INSTALLATION INSTRUCTIONS
PLEASE ENSURE THAT INSTRUCTIONS ARE UNDERSTOOD PRIOR TO FITMENT
PLACE THESE INSTRUCTIONS IN THE VEHICLE'S GLOVEBOX AFTER INSTALLATION IS COMPLETED
Towbar Installation Instructions
TOYOTA CAMRY ASV70R CL4
Part Number
03229RW
ECU: 04831
Power Harness: 04825
Tail Length: 1200mm
RPA Disable: Via button on steering wheel
Electric brake input location: BLUE wire near ECU
Hayman Reese (Cequent)
PO Box 4050, Dandenong South VIC 3164
Phone 1800 812 017 Email info@haymanreese.com.au
Rev: A
HAYMAN REESE
PART No:
03229RW
TOYOTA CAMRY ASV70R CL4
Installation Time: Approx
Max Towing Braked
Max Towing Unbraked
Max Static Ball Load
Page 1
Towbar capacity
1200
500
120
Issue Date:
165
Mins
kg
kg
kg
09-08-2018
Advertisement
Related Manuals for Hayman Reese 03229RW
Summary of Contents for Hayman Reese 03229RW
- Page 1 Power Harness: 04825 Tail Length: 1200mm RPA Disable: Via button on steering wheel Electric brake input location: BLUE wire near ECU Hayman Reese (Cequent) PO Box 4050, Dandenong South VIC 3164 Phone 1800 812 017 Email info@haymanreese.com.au Rev: A Page 1...
- Page 2 The high tensile fasteners supplied with this product were used to achieve the specified rating. If replacement is required ensure that fasteners of the same rating & quality are used. Contact an authorised Hayman Reese dealer if further information is required.
- Page 3 ACRYLIC COMPLIANCE LABEL WASHER PLAIN 1/2X1-1/8X16G WIRING LOOM M10x1.25x45 HEX BOLT PC8.8 NUT HEX HD M10 X 1.25P G8 Hayman Reese (Cequent) PO Box 4050, Dandenong South VIC 3164 Phone 1800 812 017 Email info@haymanreese.com.au Rev: A Page 3 Issue Date:...
- Page 4 3. Unclip cover from bumper on underside of vehicle via 6 x scrivets and 5 x plastic hex head nuts. Remove cover and set aside with hardware. Hayman Reese (Cequent) PO Box 4050, Dandenong South VIC 3164 Phone 1800 812 017 Email info@haymanreese.com.au Rev: A...
- Page 5 Set bumper aside. 6. Remove impact beam via 6 x hex head bolts (3 each side). Discard impact beam and bolts. Hayman Reese (Cequent) PO Box 4050, Dandenong South VIC 3164 Phone 1800 812 017 Email info@haymanreese.com.au Rev: A Page 5...
- Page 6 Repeat for opposite side. 9. Remove heat shield covering chassis rail via 2 x hex head nuts. Set aside with hardware. Repeat for opposite side. Hayman Reese (Cequent) PO Box 4050, Dandenong South VIC 3164 Phone 1800 812 017 Email info@haymanreese.com.au Rev: A...
- Page 7 Tighten all fasteners to the torques listed below: M10 x 1.25 x G8.8: 48 N.m M12 x 1.25 x G8.8: 89 N.m Hayman Reese (Cequent) PO Box 4050, Dandenong South VIC 3164 Phone 1800 812 017 Email info@haymanreese.com.au Rev: A...
- Page 8 Mark out and drill 2x ø5mm holes 69mm apart on bumper skin to support plug bracket. Feed bracket threads through drilled holes prior to reinstalling bumper. Hayman Reese (Cequent) PO Box 4050, Dandenong South VIC 3164 Phone 1800 812 017 Email info@haymanreese.com.au Rev: A...
- Page 9 19. Remove the RHS luggage compartment trim panel (1). 20. Disconnect the negative battery terminal (2). Hayman Reese (Cequent) PO Box 4050, Dandenong South VIC 3164 Phone 1800 812 017 Email info@haymanreese.com.au Rev: A Page 9...
- Page 10 23. Remove the tool tray. 24. Remove the rear luggage compartment scuff plate (1) by removing the four clips (2) and pulling in an upwards direction Hayman Reese (Cequent) PO Box 4050, Dandenong South VIC 3164 Phone 1800 812 017 Email info@haymanreese.com.au Rev: A...
- Page 11 30. Apply double sided tape to the ECU (2) and secure it to the vehicle sheet metal (1). 31. Connect the trailer patch 12-way connector (3) to the ECU (2). Hayman Reese (Cequent) PO Box 4050, Dandenong South VIC 3164 Phone 1800 812 017 Email info@haymanreese.com.au Rev: A...
- Page 12 Tie up any excess lengths if required. Note: Keep harness routing clear of all sharp edges, moving parts and places of extreme heat. Hayman Reese (Cequent) PO Box 4050, Dandenong South VIC 3164 Phone 1800 812 017 Email info@haymanreese.com.au Rev: A Page 12...
- Page 13 45. Re-fit all removed parts and secure all fasteners, ensuring there are no squeaks or rattles. 46. Place the fitting instructions in the glove box after fitment. Hayman Reese (Cequent) PO Box 4050, Dandenong South VIC 3164 Phone 1800 812 017 Email info@haymanreese.com.au Rev: A Page 13...
-
Page 14: Fitting Instructions
*Do not tow with your vehicle if the R CLIP or the SMART PIN NUT is loose or missing. Replacement parts are available from Fig 1. Smart Pin assembly your Hayman Reese Distributor. Insert Trailer Ball Mount (TBM) into towbar HITCHBOX, aligning hole in TBM SHANK with hole in HITCHBOX STEP 1 (Fig.
