Page 1: Table Of Contents
GLASS DOOR REFRIGERATED COUNTERS Kasap Tip Dik Buzdolapları CONTENTS GENERAL INFORMATION Page PRODUCT DESCRIPTION Page TECHNICAL INFORMATION Page TRANSPORTATION Page UNPACKING Page INSTALLATION Page SAFETY INSTRUCTIONS Page OPERATION Page CLEANING & MAINTENANCE Page TROUBLESHOOTING Page SPARE PART LIST- EXPLODING DRAWING Page ELECTRIC CIRCUIT SCHEMA Page... -
Page 2: Ageneral Information
GLASS DOOR REFRIGERATED COUNTERS Kasap Tip Dik Buzdolapları GENERAL INFORMATION Before installing the appliance, read operation and maintenance instructions carefully.Wrong installation and part changing may damage the product or may cause injury on people.These are not in our company’s responsibility to damage the appliance intentionally,negligence,detriments because of disobeying instructions and regulations,wrong connections.Unauthorized intervention to appliance invalidates the warranty. -
Page 3: A1 Product Description
Kasap Tip Dik Buzdolapları PRODUCT DESCRIPTION *The Professional Glass Door Refrigerated Counters ,that provides high efficiency has been designed to be used in industrial kitchen. Packaging Product Code Dimensions (mm) Weight (kg) Dimensions (mm) EMP.150.60.03 1500x600x850 1540x630x970 EMP.150.70.03 1500x700x850 1540x730x970 EMP.200.60.03 2000x600x850 2040x630x970 EMP.200.70.03... -
Page 4: A3 Transportation
GLASS DOOR REFRIGERATED COUNTERS TRANSPORTATION Kasap Tip Dik Buzdolapları *This appliance can not be moved by hand from area to area.It must be moved on pallet with forklift truck. UNPACKING *Please unpack the package according to the security codes and ordinances of current country and get rid from the pack.Parts which contacts with food are produced by stainless steel.All plastic parts are marked by material’s symbol. -
Page 5: Csafety Instructions
GLASS DOOR REFRIGERATED COUNTERS Kasap Tip Dik Buzdolapları SAFETY INSTRUCTIONS *Do not use the appliance in insufficient lighted place. *Do not touch the moving attachments while the appliance operates. *Do not install the appliance in the presence of flammable or explosive materials. ... -
Page 6: Doperation
GLASS DOOR REFRIGERATED COUNTERS OPERATION Kasap Tip Dik Buzdolapları *Control Panel; A : Degree increase B : Degree reduce C : Indicator ON/OFF D : SET approval button E: ON position F: OFF position G: Lamp ON H: Lamp OFF *Operating;... -
Page 7: Ecleaning & Maintenance
GLASS DOOR REFRIGERATED COUNTERS Kasap Tip Dik Buzdolapları CLEANING & MAINTENANCE CLEANING AND MAINTENANCE AFTER EVERY USE Always turn off the appliance and disconnect from the power supply before cleaning. Clean the inner surfaces and shelves with moist cloth and then dry after every evacuation of material. -
Page 8: Ftroubleshooting
GLASS DOOR REFRIGERATED COUNTERS TROUBLESHOOTING Kasap Tip Dik Buzdolapları Check if the appliance is plugged in. Check the electrical connections and THE APPLIANCE DOESN’T OPERATE voltage. Check if the fuse is on or off. Check the motor. THE APPLIANCE IS NOISY If the connection pipes contact with compressor,remove it. -
Page 9: Gspare Part List- Exploding Drawing
GLASS DOOR REFRIGERATED COUNTERS Kasap Tip Dik Buzdolapları SPARE PART LIST- EXPLODING DRAWINGS PRODUCT CODE : EMP.150.60.03 PRODUCT NAME P. CODE TOP TABLE YSC-ERK.1560-LZ-0030 UPPER PAN SHEET YSC-ERK.1560-PN-0177 CURTAIN SHEET YSC-ERK.1560-LZ-0063 SHELF STRUT ERK.M.MUH-002 SHELF NAIL M.RAF-ERK-002 42*49 SHELF M.RAF-ERK-001 GASKET ( 590 - 472) M.CNT-ERK-001... - Page 10 GLASS DOOR REFRIGERATED COUNTERS HINGE BOTTOM PLASTIC LEFT M.ENJ-ERK-PLS-109 HAND PLASTIC BOTTOM M.PLS-ERK-030 HAND PLASTIC TOP M.PLS-ERK-029 Kasap Tip Dik Buzdolapları GLASS COVER RIGHT ARA-1560-CAMAKB-002 HINGE TOP PLASTIC RIGHT M.ENJ-ERK-PLS-108 HINGE BOTTOM PLASTIC RIGHT M.ENJ-ERK-PLS-107 HINGE M.AKS-MNT-SC-007 LED LAMP M.ELK-LMB-ARM-006 CHASSIS UPPER RIGHT HINGE SHEET M.AKS-MNT-SC-001...
