HOT BANQUET TROLLEY CONTENTS GENERAL INFORMATION Page PRODUCT DESCRIPTION Page TECHNICAL INFORMATION Page TRANSPORTATION Page UNPACKING Page INSTALLATION Page SAFETY INSTRUCTIONS Page OPERATION CLEANING & MAINTENANCE Page TROUBLESHOOTING Page SPARE PART LIST- EXPLODING DRAWING Page ELECTRIC CIRCUIT SCHEMA Page... -
Page 2: Ageneral Information
HOT BANQUET TROLLEY GENERAL INFORMATION Before installing the appliance, read operation and maintenance instructions carefully.Wrong installation and part changing may damage the product or may cause injury on people.These are not in our company’s responsibility to damage the appliance intentionally,negligence,detriments because of disobeying instructions and regulations,wrong connections.Unauthorized intervention to appliance invalidates the warranty. -
Page 3: A1 Product Description
HOT BANQUET TROLLEY PRODUCT DESCRIPTION *The Professional Hot Banquet Trolley,that provides high efficiency has been designed to be used in industrial kitchens. Packaging Product Code Dimensions (mm) Weight (kg) Dimensions (mm) EMP.BQ1 720x885x1810 720x900x1925 EMP.BQ2 1360x885x1810 1400x900x1925 EMP.BQ3 720x885x1220 720x900x1370 EMP.BQ4... -
Page 4: A3 Transportation
HOT BANQUET TROLLEY TRANSPORTATION *This appliance can not be moved by hand from area to area.It must be moved on pallet with forklift truck. UNPACKING *Please unpack the package according to the security codes and ordinances of current country and get rid from the pack.Parts which contacts with food are produced by stainless steel.All plastic parts are marked by material’s symbol. -
Page 5: Csafety Instructions
HOT BANQUET TROLLEY SAFETY INSTRUCTIONS *Do not use the appliance in insufficient lighted place. *Do not touch the moving attachments while the appliance operates. *Do not install the appliance in the presence of flammable or explosive materials. *Do not operate the appliance when the machine is empty. *Do not load so less or more than appliance’s capacity. -
Page 6: Doperation P Age
HOT BANQUET TROLLEY OPERATION *Control Panel; 1 : Setup Menu 2 : ON/OFF Button 3 : Down Arrow Button 4 : Up Arrow Button *Operating; Before starting any operation,be sure that inside of the appliance is clean and the wheels of the appliance are locked. -
Page 7: Ecleaning & Maintenance
HOT BANQUET TROLLEY CLEANING & MAINTENANCE CLEANING AND MAINTENANCE AFTER EVERY USE Be sure that the trolley is cold (less than 40ºC) before the cleaning. Always turn off the appliance and disconnect from the power supply before cleaning. ... -
Page 8: Ftroubleshooting
HOT BANQUET TROLLEY TROUBLESHOOTING Check if the appliance is plugged in. THE APPLIANCE DOESN’T OPERATE Check the electrical connections and voltage. Check the heater resistance and thermocouple. THE APPLIANCE DOESN’T HEAT Fan may have error.In this situation inform the service. If the door has error,or door wick is broken,the appliance doesn’t heat. -
Page 9: Gspare Part List-Exploding Drawing
HOT BANQUET TROLLEY SPARE PART LIST-EXPLODING DRAWING EMP.BQ1... - Page 10 HOT BANQUET TROLLEY SPARE PART LIST-EXPLODING DRAWING PRODUCT CODE: EMP.BQ1 PRODUCT NAME P.CODE CHASSIS M.ENJ-ERK-PLS-002 PIPE M.ENJ-ERK-PLS-024 M.AKS-TKR-KS-002 WHEEL WITHOUT BRAKE M.AKS-TKR-KFS-002 WHEEL WITH BRAKE YTL-ERK.BQ-KS-0001 FIXING SCREW YTL-ERK.BQ-KS-0002 STABILIZER M.ELK-EDM-DGT-011 CENSOR DRAWER ARA-ERK.BQ-0028 M.ENJ-ERK-PLS-023 DRAWER HANDLE PLASTIC M.ELK-HVL-KFN-002 M.ENJ-ERK-PLS-103 DIGITAL PLASTIC M.AKS-ETK-LKS-14*6...
- Page 11 HOT BANQUET TROLLEY SPARE PART LIST-EXPLODING DRAWING EMP.BQ2...
- Page 12 HOT BANQUET TROLLEY SPARE PART LIST-EXPLODING DRAWING PRODUCT CODE: EMP.BQ2 PRODUCT NAME P.CODE YBR-ERK.BQ-KS-0001 HANDLE PIPE M.ENJ-ERK-PLS-019 HANDLE SIDE PART M.AKS-TKR-KFS-002 WHEEL WITH BRAKE M.ENJ-ERK-PLS-002 PIPE M.ENJ-ERK-PLS-024 M.AKS-TKR-KS-002 WHEEL WITHOUT BRAKE ARA-ERK.BQ-0034 RIGHT COVER YTL-ERK.BQ-KS-0001 FIXING SCREW STABILIZER YTL-ERK.BQ-KS-0002 M.ELK-EDM-DGT-011 CENSOR ARA-ERK.BQ-0032 DRAWER...
- Page 13 HOT BANQUET TROLLEY SPARE PART LIST-EXPLODING DRAWING EMP.BQ3...
- Page 14 HOT BANQUET TROLLEY SPARE PART LIST-EXPLODING DRAWING PRODUCT CODE: EMP.BQ3 PRODUCT NAME P.CODE CHASSIS M.ENJ-ERK-PLS-002 PIPE M.ENJ-ERK-PLS-024 M.AKS-TKR-KS-002 WHEEL WITHOUT BRAKE M.AKS-TKR-KFS-002 WHEEL WITH BRAKE M.MTS-ERK-007 1/2 TUB M.ELK-RKR-BRU-ERK-007 RESISTANCE M.ELK-HVL-KFN-005 YTL-ERK.BQ-KS-0001 FIXING SCREW YTL-ERK.BQ-KS-0002 STABILIZER M.ELK-EDM-DGT-011 CENSOR ARA-ERK.BQ-0028 DRAWER DRAWER HANDLE PLASTIC M.ENJ-ERK-PLS-023 M.ELK-HVL-KFN-002...
- Page 15 HOT BANQUET TROLLEY SPARE PART LIST-EXPLODING DRAWING EMP.BQ4...
- Page 16 HOT BANQUET TROLLEY SPARE PART LIST-EXPLODING DRAWING PRODUCT CODE: EMP.BQ4 PRODUCT NAME P.CODE CHASSIS M.ENJ-ERK-PLS-002 PIPE M.ENJ-ERK-PLS-024 M.MTS-ERK-007 1/2 TUB M.ELK-RKR-BRU-ERK-007 RESISTANCE M.AKS-TKR-KS-002 WHEEL WITHOUT BRAKE M.AKS-TKR-KFS-002 WHEEL WITH BRAKE M.ELK-HVL-KFN-005 YTL-ERK.BQ-KS-0001 FIXING SCREW YTL-ERK.BQ-KS-0002 STABILIZER M.ELK-EDM-DGT-011 CENSOR ARA-ERK.BQ-0031 DRAWER M.ENJ-ERK-PLS-023 DRAWER HANDLE PLASTIC M.ELK-HVL-KFN-002...
-
Page 17: Helectric Circuit Schema
HOT BANQUET TROLLEY ELECTRIC CIRCUIT SCHEMA EMP.BQ1-BQ2-BQ3-BQ4... - Page 18 HOT BANQUET TROLLEY...
