Dough weighing machine
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
DOUGH WEIGHING MACHINE
Kasap Tip Dik Buzdolapları
CONTENTS
Page
2
Page
3
Page
3
Page
4
Page
4
Page
4
Page
5
Page
6
Page
8
Page
11
Page
12
Page
19
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EMP.HKT.01 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for EMPERO EMP.HKT.01

Summary of Contents for EMPERO EMP.HKT.01

  • Page 1: Table Of Contents

    DOUGH WEIGHING MACHINE Kasap Tip Dik Buzdolapları CONTENTS GENEREAL INFORMATION Page PRODUCT DESCRIPTION Page TECHNICAL INFORMATION Page TRANSPORTATION Page UNPACKING Page INSTALLATION Page SAFETY INSTRUCTIONS Page OPERATION Page CLEANING & MAINTENANCE Page TROUBLESHOOTING Page SPARE PART LIST- EXPLODING DRAWINGS Page ELECTRIC CIRCUIT SCHEMA Page...

  • Page 2: Agenereal Information

    DOUGH WEIGHING MACHINE Kasap Tip Dik Buzdolapları GENERAL INFORMATION Before installing the appliance, read operation and maintenance instructions carefully.Wrong installation and part changing may damage the product or may cause injury on people.These are not in our company’s responsibility to damage the appliance intentionally,negligence,detriments because of disobeying instructions and regulations,wrong connections.Unauthorized intervention to appliance invalidates the warranty.

  • Page 3: A1 Product Description

    PRODUCT DESCRIPTION * The Professional Salad and Vegetable dryer ,that provides high efficiency has been designed to be used in industrial kitchen. Packaging Product Code Dimensions (mm) Weight (kg) Dimensions (mm) EMP.HKT.01 475x820x790 EMP.HKT.02 695x860x1000 EMP.HKT.03 430x655x805 TECHNICAL INFORMATION CODE EMP.HKT.01...

  • Page 4: A3 Transportation

    DOUGH WEIGHING MACHINE TRANSPORTATION Kasap Tip Dik Buzdolapları *This appliance can not be moved by hand from area to area.It must be moved on pallet with forklift truck. UNPACKING *Please unpack the package according to the security codes and ordinances of current country and get rid from the pack.Parts which contacts with food are produced by stainless steel.All plastic parts are marked by material’s symbol.

  • Page 5: Csafety Instructions

    DOUGH WEIGHING MACHINE Kasap Tip Dik Buzdolapları SAFETY INSTRUCTIONS Do not use the device in facilities without adequate lighting. Do not install the device close to flammable and explosive materials. Do not run the device idle. Do not load too much below/over the capacity of the device. Do not interfere with the device without using appropriate protective equipment.

  • Page 6: Doperation

    DOUGH WEIGHING MACHINE OPERATION *Control Panel (HKT.01): Kasap Tip Dik Buzdolapları Weight Swıtch Swıtch A : On – Off Button Apparatus Min (GR) Max (GR) Dia (mm) B : Start Button Ø 35 C : Stop Button Ø 40 D : Emergency Stop Button Ø...
  • Page 7 DOUGH WEIGHING MACHINE Kasap Tip Dik Buzdolapları OPERATION * Control Panel (HKT.03): A : Emergency Stop Button B : Start Button C : Stop Button  Flour the dough slot and auger before use.  Press the start button (B) ...

  • Page 8: Ecleaning & Maintenance

    DOUGH WEIGHING MACHINE CLEANING & MAINTENANCE Kasap Tip Dik Buzdolapları HKT.01 ( Cleanıng & Maıntenance ) Figure - 2 Figure - 1 A : Front Cover B : Engine Group C : Dough setting sensor D : Top cover E : Dough pushing auger F : Dough mouth G : Wing nut H : Helical wing nut...
  • Page 9 DOUGH WEIGHING MACHINE Kasap Tip Dik Buzdolapları CLEANING & MAINTENANCE HKT.03 Figure - 4 J : Front Cover K : Spiral peripheral chamber L : Silicone Gasket Figure - 5...
  • Page 10 DOUGH WEIGHING MACHINE CLEANING & MAINTENANCE Kasap Tip Dik Buzdolapları  CLEANING AND MAINTENANCE AFTER EVERY USE For HKT.01; After each dough cutting process; • Open the front cover. (A) (Picture – 1) • Clean the sensor inside the dough weight adjustment knob (C). (Picture – 1) •...

