Page 1: Table Of Contents
PLANETARY MIXERS ( SPEED CONTROL ) Kasap Tip Dik Buzdolapları CONTENTS GENERAL INFORMATION Page PRODUCT DESCRIPTION Page TECHNICAL INFORMATION Page TRANSPORTATION Page UNPACKING Page INSTALLATION Page SAFETY INSTRUCTIONS Page OPERATION Page CLEANİNG & MAINTENANCE Page TROUBLESHOOTING Page SPARE PART LIST- EXPLODING DRAWING Page ELECTRIC CIRCUIT SCHEMA Page... -
Page 2: Ageneral Information
PLANETARY MIXERS ( SPEED CONTROL ) Kasap Tip Dik Buzdolapları GENERAL INFORMATION Before installing the appliance, read operation and maintenance instructions carefully.Wrong installation and part changing may damage the product or may cause injury on people.These are not in our company’s responsibility to damage the appliance intentionally,negligence,detriments because of disobeying instructions and regulations,wrong connections.Unauthorized intervention to appliance invalidates the warranty. -
Page 3: A1 Product Description
Kasap Tip Dik Buzdolapları PRODUCT DESCRIPTION *The Professional Planetary Mixer, that provides high efficiency has been designed to be used in industrial kitchens. Packaging Product Code Dimensions (mm) Weight (kg) Dimensions (mm) MK.07 680x860x1380 740x880x1370 MK.03 680x880x1400 740x920x1410 MK.05 680x905x1425 750x940x1430 EMP.10... -
Page 4: A3 Transportation
PLANETARY MIXERS ( SPEED CONTROL ) TRANSPORTATION *This appliance can not be moved by hand from area to area.It must be moved on pallet with Kasap Tip Dik Buzdolapları forklift truck. UNPACKING *Please unpack the package according to the security codes and ordinances of current country and get rid from the pack.Parts which contacts with food are produced by stainless steel.All plastic parts are marked by material’s symbol. -
Page 5: Csafety Instructions
PLANETARY MIXERS ( SPEED CONTROL ) Kasap Tip Dik Buzdolapları SAFETY INSTRUCTIONS *Do not use the appliance in insufficient lighted place. *Do not touch the moving attachments while the appliance operates. *Do not install the appliance in the presence of flammable or explosive materials. ... -
Page 6: Doperation
PLANETARY MIXERS ( SPEED CONTROL ) OPERATION Kasap Tip Dik Buzdolapları *Control Panel; A : Timer setting B : Start C : Stop D : Speed Setting *Operating; • Before operating,clean the bowl with a wet cloth and dry. • Insert the desired attachment,push up to the right and lock it into the place. -
Page 7: Ecleaning & Maintenance
PLANETARY MIXERS ( SPEED CONTROL ) Kasap Tip Dik Buzdolapları CLEANING & MAINTENANCE ➢ CLEANING AND MAINTENANCE AFTER EVERY USE • Clean all mixer attachments after every mixing and kneading process.Otherwise the remains in these parts may make appliance’s operating difficult. •... -
Page 8: Ftroubleshooting
PLANETARY MIXERS ( SPEED CONTROL ) TROUBLESHOOTING Kasap Tip Dik Buzdolapları Check if the appliance is plugged in. Check the electrical connections and THE APPLIANCE DOESN’T OPERATE voltage. Pull handle and bowl up. Check the position of safety guard. Check the distance between bowl and attachment and adjust them.The THE APPLIANCE IS NOISY attachment should not touch the bowl. -
Page 9: Gspare Part List-Exploding Drawing
PLANETARY MIXERS ( SPEED CONTROL ) Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING MK.03... - Page 10 PLANETARY MIXERS ( SPEED CONTROL ) SPARE PART LIST-EXPLODING DRAWING Kasap Tip Dik Buzdolapları PRODUCT CODE : MK.03 PRODUCT NAME P.CODE BUTTON SOCKET M.AKS-DGM-MUH-009 GREEN LIGHTED BUTTON ERS.M.ELK-SLT-BTL-011 RED BUTTON (MOMENTARY) M.ELK-SLT-BTL-010 BUTTON M.ENJ-ERS-PLS-PS-018 PANEL SHEET YSC-ERS.SH-LZ-0074 POTENTIOMETER M.ELK-PMT-4,7 TIME CLOCK M.ELK-MEK-MTM-004 TOP COVER M.ENJ-ERS-PLS-MK-003...
- Page 11 PLANETARY MIXERS ( SPEED CONTROL ) Kasap Tip Dik Buzdolapları STEERING HANDLE YTL-ERS.MK-KS-0066 BALL CONNECTION M.MUH-049 LIFTING ARM YTL-ERS.MK-KS-0075 BEARING ( UCFL 204G ) M.RLM-YTK-002 MAGNETIC SENSOR M.ELK-SWC-KTG-001 SHOCK ABSORBER M.MUH-052 CHASSIS PG-13,5 CABLE FITTING M.ELK-RKR-PLS-007 FOOT BOTTOM RUBBER M.ENJ-ERS-LST-042 PLASTIC FOOT M.ENJ-ERS-LST-044 MIXING APPARATUS...