- Page 11 GLASS DOOR REFRIGERATED COUNTERS Kasap Tip Dik Buzdolapları SPARE PART LIST- EXPLODING DRAWINGS PRODUCT CODE : EMP.150.70.03 PRODUCT NAME P. CODE TOP TABLE SHEET YSC-ERK.1570-LZ-0040 UPPER PAN SHEET YSC-ERK.1570-PN-0291 CURTAIN SHEET YSC-ERK.1560-LZ-0063 SHELF STRUT ERK.M.MUH-002 SHELF NAIL M.RAF-ERK-002 49*52 SHELF M.RAF-ERK-003 LED LAMP M.ELK-LMB-ARM-006...
- Page 12 GLASS DOOR REFRIGERATED COUNTERS GLASS COVER LEFT ARA-1560-CAMAKB-001 HINGE TOP PLASTIC LEFT M.ENJ-ERK-PLS-110 HINGE BOTTOM PLASTIC LEFT M.ENJ-ERK-PLS-109 Kasap Tip Dik Buzdolapları HAND PLASTIC BOTTOM M.PLS-ERK-030 HAND PLASTIC TOP M.PLS-ERK-029 GLASS COVER RIGHT ARA-1560-CAMAKB-002 HINGE TOP PLASTIC RIGHT M.ENJ-ERK-PLS-108 HINGE BOTTOM PLASTIC RIGHT M.ENJ-ERK-PLS-107 HINGE M.AKS-MNT-SC-007...
- Page 13 GLASS DOOR REFRIGERATED COUNTERS Kasap Tip Dik Buzdolapları SPARE PART LIST- EXPLODING DRAWINGS PRODUCT CODE : EMP.200.60.03 PRODUCT NAME P. CODE TOP TABLE YSC-ERK.2060-LZ-0007 UPPER PAN SHEET YSC-ERK.2060-PN-0093 CURTAIN SHEET YSC-ERK.2060-LZ-0019 SHELF STRUT ERK.M.MUH-002 SHELF NAIL M.RAF-ERK-002 42*49 SHELF M.RAF-ERK-001 LED LAMP M.ELK-LMB-ARM-006 CHASSIS...
- Page 14 GLASS DOOR REFRIGERATED COUNTERS HINGE TOP PLASTIC LEFT M.ENJ-ERK-PLS-110 GLASS COVER LEFT ARA-1560-CAMAKB-001 HINGE BOTTOM PLASTIC LEFT M.ENJ-ERK-PLS-109 Kasap Tip Dik Buzdolapları HAND PLASTIC BOTTOM M.PLS-ERK-030 HAND PLASTIC TOP M.PLS-ERK-029 GLASS COVER RIGHT ARA-1560-CAMAKB-002 HINGE TOP PLASTIC RIGHT M.ENJ-ERK-PLS-108 HINGE BOTTOM PLASTIC RIGHT M.ENJ-ERK-PLS-107 HINGE M.AKS-MNT-SC-007...
