DOUGHNUT MACHINES

Kasap Tip Dik Buzdolapları

CONTENTS

GENERAL INFORMATION

PRODUCT DESCRIPTION

TECHNICAL INFORMATION

TRANSPORTATION

UNPACKING

INSTALLATION

SAFETY INSTRUCTIONS

OPERATION

CLEANING & MAINTENANCE

TROUBLESHOOTING

SPARE PART LIST- EXPLODING DRAWING

ELECTRIC CIRCUIT SCHEMA

Page

Need help?

Do you have a question about the EMP.LK.001 and is the answer not in the manual?

Questions and answers

Summary of Contents for EMPERO EMP.LK.001

Page 1 DOUGHNUT MACHINES Kasap Tip Dik Buzdolapları CONTENTS GENERAL INFORMATION Page PRODUCT DESCRIPTION Page TECHNICAL INFORMATION Page TRANSPORTATION Page UNPACKING Page INSTALLATION Page SAFETY INSTRUCTIONS Page OPERATION Page CLEANING & MAINTENANCE Page TROUBLESHOOTING Page SPARE PART LIST- EXPLODING DRAWING Page ELECTRIC CIRCUIT SCHEMA Page...
Page 2 PRODUCT DESCRIPTION *The Professional Doughnut Machines,that provides high efficiency has been designed to be used in industrial kitchens. Weight Packaging Product Code Dimensions (mm) (kg) Dimensions (mm) EMP.LK.001 830x410x590 920x570x550 EMP.LK.002 1400x700x850/1320 1370x770x1450 EMP.LK.003 1400x700x850/1320 1370x770x1450 EMP.LK.004...
Page 3 DOUGHNUT MACHINES Kasap Tip Dik Buzdolapları TECHNICAL INFORMATION EMP.LK. EMP.LK. EMP.LK. EMP.LK.003 EMP.LK. EMP.LK. CODE (Electrical (LPG-NG (LPG-NG (Electric Table) Table) Table) Table) Cooking Tank 25+25 Capacity (kg) Dough Tank Capacity(kg) Product Saray : 300 Doughnut Capacity İzmir : 48 Doughnut (piece./min.) 0,752...
Page 4 DOUGHNUT MACHINES TRANSPORTATION Kasap Tip Dik Buzdolapları *This appliance can not be moved by hand from area to area.It must be moved on pallet with forklift truck. UNPACKING *Please unpack the package according to the security codes and ordinances of current country and get rid from the pack.Parts which contacts with food are produced by stainless steel.All plastic parts are marked by material’s symbol.
Page 5 DOUGHNUT MACHINES Kasap Tip Dik Buzdolapları SAFETY INSTRUCTIONS *Do not use the appliance in insufficient lighted place. *Do not touch the moving attachments while the appliance operates. *Do not install the appliance in the presence of flammable or explosive materials. ...
Page 6 *Control Panel; A : Thermal Indıcator B : Thermostat C : On/Off Switch A : Switch ON B : Switch OFF EMP.LK.001 EMP.LK.003 *Operating; • Clean the cooking tank and dough tank before operating the appliance. • At gaseous benches,turn on gas valves and fire the gas.At electrical benches plug in and adjust the heat with thermostat degree.
Page 7 DOUGHNUT MACHINES Kasap Tip Dik Buzdolapları CLEANING & MAINTENANCE ➢ CLEANING AND MAINTENANCE AFTER EVERY USE • Lubricate the dough tank after every use. • Always turn off the appliance and disconnect from the power supply while cleaning electrical bench. •...
Page 8 DOUGHNUT MACHINES TROUBLESHOOTING Kasap Tip Dik Buzdolapları Check if the appliance is plugged in. Check the electrical connections and THE APPLIANCE DOESN’T OPERATE voltage. Check gas connections. If the piston crashes the tank,place the perforated plate on to the piston and THE APPLIANCE IS NOISY compress the yellow screw.
