7000
Series ELR
Multi-Point Lock with
SE LP10 Reader
Installation Instructions
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Assa Abloy Sargent ELR Series
Summary of Contents for Assa Abloy Sargent ELR Series
- Page 1 Multi-Point Lock with SE LP10 Reader Installation Instructions A8239B 05/20 Copyright © 2020, Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Sargent Manufacturing Company is prohibited.
-
Page 2: Table Of Contents
SE LP10 7000 Series Multi Point Lock Table of Contents Regulatory Compliance ............3 Warning ..................3 General Description ..............4 Specifications/Features ............4 Wiring Diagrams ..............6 Parts Breakdown ..............9 Installation Instructions ............12 Concealed Door Position Switch Instructions (3287) ..18 Operational Check ..............19 A8239B • 800-810-WIRE (9473) • www.sargentlock.com... -
Page 3: Regulatory Compliance
SE LP10 7000 Series Multi Point Lock Regulatory Compliance Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 4: General Description
SE LP10 7000 Series Multi Point Lock General Description The SARGENT SE LP10 brings flexibility to our Integrated Wired access control solutions for the 7000 series multipoint locks. Featuring multiCLASS SE® Technology from HID Global®, the SE LP10 is ideal for mixed credential environments and enables easy migration to higher security credentials and mobile access. - Page 5 SE LP10 7000 Series Multi Point Lock Specifications / Features (Continued) • UL 294 Access Control Ratings: • UL Listed* - UL 294 Indoor Use • CUL Listed - S319: Class 1 Destructive Attack Level 1 • ANSI/BHMA A156.25 Listed Line Security Level 1 Grade 1 Compliant...
-
Page 6: Wiring Diagrams
SE LP10 7000 Series Multi Point Lock Wiring Diagrams Product 8 PIN CONNECTOR 4 PIN CONNECTOR 1-Black 2-Red 3-White 4-Green 5-Orange 6-Blue 7-Brown 8-Yellow 1-Violet 2-Gray 3-Pink 4-Tan ACCESS CONTROL DEVICES: SE LP10 7000 MP Lock, ElectroLynx wire Color / Function assignments 12VDC WIEGAND WIEGAND... - Page 7 SE LP10 7000 Series Multi Point Lock Typical (UL294-Compliant) SE LP10 7000 Multi Point Lock Application Diagram #1 Tamper will trigger when reader is removed from door and tamper wiring is connected at the panel. 12/24VDC System Average Peak Average Peak Reader 100mA...
- Page 8 SE LP10 7000 Series Multi Point Lock Alternate Indicator Application Diagram #2 (12/24VDC System) Connect GREEN_LED input to switch controlled by panel. Shorting GREEN_LED to READER_NEG (Black) with panel switch will override reader LED to keep it green. Reader Electronics Requires 12VDC Filtered and Regulated 120 VAC Power Supply 12-24VDC...
-
Page 9: Parts Breakdown
SE LP10 7000 Series Multi Point Lock Parts Breakdown SE LP10 7000 Series Tools Required • Phillips screw driver (standard size) • Slotted screw driver (standard size) • #8-32 tap & tap drill (for metal door applications) • T10 Torx Driver A8239B •... - Page 10 SE LP10 7000 Series Multi Point Lock Parts Breakdown (Continued) SE LP10 7000 Series Tools Required • Phillips screw driver (standard size) • Slotted screw driver (standard size) • #8-32 tap & tap drill (for metal door applications) • T10 Torx Driver A8239B •...
- Page 11 SE LP10 7000 Series Multi Point Lock Parts Breakdown (Continued) SE LP10 7000 Series ITEM PART # Description Req. WD/MD/AD Inside Trim Assembly Outside Trim Assembly 94-2411 MD/AD Inner Chassis Assembly 94-2412 MD/AD Inner Chassis Assembly, Fire (12-) 94-2414 MD/AD Monitoring Inner Chassis, Fire (53-/12-53-) 94-2423 WD Inner Chassis Assembly (Not shown) 94-2424...
-
Page 12: Installation Instructions
SE LP10 7000 Series Multi Point Lock Installation Instructions 1 Door Preparation Inside A. Verify Hand and Bevel of Door • Check hand of door. The Multi-Point lock may be handed. • Door should be fitted and hung. Left Hand Right Hand •... - Page 13 SE LP10 7000 Series Multi Point Lock 3 Install Outside Trim and Inside Trim A. Outside Trim Outside Exit trim 1. For exterior applications, use ET gasket (52-0263) to seal ET escutcheon and outside door surface (Fig. 3A). 2. Feed wire through the through hole and attach the outside exit trim to the door.
- Page 14 SE LP10 7000 Series Multi Point Lock 5 Installation of SE LP10 Reader & Trim Bezel Observe precautions for handling electrostatic sensitive devices. If the SE LP10 reader is installed with a module (Fig. 5A), make sure that the reader is powered down when inserting/removing the module; i.e., do not “hot-plug”...
- Page 15 SE LP10 7000 Series Multi Point Lock 6A Inside Mounting Plate and Wire Connections (Non-ELR) 1. Attach mounting plate using (2) #8 x 1/2” self-drilingl screws (Fig. 6A). 2. Connect 6- and 2-pin connectors from device to 6- and 2-pin connectors on reader harness (Fig.
- Page 16 SE LP10 7000 Series Multi Point Lock 6B Inside Mounting Plate and Wire Connections (ELR) Install the upper left mounting screw, #8 - 32 x 5/8 Fillister for metal door or #8 x 5/8 self-drilling Fillister for wood doors (Figure 6F). Note: Leave the screw loose enough to slide the ELR assembly on.
- Page 17 SE LP10 7000 Series Multi Point Lock 7 Fire Plate Installation and Earth Ground Connection 1. Remove lower left screw from mounting plate. Feed screw through green/yellow ground wire ring terminal. Reinstall screw. Ensure that green/yellow wire points toward top of door in order to avoid interference with escutcheon.
-
Page 18: Concealed Door Position Switch Instructions (3287)
SE LP10 7000 Series Multi Point Lock 8B Position Inside Escutcheon & Wires (ELR) 1. Position escutcheon against door by hooking the top edge on the top of the ELR assembly. Verify that no wires are being pinched. 2. Mount inside escutcheon assembly to plate using (1) #8-32 x 5/8"... -
Page 19: Operational Check
(e.g. if fail-secure, the outside lever should be rigid with power removed). Feature Wiegand Test Unit 12 or 24VDC lock The ASSA ABLOY Wiegand Test Unit verifies your installation in voltage adjustable the field. The test unit checks for proper wiring, card reader data integrity, lock functionality including lock/unlock, door position... - Page 20 The company’s customer base includes commercial construction, institutional, and industrial markets. Copyright © 2020, Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Sargent Manufacturing Company is prohibited.
