- Page 1 User Manual 18G, 2x1 HDMI/USB-C Wall Plate w/Auto-Switching, USB2.0 and included Receiver Wall plates Product no: VLWP-UHU-TR Document no: VL-UserManual_VLWP-UHU-TR_Rev1.4...
- Page 2 Welcome, to the VigillInk User Manual! Thank you for your purchase. At VigilLink, we prioritize the end-user experience by focusing on ease of use, ensuring our solutions are straightforward to install and program for our valued dealers. Our mission goes beyond product development;...
- Page 3 Surge protection device recommended This product includes sensitive electrical components that can be damageed by electrical spike, suges, shocks, of lightning strikes. To sfeguard and prolong the lifespan of yor equiptment, it is highly recommended to use surge protection systems. Caution The product requires the use of UTP connectors.
- Page 4 Copyright 2024 VigilLink. All right reserved. www.vigillink.com Connecting for a Smarter Future...
-
Page 5: Table Of Contents
Table of Contents: Product Description ---------------------------------------- Featured Highlights ------------------------------------------ Included Components --------------------------------------- Specifications 01. Technical ------------------------------------------------- Connections -------------------------------------------- Mechanical --------------------------------------------- Product Dimensions ----------------------------------------- Operation Controls and Functions 01. Wallplate ------------------------------------------------- 02. Receiver Panel ----------------------------------------- Application Example ----------------------------------------- Company Information and Techinical Support --------... -
Page 6: Product Description
1. Product Description The VLWP-UHU-TR wall plate features HDMI and USB-C inputs, alongside a local HDMI input on the receiver, ensuring seamless connectivity. Supporting HDMI 2.0b, HDCP 2.2, and DisplayPort 1.2a, it handles 18Gbps video bandwidth for resolutions up to 4K@60Hz 4:4:4. With HDBaseT technology, extend video up to 70m for 1080P or 40m for 4K as well as USB2.0. -
Page 7: Featured Highlights
2. Featured Highlights • HDMI and USB-C input, plus Local HDMI input on Receiver • HDMI 2.0b, HDCP 2.2, and DisplayPort 1.2a • Support for 18Gbps video bandwidth • Video resolution up to 4K@60Hz 4:4:4 • HDBaseT output can extend video transmission distance up to 230ft / 70m for 1080P or 131ft / 40m for 4K via a single Cat6/6a/7 cable •... -
Page 8: Included Components
3. Included Components Encoder or Decoder Component 18Gbps HDBaseT 70M with USB-C/HDMI & KVM Function Wall Plate Transmitter HDBaseT Receiver with Local HDMI Input and USB User Manual Connecting for a Smarter Future... -
Page 9: Specifications
4. Specifications Technical HDMI Compliance HDMI 2.0b, DisplayPort 1.2a HDCP Compliance HDCP 2.2 Video Bandwidth 18Gbps Video Resolution 4096×2160@24/25/30/50/60Hz,3840×2160@24/25/ 30/50/60Hz, 2048x1080p,1080p@23.98/24/25/29.97 /30/50/59.94/60Hz,1080i@50/59.94/60Hz, 720p@50 /59.94/60Hz, 576p, 576i, 480p, 480i Color Space RGB, YCbCr 4:4:4, YCbCr 4:2:2, YUV 4:2:0 Color Depth 8/10/12-bit HDR10, HDR10+ HDMI Audio Formats Dolby Atmos, TrueHD, Digital+, Digital;... -
Page 10: Connections
Connections Transmitter Input 1x HDMI Type A [19-pin female] 1x USB-C Output 1x HDBaseT Out [RJ45, 8-pin female] 1x USB-C (only for charging) Control 1x USB-B [Micro USB, Update port] Receiver Input 1x HDMI IN [Type A, 19-pin female] 1x HDBaseT IN [RJ45, 8-pin female] Output 1x HDMI OUT [Type A, 19-pin female] 1x AUDIO OUT [Phoenix jack]... -
Page 11: Mechanical
Mechanical Housing Metal Enclosure Color White Dimensions Wall plate: 33.3mm [W] x 65.7mm [D] x 68.7mm [H] Faceplate: 69.9mm [W] x 3mm [D] x 114.3mm [H] Receiver: 200mm [W] x 98mm [D] x 23mm [H] Weight Wall plate: 196g, Receiver: 511g Power Supply PoC (only from Receiver to Transmitter) Power Consumption... -
Page 12: Product Dimensions
5. Product Dimensions Connecting for a Smarter Future... -
Page 13: Operation Controls And Functions
6. Operation Controls and Functions 5.1 Wallplate NAME FUNCTION DESCRIPTION Power LED The power LED indicator will illuminate in green when the product is powered on and red when the product is on standby. HDMI LED The green LED will be on when the, HDMI input port is active and the HDMI signal is detected. -
Page 14: Receiver Panel
5.1.2 Receiver Panel BACK ⬇ USB 2 DC 24V HDBasT IN HDMI IN AUDIO OUT USB 1 HDMI OUT NAME FUNCTION DESCRIPTION Power LED The red LED The indicator will be on when the product is powered on. DC 24V DC 24V power supply port. - Page 15 Note: The transmitter supports automatic and manual mode for source signal switching. To initiate manual switching mode, press the SOURCE button to toggle through the HDMI, USB-C, and Local RX HDMI input source. In automatic switching mode, the most recently connected or the currently connected source device will be selected automat- ically.
-
Page 16: Application Example
7. Application Example The terms HDMI and HDMI High-Definition Multimedia interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries. Connecting for a Smarter Future... -
Page 17: Company Information And Techinical Support
8. Company Information and Techinical Support Headquarters 46 Corporate Park #130 Irvine, CA 92606 949-701-4742 info@vigillink.com For order support, please contact your Distributor or Reseller. For technical support, check with the our website www.vigillink.com or contact info@vigillink.com...
