4. INSTALLATION
4.1. Lifting of the machine
The lifting and transport operations have to be carried on with means suitable for the weight of the machine
and by personnel trained for this kind of maneuver.
4.2. Lifting of the rotodent
If the machine is supplied closed, connect it only as indicated in the figure to the two
suitable side hooks, during this operation the machine shall not be lifted for more than
200 mm from the ground.
Do not connect the machine to the central hook if it is closed. This may cause the
overturning of the machine itself in that its barycentre is placed above the
connection point.
If the machine is supplied open, connect it to the central hook, as indicated in the figure,
and perform the transportation, during this operation the machine shall not be lifted for
more than 200 mm from the ground.
4.3. Machine with disassembled roller
If the machine is supplied with the roller disassembled, it is necessary to
perform the assembling of the same. Pay attention to the instability of the
machine without the roller.
Keeping the machine lifted with proper means apply it to the three points of the
tractor locking the piston pins by means of the suitable bolts.
Verify that everything is perfectly connected and place the machine onto the ground,
carefully.
Connect the roller as indicated in the figure by means of a proper lifting mean and by
keeping it stable without lifting it from the floor, proceeds as indicated in paragraph 4.4