- Page 12 PLANETARY MIXERS ( SPEED CONTROL ) SPARE PART LIST-EXPLODING DRAWING Kasap Tip Dik Buzdolapları MK.05...
- Page 13 PLANETARY MIXERS ( SPEED CONTROL ) Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING PRODUCT CODE : MK.05 PRODUCT NAME P.CODE ERS.M.ELK-SLT-BTL-011 GREEN LIGHTED BUTTON RED BUTTON (MOMENTARY) M.ELK-SLT-BTL-010 M.ENJ-ERS-PLS-PS-018 BUTTON PANEL SHEET YSC-ERS.SH-LZ-0074 POTENTIOMETER M.ELK-PMT-4,7 M.ELK-MEK-MTM-004 TIME CLOCK BUTTON SOCKET M.AKS-DGM-MUH-009 M.ENJ-ERS-PLS-MK-003 TOP COVER...
- Page 14 PLANETARY MIXERS ( SPEED CONTROL ) PG-13,5 CABLE FITTING M.ELK-RKR-PLS-007 CHASSIS Kasap Tip Dik Buzdolapları M.ENJ-ERS-LST-042 FOOT BOTTOM RUBBER PLASTIC FOOT M.ENJ-ERS-LST-044 M.MON-RAY-002 SLED M.MON-RAY-001 M.ENJ-ERS-PLS-MK-006 FOOTTOP COVER M.MTS-ERS-MK-009 BOILER 43*46 BASKET M.MUH-053 YTL-ERS.MK-KS-0068 MIXING ELEMENT YTL-ERS.MK-KS-0060 MIXING ELEMENT ARA-ERS.MK-0013 MIXING APPARATUS YDK-ERS.MK-CN-0044 MIXING APPARATUS...
- Page 15 PLANETARY MIXERS ( SPEED CONTROL ) Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING MK.07...
- Page 16 PLANETARY MIXERS ( SPEED CONTROL ) SPARE PART LIST-EXPLODING DRAWING Kasap Tip Dik Buzdolapları PRODUCT CODE : MK.07 PRODUCT NAME P.CODE M.ENJ-ERS-PLS-PS-018 BUTTON M.AKS-DGM-MUH-009 BUTTON SOCKET GREEN LIGHTED BUTTON ERS.M.ELK-SLT-BTL-011 RED BUTTON (MOMENTARY) M.ELK-SLT-BTL-010 YSC-ERS.SH-LZ-0074 PANEL SHEET M.ELK-MEK-MTM-004 TIME CLOCK M.ELK-PMT-4,7...
- Page 17 PLANETARY MIXERS ( SPEED CONTROL ) Kasap Tip Dik Buzdolapları BEARING ( UCFL 204G ) M.RLM-YTK-002 M.ELK-RKR-PLS-007 PG-13,5 CABLE FITTING ERS.M.AKS-KLP-BKL-010 HANDLE YTL-ERS.MK-KS-0076 STAMP YTL-ERS.MK-KS-0059 STEERING HANDLE STEERING HANDLE YTL-ERS.MK-KS-0066 MAGNET M.MIK-ERS-007 CHASSIS M.ENJ-ERS-LST-042 FOOT BOTTOM RUBBER M.ENJ-ERS-LST-044 PLASTIC FOOT M.MON-RAY-002 SLED M.MON-RAY-001...
- Page 18 PLANETARY MIXERS ( SPEED CONTROL ) SPARE PART LIST-EXPLODING DRAWING Kasap Tip Dik Buzdolapları EMP.10...
- Page 19 PLANETARY MIXERS ( SPEED CONTROL ) Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING PRODUCT CODE : EMP.10 PRODUCT NAME P.CODE GREEN LIGHTED BUTTON ERS.M.ELK-SLT-BTL-011 RED BUTTON (MOMENTARY) M.ELK-SLT-BTL-010 BUTTON M.ENJ-ERS-PLS-PS-018 PANEL SHEET YSC-ERS.SH-LZ-0074 POTENTIOMETER M.ELK-PMT-4,7 TIME CLOCK M.ELK-MEK-MTM-004 TOP COVER M.ENJ-ERS-PLS-MK-013 ENGINE PULLEY YDK-ERS.MK-CN-0034...
-
Page 20: Helectric Circuit Schema
PLANETARY MIXERS ( SPEED CONTROL ) ELECTRIC CIRCUIT SCHEMA Kasap Tip Dik Buzdolapları B1- STOP BUTTON B2- START BUTTON T-TIME CLOCK S1- SWITCH S2- MAGNETIC SENSOR C1- CONTACTOR 1 H-DRIVER M-ENGINE...
