  • Page 1 Keypad Mortise Lock Installation & Programming Instructions A7373E 02/21 Copyright 2014. 2021, Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Sargent Manufacturing Company is prohibited.

  • Page 2: Table Of Contents

    KP Series Keypad Mortise Lock Table of Contents Regulatory Compliance ............3 Warning ...................3 General Description ..............4 Specifications ................4 Features ...................4 Parts Breakdown ..............6 Installation Instructions ............8 Operational Check ..............18 Programming Instructions ............19 Troubleshooting ..............26 A7373E • 800-810-WIRE (9473) • www.sargentlock.com...

  • Page 3: Regulatory Compliance

    KP Series Keypad Mortise Lock Regulatory Compliance Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 4: General Description

    Keypad Mortise Lock General Description The SARGENT KP Series Mortise Lock is designed for areas which require standalone authorized entry. It is a self-contained microprocessor-controlled keypad with non-volatile memory. The keypad holds a total of 99 different user codes. User codes 01, 02 and 03 are utilized for Master Code, Emergency Code and Supervisory Code, respectively.
  • Page 5 KP Series Keypad Mortise Lock Features (continued) KP8276 KP8278 • Deadbolt function • No deadbolt function • Cylinder override provided • Cylinder override provided KP8277 KP8279 • Deadbolt function • No deadbolt function • No cylinder override • No cylinder override Keypad •...

  • Page 6: Parts Breakdown

    KP Series Keypad Mortise Lock Parts Breakdown Tools Required (not supplied): KP Series Parts List • #2 Phillips screwdriver • Flat head screwdriver • Security socket screw key 1/8”allen wrench KP8276 ONLY KP8278 Inside of Door Outside of Door A7373E • 800-810-WIRE (9473) • www.sargentlock.com...
  • Page 7 KP Series Keypad Mortise Lock Parts Breakdown (Continued) Part # Req. Item Description 01-0803 Battery Alkaline (“C” cell) 77-0168 #8-32UNC-2A x 1-7/8” PH FL HD Machine Screw 01-0297 Security Socket Screw Key (1/8”) - not provided 01-9674 #8-32UNC-2A x 1-1/2” PH Machine Screw 01-9063 Washer 81-0467...

  • Page 8: Installation Instructions

    KP Series Keypad Mortise Lock Installation Instructions Step #1 – Verify Hand and Bevel of Door A. Verify Hand and Bevel of Door Stand on outside/locked side of door when determining the door hand LHRB RHRB Left Hand Left Hand Right Hand Right Hand Hinges Left...
  • Page 9 KP Series Keypad Mortise Lock Step #2 – Verify Hand and Bevel of Door A. Reverse Lock Hand Red surface of locking piece must face the outside/locked side of door. To rotate locking piece (Fig. 2A): 1. Position lock body with red surface of locking piece visible. 2.
  • Page 10 KP Series Keypad Mortise Lock Step #3 – Install Lock Body Inside of Door 1. Insert lock body into mortised cutout (Fig. 3A). Fig. 3A 2. Hold lock body loosely in place with (2) lock body screws. Note: Do not completely tighten screws at this time. Outside of Door Harness exits Non-Cylinder side...
  • Page 11 KP Series Keypad Mortise Lock Step #4 – Exterior Door Options Install Weather Conduit Non Fire-Rated Exterior A. Fire Stop Plate (P/N 53-0033) hollow metal doors only Fire-rated doors require a fire stop plate on the outside of the door (Fig. 4A). O-Ring 1.
  • Page 12 KP Series Keypad Mortise Lock Step #6 – Install Outside Escutcheon and Lever Assembly Install Outside Lever Assembly A7373E • 800-810-WIRE (9473) • www.sargentlock.com...
  • Page 13 KP Series Keypad Mortise Lock Step #7 – Install Inside Escutcheon Remove screw with 1/8" security wrench (not provided) then remove Battery Cover (52-0069) Inside Escutcheon Assembly C. Plug keypad connector into inside escutcheon as shown. Gently fold cable into hole toward keypad.
  • Page 14 KP Series Keypad Mortise Lock Step #8 – Inside Lever Installation B. Place escutcheon flat against door insuring excess wire is placed as per 7C and 7D. A7373E • 800-810-WIRE (9473) • www.sargentlock.com...
  • Page 15 KP Series Keypad Mortise Lock Step #8 – Continued A7373E • 800-810-WIRE (9473) • www.sargentlock.com...
  • Page 16 KP Series Keypad Mortise Lock Step #9 – KP8276 and KP8278 Only - Install Cylinder Position cylinder so that the SARGENT logo is right-side up. Correct Incorrect A7373E • 800-810-WIRE (9473) • www.sargentlock.com...
  • Page 17 KP Series Keypad Mortise Lock Step #10 – Application of Front Plate Step #11 – Battery Installation A7373E • 800-810-WIRE (9473) • www.sargentlock.com...

