2.3.3 LAN Ports
EPC-R3720 supports 2 x 10/100/1000Mbps LAN ports on the front side.
LAN1:
Pin
1
3
5
7
9
11
13
LAN2:
Pin
1
3
5
7
9
11
13
EPC-R3720 User Manual
Pin Name
LAN1_MDI0+
LAN1_MDI1+
GND
LAN1_MDI2+
LAN1_MDI3+
LAN1_ACT#
LAN1_LED_1000#
Pin Name
LAN0_MDI0+
LAN0_MDI1+
GND
LAN0_MDI2+
LAN0_MDI3+
LAN0_ACT#
LAN0_LED_1000#
9
Pin Pin Name
2 LAN1_MDI0-
4 LAN1_MDI1-
6 GND
8 LAN1_MDI2-
10 LAN1_MDI3-
12 +2.5V_VDDH1
14 LAN1_LED_10_100#
Pin Pin Name
2 LAN0_MDI0-
4 LAN0_MDI1-
6 GND
8 LAN0_MDI2-
10 LAN0_MDI3-
12 +2.5V_VDDH0
14 LAN0_LED_10_100#