  • Page 11: Ftroubleshooting

    DOUGH WEIGHING MACHINE Kasap Tip Dik Buzdolapları TROUBLESHOOTING Check whether the plug of the device is plugged into the THE DEVICE DOES socket. NOT WORK Check the electrical connections. Check the door sensors. Check whether there is material jam in the augers. SOUND COMING If there is a sound from the engine, stop the device and call FROM DEVİCE...

  • Page 12: Gspare Part List- Exploding Drawings

    DOUGH WEIGHING MACHINE SPARE PART LIST-EXPLODING DRAWING Kasap Tip Dik Buzdolapları EMP.HKT.01...
  • Page 13 DOUGH WEIGHING MACHINE Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING PRODUCT CODE: EMP.HKT.01 PRODUCT NAME PRODUCT CODE M8 DIAMETER 49 BUTTERFLY FEMALE WITH BAKALIT HANDLE M.AKS-KLP-BKL-030 BODY BACK COVER SHEET YSC-ERS.HKT-PN-0001 SPIRAL PIPE REAR LOCK PART YTL-ERS.HKT-KS-0017 RING (471-50)
  • Page 14 DOUGH WEIGHING MACHINE MAGNETIC SENSOR (MMS-301-1-0-3) M.ELK-SWC-KTG-001 PIZZATO BRAND MK V11D15 BRAND SWICH M.ELK-SWC-EMAS-008 Kasap Tip Dik Buzdolapları SWITCH FINISHER ALUMINUM YTL-ERS.HKT-KS-0034 SWITCH TOP ALUMINUM 43 mm YTL-ERS.HKT-2CN-0001 SWITCH ALUMINUM MOTION PART YTL-ERS.HKT-KS-0033 SWICH ALUMINUM MOVEMENT SCREW YTL-ERS.HKT-KS-0036 SWICH ALUMINUM FIXING SHAFT YTL-ERS.HKT-KS-0035 SWICH FIXED ALUMINUM YTL-ERS.HKT-KS-0032...
  • Page 15 BEZE RAMP SC-LOWER YSC-ERS.HKT-LZ-0051 KNIFE MOTOR PROTECTION CONNECTING SHEET YSC-ERS.HKT-LZ-0063 ALUMINUM THROAT SHEET YSC-ERS.HKT-LZ-0028 ø170 ALUMINUM THROAT YTL-ERS.HKT-KS-0022 EMP.HKT.01-Ø65 Dough Mouth POLYEMITE YTL-ERS.HKT-KS-0050 EMP.HKT.01-Ø45 Dough Mouth POLYEMITE YTL-ERS.HKT-KS-0046 EMP.HKT.01-Ø50 Dough Mouth POLYEMITE YTL-ERS.HKT-KS-0047 EMP.HKT.01-Ø55 Dough Mouth POLYEMITE YTL-ERS.HKT-KS-0048 EMP.HKT.01-Ø40 Dough Mouth POLYEMITE YTL-ERS.HKT-KS-0045...
  • Page 16 DOUGH WEIGHING MACHINE SPARE PART LIST-EXPLODING DRAWING Kasap Tip Dik Buzdolapları PRODUCT CODE: EMP.HKT.02 PRODUCT NAME PRODUCT CODE DOUGH HOPPER SHEET YSC-ERS.HKT-LZ-0041 CHASSIS BACK COVER SHEET YSC-ERS.HKT-PN-0006 RIGHT-LEFT COVER SHEET YSC-ERS.HKT-PN-0005 SUB COLLECTION SHEET YSC-ERS.HKT-LZ-0038 15 CM INOX PIPE FEET M.AKS-AYK-INX-001...
  • Page 17 DOUGH WEIGHING MACHINE Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING EMP.HKT.03...

  • Page 18: Helectric Circuit Schema

    DOUGH WEIGHING MACHINE SPARE PART LIST-EXPLODING DRAWING PRODUCT CODE : EMP.HKT.03 Kasap Tip Dik Buzdolapları PRODUCT NAME PRODUCT CODE Dough Spiral M.ENJ-ERS-ALM-HKT-001 ALUMINUM PIPE NOZZLE ø229 POLYEMIDE YTL-ERS.HKT-KS-0026 ALUMINUM PIPE ø210 488 mm YBR-ERS.HKT-KS-0002 ø200x190 ACRYLIC PIPE 488 mm YBR-ERS.HKT-KS-0001 ALUMINUM PIPE INSTALLATION ARA-ERS.HKT-0004 CHASSIS...
