- Page 1 User Manual 4K60 3x1 HDMI™ Switcher SWITCHER Product no: VLSW-31H20MB Document no: VL-UserManual_VLSW31H20MB_Rev1...
- Page 2 Welcome, to the VigillInk User Manual! Thank you for your purchase. At VigilLink, we prioritize the end-user experience by focusing on ease of use, ensuring our solutions are straightforward to install and program for our valued dealers. Our mission goes beyond product development;...
- Page 3 Surge protection device recommended This product includes sensitive electrical components that can be damageed by electrical spike, suges, shocks, of lightning strikes. To sfeguard and prolong the lifespan of yor equiptment, it is highly recommended to use surge protection systems.
- Page 4 Copyright 2024 VigilLink. All right reserved. www.vigillink.com Connecting for a Smarter Future...
-
Page 5: Table Of Contents
Table of Contents: Product Description ---------------------------------------- Featured Highlights ---------------------------------------- Included Components --------------------------------------- Specifications 01. Technical ------------------------------------------------- Connections -------------------------------------------- Mechanical --------------------------------------------- Operation Control and Functions Encoder Panel ---------------------------------------- Decoder Panel ---------------------------------------- IR Pin Definition --------------------------------------- Rack Mounting Instructions 01. 6U V2 Rack Mounting ------------------------------- 02. -
Page 6: Product Description
1. Product Description This is a 4K60 3x1 switcher with high performance, switching three HDMI source signals to one HDMI display. It supports any HDMI video resolution to input up to 4K@60Hz. It supports manual and automatic switching for input sources, and you can switch to auto mode quickly via AUTO bottom. -
Page 7: Featured Highlights
2. Featured Highlights • HDCP 2.2 compliant • Support video resolution up to 4K@60Hz and 18Gbps video bandwidth, as specified in HDMI 2.0 • 3D format is supported • Support HDR, HDR10, HDR10+, Dolby Vision, HLG pass- through • Support audio formats: Dolby-AC3, DTS, DTS-HD, Dolby- trueHD, LPCM 7.1, DSD •... -
Page 8: Included Components
3. Included Components HDMI Switcher Component 4K4K60 3x1 HDMI Switcher IR Remote IR Receiver Cable (1.5m) 5V/1A Multinational Power Supply Power Adapter Machine Screw (K3*4) Mounting ear User manual Connecting for a Smarter Future... -
Page 9: Specifications
4. Specifications Technical HDMI Compliance HDMI 2.0b HDCP Compliance HDCP 2.2 Video Bandwidth 18Gbps Video Resolution Up to 4K2K@60Hz Color Depth 8/10/12-bit Color Space RGB, YCbCr_4:4:4, YCbCr_4:2:2, YCbCr_4:2:0 HDR, HDR10, HDR10+, Dolby Vision, HLG Audio Formats HDMI input/output: LPCM, Dolby Digital/Plus/EX, Dolby True HD, Dolby Atmos, DTS, DSD DTS-EX, DTS-96/24, DTS High Res, DTS-HD Master Audio, DTS:X... -
Page 10: Connections
4. Con’t - Specifications Connections Encoder Input 3 × HDMI IN [Type A, 19-pin female] Output 1 × HDMI OUT [Type A, 19-pin female] 1 × L/R [3.5mm stereo mini-jack] Control 1 × IR EXT [3.5mm stereo mini-jack] Connecting for a Smarter Future... -
Page 11: Mechanical
4. Con’t - Specifications Mechanical Housing Iron Enclosure Color Black Dimensions 145mm (7.71 inches)[W] × 68mm (2.68inches) [D] × 18mm 0.71 (inches)[H] Weight 251g or 0.55lbs Power Supply Input: AC100 - 240V 50/60Hz, Output: DC 5V/1A (US/EU standards, CE/FCC/UL certified) Power Cosumption 1.9W (Max) Operating Temperature... - Page 12 4. Con’t - Specifications Recommended HDMI Cable Video 4K60 1080P Resolution HDMI Cable 5m/16ft 10m/33ft Length (HDMI IN/OUT) The use of “Premium High Speed HDMI” cable is highly recommended Connecting for a Smarter Future...
-
Page 13: Operation Control And Functions
5. OPERATIAON CONTROLS AND FUNCTIONS FRONT IN 1 IN 3 AUTO IN 2 IN 2 IN 1 IN 3 AUTO EDID NAME FUNCTION DESCRIPTION IR Window IR input signal receiving window. POWER LED The power LED lights in green when the device is working, and red when the device is in standby. - Page 14 Back L/R OUT IN 1 IN 2 IN 3 DC 5V IR EXT NAME FUNCTION DESCRIPTION IN port HDMI signal input port, connected to HDMI source (1~3) device such as DVD or PS5 via HDMI cable. OUT port HDMI signal output port, connected to HDMI display device such as TV or Monitor via HDMI cable.
-
Page 15: Ir Pin Definition
6. IR Pin Defintion... -
Page 16: Application Example
10. Application Example 8K TV DVD or Blu-ray Player Power Supply Back L/R OUT IN 1 IN 2 IN 3 DC 5V IR EXT AudioAmplifier IR Receiver Connecting for a Smarter Future... - Page 17 The terms HDMI and HDMI High-Definition Multimedia interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.
- Page 18 Headquarters 46 Corporate Park #130 Irvine, CA 92606 949-701-4742 info@vigillink.com For order support, please contact your Distributor or Reseller. For technical support, check with the our website www.vigillink.com or contact info@vigillink.com Connecting for a Smarter Future...