-
Page 15: Product Name
GLASS DOOR REFRIGERATED COUNTERS Kasap Tip Dik Buzdolapları SPARE PART LIST- EXPLODING DRAWINGS PRODUCT CODE : EMP.200.70.03 PRODUCT NAME P. CODE TOP TABLE SHEET YSC-ERK.2070-LZ-0026 UPPER PAN SHEET YSC-ERK.2070-PN-0129 CURTAIN SHEET YSC-ERK.2060-LZ-0019 SHELF STRUT ERK.M.MUH-002 SHELF NAIL M.RAF-ERK-002 49*52 SHELF M.RAF-ERK-003 GASKET ( 590 - 472) M.CNT-ERK-001... - Page 16 GLASS DOOR REFRIGERATED COUNTERS HINGE BOTTOM PLASTIC LEFT M.ENJ-ERK-PLS-109 HAND PLASTIC BOTTOM M.PLS-ERK-030 HAND PLASTIC TOP M.PLS-ERK-029 Kasap Tip Dik Buzdolapları GLASS COVER RIGHT ARA-1560-CAMAKB-002 HINGE TOP PLASTIC RIGHT M.ENJ-ERK-PLS-108 HINGE BOTTOM PLASTIC RIGHT M.ENJ-ERK-PLS-107 HINGE M.AKS-MNT-SC-007 LED LAMP M.ELK-LMB-ARM-006 CHASSIS UPPER RIGHT HINGE SHEET M.AKS-MNT-SC-001...
- Page 17 GLASS DOOR REFRIGERATED COUNTERS Kasap Tip Dik Buzdolapları SPARE PART LIST- EXPLODING DRAWINGS PRODUCT CODE : EMP.255.60.03 PRODUCT NAME P. CODE TOP TABLE YSC-ERK.2560-LZ-0017 UPPER PAN SHEET YSC-ERK.2560-PN-0087 CURTAIN SHEET YSC-ERK.2560-LZ-0028 SHELF STRUT ERK.M.MUH-002 SHELF NAIL M.RAF-ERK-002 42*49 SHELF M.RAF-ERK-001 LED LAMP M.ELK-LMB-ARM-006 CHASSIS...
- Page 18 GLASS DOOR REFRIGERATED COUNTERS GLASS COVER LEFT ARA-1560-CAMAKB-001 HINGE TOP PLASTIC LEFT M.ENJ-ERK-PLS-110 HINGE BOTTOM PLASTIC LEFT M.ENJ-ERK-PLS-109 Kasap Tip Dik Buzdolapları HAND PLASTIC BOTTOM M.PLS-ERK-030 HAND PLASTIC TOP M.PLS-ERK-029 GLASS COVER RIGHT ARA-1560-CAMAKB-002 HINGE TOP PLASTIC RIGHT M.ENJ-ERK-PLS-108 HINGE BOTTOM PLASTIC RIGHT M.ENJ-ERK-PLS-107 HINGE M.AKS-MNT-SC-007...
- Page 19 GLASS DOOR REFRIGERATED COUNTERS Kasap Tip Dik Buzdolapları SPARE PART LIST- EXPLODING DRAWINGS PRODUCT CODE : EMP.255.70.03 PRODUCT NAME P. CODE TOP TABLE SHEET YSC-ERK.2570-LZ-0007 UPPER PAN SHEET YSC-ERK.2570-PN-0042 CURTAIN SHEET YSC-ERK.2560-LZ-0028 SHELF STRUT ERK.M.MUH-002 SHELF NAIL M.RAF-ERK-002 49*52 SHELF M.RAF-ERK-003 LED LAMP M.ELK-LMB-ARM-006...
- Page 20 GLASS DOOR REFRIGERATED COUNTERS GLASS COVER LEFT ARA-1560-CAMAKB-001 HINGE TOP PLASTIC LEFT M.ENJ-ERK-PLS-110 HINGE BOTTOM PLASTIC LEFT M.ENJ-ERK-PLS-109 Kasap Tip Dik Buzdolapları HAND PLASTIC BOTTOM M.PLS-ERK-030 HAND PLASTIC TOP M.PLS-ERK-029 GLASS COVER RIGHT ARA-1560-CAMAKB-002 HINGE TOP PLASTIC RIGHT M.ENJ-ERK-PLS-108 HINGE BOTTOM PLASTIC RIGHT M.ENJ-ERK-PLS-107 HINGE M.AKS-MNT-SC-007...
-
Page 21: Helectric Circuit Schema
GLASS DOOR REFRIGERATED COUNTERS Kasap Tip Dik Buzdolapları ELECTRIC CIRCUIT SCHEMA Compressor Double Inner Digital Inner Terminal lighted 0- lighting Indicator condenser cooling fan 1 switch lamp...
