6.5.1. Replacement of the quick-release tines
In the machines which are equipped with quick-release tines, take the following steps:

Insert tine (Ref. 1)

Insert the pin (Ref. 2)

Block the whole with the spring pin (Ref. 3)
Correct assembly of the tines:
DJ-DP
DTEK "PLUS"
37 Strictly confidential information - All rights to the contents of this document are reserved. It is forbidden to copy, use, distribute, even partially or
otherwise disclose such information, unless expressly authorised by "ALPEGO S.p.a.". Violations will be prosecuted in accordance with the law.
Codice: Q00A00017 Rev. 23_11/2022
DTEK "BASE"
DTEK Rapido
DMAX Rapido
DMAX