Page 9 DOUGHNUT MACHINES Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING EMP.LK.001...
Page 10 DOUGHNUT MACHINES SPARE PART LIST-EXPLODING DRAWING PRODUCT CODE : EMP.LK.001 Kasap Tip Dik Buzdolapları PRODUCT NAME P.CODE PUSHER ELEMENT YTL-ERS.LK-KS-0003 PIPE BOTTOM NUT YTL-ERS.LK-KS-0005 BOILER (35*21) M.MTS-ERS-LK-001 YTL-ERS.LK-KS-0017 SHORT MILES UPPER NUT YTL-ERS.LK-KS-0015 YTL-ERS.LK-KS-0014 MOVEMENT SIGN SHAFT CONNECTION YDK-ERS.LK-CN-0011 YSC-ERS.LK-LZ-0013...
Page 11 DOUGHNUT MACHINES Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING EMP.LK.002...
Page 12 DOUGHNUT MACHINES SPARE PART LIST-EXPLODING DRAWING Kasap Tip Dik Buzdolapları PRODUCT CODE: EMP.LK.002 PRODUCT NAME P.CODE WHEEL WITH BRAKE M.AKS-TKR-PSF-003 CHASSIS ERK.M.ELK-SLT-ANL-003 WHEEL WITHOUT BRAKE M.AKS-TKR-PS-002 THERMOCOUPLE ERK.M.GAZ-TRL-005 1/2 YELLOW NIPPLE M.MEK-TES-BAG-009 YELLOW ELBOW ERK.M.MEK-TES-SRI-032 INJECTOR ERK.M.GAZ-ENJ-LPG-011 HOSE END ERK.M.MEK-TES-SRI-031 BUTTON ERK.M.AKS-DGM-EMP-024 GAS VALVE...
Page 13 DOUGHNUT MACHINES Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING EMP.LK.003...
Page 14 DOUGHNUT MACHINES SPARE PART LIST-EXPLODING DRAWING PRODUCT CODE: EMP.LK.003 Kasap Tip Dik Buzdolapları PRODUCT NAME P.CODE WHEEL WITH BRAKE M.AKS-TKR-PSF-003 CHASSIS WHEEL WITHOUT BRAKE M.AKS-TKR-PS-002 BUTTON ERK.M.AKS-DGM-EMP-024 BUTTON FRAME M.AKS-DGM-EMP-013 TICKET M.AKS-ETK-FLY-002 ERK.M.ELK-SLT-ANL-003 THERMOSTAT ERK.M.ELK-MEK-LMT-015 LAMP ERK.M.ELK-LMB-SNY-002 POWER SOURCE M.ELK-MUH-006 THERMOSTAT ERK.M.ELK-MEK-TRM1-022 RESISTANCE...
Page 15 DOUGHNUT MACHINES Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING EMP.LK.006...
Page 16 DOUGHNUT MACHINES SPARE PART LIST-EXPLODING DRAWING Kasap Tip Dik Buzdolapları PRODUCT CODE: EMP.LK.006 PRODUCT NAME P.CODE YELLOW ELBOW ERK.M.MEK-TES-SRI-032 FOOT ERK.M.AKS-AYK-INX-001 GAS TANK ERK.M.GAZ-BRL-DKM-002 ERK.M.ELK-SLT-ANL-003 BUTTON ERK.M.AKS-DGM-EMP-024 GAS VALVE ERK.M.GAZ-VNA-ECA-008 THERMOCOUPLE ERK.M.GAZ-TRL-005 HOSE END ERK.M.MEK-TES-SRI-031 1/2 YELLOW NIPPLE M.MEK-TES-BAG-009 1/2 GAS FLEX M.GAZ -TES-SPR-001 GAS FLEX ERK.M.GAZ-TES-SPR-020...
Page 17 DOUGHNUT MACHINES Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING EMP.LK.007...
Page 18 DOUGHNUT MACHINES SPARE PART LIST-EXPLODING DRAWING Kasap Tip Dik Buzdolapları PRODUCT CODE: EMP.LK.007 PRODUCT NAME P.CODE WHEEL WITH BRAKE M.AKS-TKR-PSF-003 CHASSIS WHEEL WITHOUT BRAKE M.AKS-TKR-PS-002 THERMOSTAT ERK.M.ELK-MEK-LMT-015 ERK.M.ELK-SLT-ANL-003 BUTTON M.AKS-DGM-EMP-014 BUTTON FRAME M.AKS-DGM-EMP-013 LAMP ERK.M.ELK-LMB-SNY-002 POWER SOURCE M.ELK-MUH-006 RESISTANCE M.ELK-RZS-BRU-LK-001 WATER DISCHARGE YTL-ERK.BEH-KS-0001 M.MTS-ERK-050...
Page 19 DOUGHNUT MACHINES Kasap Tip Dik Buzdolapları ELECTRIC CIRCUIT SCHEMA LT - LIMIT CONTROL THERMOSTAT T1 - THERMOSTAT P1 - ON/OFF SWITCH C1 - CONTACTOR R1/R2/R3 - RESISTANCE G1 - POWER SOURCE EMP.LK.003...
Page 20 DOUGHNUT MACHINES ELECTRIC CIRCUIT SCHEMA Kasap Tip Dik Buzdolapları EMP.LK.001...