  • Page 18: Operational Check

    KP Series Keypad Mortise Lock Operational Check • Place key into cylinder and rotate key. • The key will retract the latchbolt. • If the deadbolt is thrown, the key will retract both the deadbolt and the latchbolt. • Inside handle lever retracts latchbolt and (if provided). •...

  • Page 19: Programming Instructions

    KP Series Keypad Mortise Lock Programming Instructions The KP Keypad Lock can support 99 users. Each user is assigned a User Number in addition to the code used for entry. Example: USER TYPE USER NUMBER USER CODE (2-6 DIGITS) Master 1 2 3 4 Emergency 2 2 2 2 2...
  • Page 20 KP Series Keypad Mortise Lock Programming Instructions (Continued) **NOTE: Product is shipped in Standard Mode (default mode). If lock configuration needs to change from Standard to Pharmacy mode then ENABLE Pharamacy mode using the following keypad programming steps: Pharmacy (PHR) Mode ENABLE •...
  • Page 21 KP Series Keypad Mortise Lock Programming Instructions (Continued) All of the following procedures start with 99#. If after the last “ ” is depressed, the yellow LED does not go out, depress “ ” once more. Change Master Code: • 1234* (Yellow LED Begins to Blink Slowly) This example uses the Factory Default Master Code •...
  • Page 22 KP Series Keypad Mortise Lock Programming Instructions (Continued) All of the following procedures start with 99# (continued). If after the last “ ” is depressed, the yellow LED does not go out, depress “*” once more. To Deactivate “Beep” With the Depression of Each Key: •...
  • Page 23 KP Series Keypad Mortise Lock Programming Instructions (Continued) Chain Programming When programming multiple User Numbers and Codes into the Keypad Exit Device, it is not necessary to leave and re-enter the programming Mode (50) for each entry. Multiple entries may be chained together and the three different types ofuser codes (Standard, Passage and One time) may be mixed.
  • Page 24 KP Series Keypad Mortise Lock Programming Instructions (Continued) All of the following procedures start with 99# (continued). If after the last “ *” is depressed, the yellow LED does not go out, depress “ *” once more. To Interrogate Transaction Log (to output last 15 entries): Hold Data Transfer Device (DTD) up to the (top right side) infrared LED as shown.
  • Page 25 KP Series Keypad Mortise Lock Programming Instructions (Continued) All of the following procedures start with 99# (continued). If after the last “ ” is depressed, the yellow LED does not go out, depress “*” once more. To Delete a User Number: •...

  • Page 26: Troubleshooting

    KP Series Keypad Mortise Lock Troubleshooting Instructions Note: The following three tests are used to check basic functionality of the keypad, inside controller and deadbolt (on 8200 series mortise lock only). Power On Self Test (POST) for new KP controllers only (released after 1/2021) •...
  • Page 27 KP Series Keypad Mortise Lock A7373E • 800-810-WIRE (9473) • www.sargentlock.com...
  • Page 28 The company’s customer base includes commercial construction, institutional, and industrial markets. Copyright © 2014. 2021, Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Sargent Manufacturing Company is prohibited.
