1.1 Introduction
EPC-R3720 is an ARM® Cortex®-A53 i.MX8MPlus-based secured, compact-sized, low-power
consumed Edge AI Box, best for your Edge AI Inference with Neural Network Accelerator up to
2.3 TOPS, HDR-Capable ISP of 375 MPixels/s, with a wide range of I/O extension and oriented for
industrial automation.
1.2 Product Features
1.2.1 Specification
Module Name
Processor
Memory
Ethernet
Watch Dog Timer
RTC
I/O
(Front)
I/O
(Rear)
Expansion
LED system indicators
EPC-R3720 User Manual
EPC-R3720
SOC NXP i.MX 8M Plus
Spec. Quad Core Cortex-A53 1.6 GHz
Technology LPDDR4 4000MT/s
Capacity
Onboard 6G
Flash 16GB eMMC
Chipset
NXP i.MX 8M Plus Integrated RGMII
Speed 2 x 10/100/1000Mbps
Yes
Yes
HDMI
1 x HDMI 2.0, up to 3840 x 2160 at 30Hz
2 x RJ45
LAN
USB 1 x USB2.0 Type A, 1 x USB 3.2 Gen 1 by 1 Type A
COM 2 x 2-wire RS-232 with UIO-4032/ UIO-4034
1 x RS-435, 1 x RS-232 with UIO-4030
LAN 1 x 10/100/1000 Mbps with UIO-4032
4 x 10/100/1000 Mbps with UIO-4036 (Hub)
USB 2 x USB2.0 with UIO-4032
CAN bus 1 x CAN bus 2.0 A/B with UIO-4034
GPIO 4 x DIs, 4 x DOs with UIO-4030
Mini-PCIE 1 x Full-size mini PCIe slot (USB signal only)
M.2 1 x M.2 2230 Key E slot (PCIe/USB/SDIO/UART/I2S)
SIM slot 1 x Nano SIM slot
SD socket 1 x Micro SD slot
1 x Green LED for system power
1 x Blue Programmable LED
