PRODUCT DETAILS:
Part Number:
ECU Number:
Tail Harness Length Required:
TBM/Lug Part Number:
Wiring Part Number:
FITTING DETAILS:
Towbar Installation Time:
Wiring Installation Time:
Total Installation Time:
Bumper Cut Required:
49-75 Pacific Drive Keysborough, VIC 3173
Phone: 1800 812 017
Email: info@haymanreese.com.au
Rev:
A
03452RW
Maximum Towing Braked:
04826
Maximum Towing Unbraked:
1800 mm
Maximum Static Ball Load:
21232
102695-WL
60 Mins.
Hayman Reese SmartCODE Solution Required:
60 Mins.
RPA Disable/Other:
120 Mins.
Note:
Yes
Page
INSTALLATION INSTRUCTIONS
PART NUMBER
HAVAL JOLION A01 HEV CL4
•
Rear Cross traffic is disabled via accessing
Intelligent systems menu on the centre
infotainment.
•
RPA is disable via button on dash.
•
13mm drill required.
1
TOWBAR
03452RW
1500
kg
750
kg
150
kg
NO
YES
Issue Date:
08-12-2022
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Hayman Reese 03452RW
Summary of Contents for Hayman Reese 03452RW
- Page 1 Maximum Static Ball Load: TBM/Lug Part Number: 21232 Wiring Part Number: 102695-WL FITTING DETAILS: Towbar Installation Time: 60 Mins. Hayman Reese SmartCODE Solution Required: Wiring Installation Time: 60 Mins. RPA Disable/Other: Total Installation Time: 120 Mins. Note: • Rear Cross traffic is disabled via accessing...
- Page 2 1. 2. Do not, drill, cut, weld or otherwise modify the towbar. FOR TOWING PURPOSES ONLY - This towbar is designed and tested by Hayman Reese to adhere to ADR 62/02 which provides only for the expected load demands of towing.
- Page 3 ITEM DESCRIPTION ITEM DESCRIPTION HAVAL JOLION WELDED ASSEMBLY WASHER PLAIN M14x28x3 TRAILER BALL MOUNT HAYMAN REESE LOGO STICKER NUT HEX HD M12x1.75P HITCH BOX COLLAR COVER NUT NYLOC HEX HD M4x0.7P "D" SHACKLE 10mm FITTING PLATE Ø50mm SMART PIN GOLD BOLT HEX HD M14x50x1.5P...
- Page 4 TOWBAR INSTALLATION INSTRUCTIONS PART NUMBER 03452RW HAVAL JOLION A01 HEV CL4 1. Open tailgate, lift the plastic screw covers and remove the remove 2 x screws securing the taillight along with the 2 x screws on the rubber boot stops.
- Page 5 TOWBAR INSTALLATION INSTRUCTIONS PART NUMBER 03452RW HAVAL JOLION A01 HEV CL4 5. Along the underside of the bumper, remove 2 x screws. 6. Peel away from the sides and remove bumper. Ensure to disconnect any wiring connectors from the main loom located on the LH side.
- Page 6 TOWBAR INSTALLATION INSTRUCTIONS PART NUMBER 03452RW HAVAL JOLION A01 HEV CL4 9. Position the towbar up to the chassis rail and loosely secure with 2 x M14 bolts complete with 1 x washer per bolt. Repeat for the other side.
- Page 7 TOWBAR INSTALLATION INSTRUCTIONS PART NUMBER 03452RW HAVAL JOLION A01 HEV CL4 12. At an appropriate position on the bumper, mark out and drill 2x ø5mm holes 69mm apart on bumper skin to support plug bracket. 13. Fold down rear passenger seats (1).
- Page 8 TOWBAR INSTALLATION INSTRUCTIONS PART NUMBER 03452RW HAVAL JOLION A01 HEV CL4 18. Remove screws and bolts holding both the RHS & LHS Rear Interior Trim (1). 19. Dislodge both the RHS & LHS Rear Interior Trim (1) towards the centre of the vehicle.
- Page 9 TOWBAR INSTALLATION INSTRUCTIONS PART NUMBER 03452RW HAVAL JOLION A01 HEV CL4 24. Push the Vehicle LHS tail lamp grommet (1) and connector inside the vehicle and connect the vehicle LH tail lamp connector to the mating Trailer Harness connector. 25. Pull the Trailer Wiring Harness LHS tail lamp connecter back thru the hole and secure the grommet.
- Page 10 TOWBAR INSTALLATION INSTRUCTIONS PART NUMBER 03452RW HAVAL JOLION A01 HEV CL4 31. Route the orange power wire towards the RHS vehicle interior Fuse box. 32. Tuck the power wire under the trim as required. 33. Remove Fuse box Cover to expose 6mm positive stud (1).
- Page 11 TOWBAR INSTALLATION INSTRUCTIONS PART NUMBER 03452RW HAVAL JOLION A01 HEV CL4 38. For RPA Disable locate the bumper connector on the LHS rear of the vehicle. Note: RPA Disable Grey & Grey/Black Wires may need to be extended. 39. Peel back the tube on Pin 5 Black/Yellow wire, on the 20 Way Connector and cut it 100mm back from the connector.
- Page 12 TOWBAR MAINTENANCE AND CARE: 1. Hayman Reese recommend that the towbar LUG or TBM (tow ball Mount) Pull Pin and R-clip are removed and stored when not in use. Removal of LUG or TBM (tow ball mount) is advisable when not in use to assist with any of the following.
- Page 13 VEHICLE’S GLOVEBOX AFTER INSTALLATION HAYMAN REESE SMART PIN Your Hayman Reese towbar is equipped with Smart Pin technology to help reduce towbar tongue rattle in most driving conditions. Please ensure below instructions are understood and routine maintenance is carried out to ensure best towing experience.
