  • Page 44 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Data60 3000 Series Disassembly Figure 57: Remove the Rear Bulkhead Assembly Step 21 : Remove the HEM alignment guides. a. The HEM alignment guides have tabs that fit into holes on the baseboard. Use your fingers —or a flat-head screwdriver—to pry up the tabs and free the HEM alignment guides from the baseboard.
  • Page 45 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Data60 3000 Series Disassembly Figure 58: Pry Up the HEM Alignment Guide Tabs b. Pull the HEM alignment guides backward to remove them from the chassis. Figure 59: Remove the HEM Alignment Guides Remove the IOM housing.
  • Page 46 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Data60 3000 Series Disassembly Figure 60: Remove the PDB Screws b. On each side of the IOM housing, use a T7 Torx screwdriver to remove the eight (8) screws shown in the following image (16 screws total).
  • Page 47 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Data60 3000 Series Disassembly Figure 61: Remove the IOM Housing Screws Step 23 : Pull the IOM housing upward to remove it from the chassis.
  • Page 48 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Data60 3000 Series Disassembly Figure 62: Remove the IOM Housing Step 24 : Disassemble the IOM housing. a. Lay the IOM housing on its left side, as shown in the following image. Figure 63: Lay Down theIOM Housing b.
  • Page 49 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Data60 3000 Series Disassembly Figure 64: Remove the Side Panel Screws c. Pull the side panel upward to remove it from the IOM housing. Figure 65: Remove the Side Panel...
  • Page 50 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Data60 3000 Series Disassembly d. Use a T7 Torx screwdriver to remove the three (3) screws securing the PDB to the IOM housing. Figure 66: Remove the PDB Screws e. Pull the PDB upward to remove it from the IOM housing.
  • Page 51 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Data60 3000 Series Disassembly Figure 67: Remove the PDB Step 25 : Remove the drive dividers. a. At the front-right of the chassis, use a T7 Torx screwdriver to remove the four (4) screws securing the right drive divider to the right side of the chassis.
  • Page 52 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Data60 3000 Series Disassembly Figure 68: Remove the Right Drive Divider Screws b. At the front-left of the chassis, use a T7 Torx screwdriver to remove the four (4) screws securing the left drive divider to the left side of the chassis. Figure 69: Remove the Left Drive Divider Screws...
  • Page 53 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Data60 3000 Series Disassembly c. On the left side of the chassis, use a T7 Torx screwdriver to remove the twelve (12) screws securing the left drive divider to the left side of the chassis. Figure 70: Remove the Left Drive Divider Screws d.
  • Page 54 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Data60 3000 Series Disassembly Figure 72: Remove the Right Drive Divider Screws f. At the front-left of the chassis, use a T8 Torx screwdriver to remove the two (2) screws securing the left drive divider to the left side of the chassis. Figure 73: Remove the Left Drive Divider Screws...
  • Page 55 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Data60 3000 Series Disassembly g. Inside the drive dividers, use a T7 Torx screwdriver to remove the eight (8) screws securing the drive dividers through the baseboards to the chassis. Figure 74: Remove the Inside Drive Divider Screws h.
  • Page 56 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Data60 3000 Series Disassembly Figure 75: Remove the Right Drive Divider i. Pull the left drive divider upward to remove it from the chassis.
  • Page 57 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Data60 3000 Series Disassembly Figure 76: Remove the Left Drive Divider Step 26 : Remove the drive limiters. The bottom side of each drive limiter has clips that fit into holes in the Note: baseboard.
  • Page 58 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Data60 3000 Series Disassembly Figure 77: Drive Limiter Clips a. Use your fingers—or a flat-head screwdriver—to pry up the ten (10) drive limiters at their clip locations, and remove them from the baseboard. Figure 78: Remove the Drive Limiters Step 27 : Remove the baseboard.
  • Page 59 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Data60 3000 Series Disassembly Figure 79: Remove the Baseboard Screws b. At the front-left corner of the chassis, use a flat-head screwdriver to pry up and remove the pins and cover securing the LED board connector.
  • Page 60 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Data60 3000 Series Disassembly Figure 80: Remove the LED Connector Cover c. Disconnect the ribbon cable from its baseboard connector.
  • Page 61 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Data60 3000 Series Disassembly Figure 81: Disconnect the Cable d. Pull the baseboard upward to remove it from the chassis.
  • Page 62 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Data60 3000 Series Disassembly Figure 82: Remove the Baseboard Remove the LED board. Step 28 : a. At the front of the chassis, use a T7 Torx screwdriver to remove the nine (9) screws securing the LED board to the chassis.
  • Page 63 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Data60 3000 Series Disassembly Figure 83: Remove the LED Board Screws b. Pull the LED board upward to remove it from the chassis.
  • Page 64 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.4 Data60 3000 Series Disassembly Figure 84: Remove the LED Board   R esult:   T he Data60 3000 Series enclosure is now disassembled.   W hat to do next:   P roceed to IOM Disassembly (page 60)

  • Page 65: Iom Disassembly

    1. EU EcoDesign Disclosures EcoDesign Disclosures 1.5 IOM Disassembly 1.5  IOM Disassembly This procedure provides instructions for disassembling the IOM of a Data60 3000 Series storage enclosure. Table 4: IOM Disassembly Information Category Details Number of People Required Time 7 minutes T7 Torx screwdriver Required Tools T10 Torx screwdriver...
  • Page 66 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.5 IOM Disassembly Figure 87: Lift the Bottom Edge of the Side Panel Figure 88: Remove the Side Panel Step 4 : Use a T10 Torx screwdriver to remove the four (4) screws securing the PCB assembly to the IOM housing.
  • Page 67 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.5 IOM Disassembly Figure 89: Remove the PCB Assembly Screws Step 5 : Pull the PCB assembly upward to remove it from the IOM housing. Figure 90: Remove the PCB Assembly   R esult:   T he IOM is now disassembled.  ...

  • Page 68: Hem Disassembly

    1. EU EcoDesign Disclosures EcoDesign Disclosures 1.6 HEM Disassembly 1.6  HEM Disassembly This procedure provides instructions for disassembling the HEM of a Data60 3000 Series storage enclosure. Table 5: HEM Disassembly Information Category Details Number of People Required Time 5 minutes Required Tools T7 Torx screwdriver Place the HEM on an ESD-safe work surface.
  • Page 69 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.6 HEM Disassembly Figure 92: Remove the Front-Left Corner Screws Step 3 : Use a T7 Torx screwdriver to remove the two (2) screws at the front-right corner of the HEM. Figure 93: Remove the Front-Right Corner Screws Step 4 : Rotate the faceplate upward and away from the HEM housing until it is freed from the SAS ports.
  • Page 70 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.6 HEM Disassembly Figure 94: Remove the Faceplate Step 5 : Use a T7 Torx screwdriver to remove the four (4) screws securing the PCB assembly to the HEM housing. Figure 95: Remove the PCB Assembly Screws Pull the PCB assembly upward to remove it from the HEM housing.
  • Page 71 1. EU EcoDesign Disclosures EcoDesign Disclosures 1.6 HEM Disassembly Figure 96: Remove the PCB Assembly   R esult:   T he HEM is now disassembled.
