Page 2: Table Of Contents
CONTENTS 1. Safety Instructions ..................2 2. Technical Specifications ................. 4 3. Control Panel ....................6 4. Fixture Installation ..................7 5. Effect Wheels ....................8 6. Control By Universal DMX Controller ............. 9 6.1 DMX512 Connection ................9 6.2 Address Setting ..................10 6.3 DMX512 Configuration ................ -
Page 3: Safety Instructions
1. Safety Instructions Please read the instruction carefully which includes important information about the installation, usage and maintenance. WARNING Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction manual. Important: Damages caused by the disregard of this user manual are not subject to warranty. - Page 4 DO NOT operate in a dirty or dusty environment. DO clean the fixture regularly. DO NOT touch any wire during operation as there might be a hazard of electric shock. Avoid entanglement of the power cord with other wires. ...
-
Page 5: Technical Specifications
2. Technical Specifications Power Voltage: 180-240V~ 50/60Hz Power Consumption: 120W Light Source: T0-90-V2-80H Color Temperature: 8000K Beam Angle: 2° Movement: Pan: 540° Tilt: 270° Pan/Tilt Resolution: 16-bit Automatic pan/tilt position correction Dimmer/Shutter: 0-100% smooth dimming; outstanding strobe effect with variable speed Color Wheel: 1 x color wheel with 10 fixed colors plus open Gobo Wheel:... - Page 6 Features: RA>70 Electronic linear focus adjustment system 1x48-facet prism, rotatable in both directions Build-in macro color effect leads to excellent performance Multiple built-in show modes Dimension/Weight: 286x166x434, 8.2kgs 11.3"x6.5"x17.1"in, 18.1lbs Photometric Diagram:...
-
Page 7: Control Panel
3. Control Panel 1. DMX OUT: For DMX512 link, use a network cable to link the next units 2. DMX IN: For DMX512 link, use a network cable to link the unit and the DMX controller 3. POWER IN: To connect to supply power... -
Page 8: Fixture Installation
4. Fixture Installation DO install and operate by qualified operator. Fixture(s) should be installed in areas outside walking paths, seating areas, or away from areas were unauthorized personnel might reach the fixture by hand. NEVER stand directly below the fixture(s) when rigging, removing or servicing. Always ensure that the unit is firmly fixed to avoid vibration and slipping off during operation. -
Page 9: Effect Wheels
5. Effect Wheels DANGER! Install the color wheel/static gobo wheel with the device switched off only. Unplug from mains before changing the color wheel/static gobo wheel! -
Page 10: Control By Universal Dmx Controller
6. Control By Universal DMX Controller 6.1 DMX512 Connection 1. To avoid erratic behavior, make sure that the output of the last DMX device in the chain is terminated by a resistor (120-ohm 1/4W) which is connected between RJ45 PIN 1 (XLR PIN 3) and RJ45 PIN 2 (XLR PIN 2) of a RJ45 connector (a male XLR connector). -
Page 11: Address Setting
6.2 Address Setting If you use a universal DMX controller to control the units, you have to set DMX address from 1 to 512 so that the units can receive DMX signal. Please refer to the following diagram to address your DMX512 channel for the first 4 units. Unit 1 Unit 2 Unit 3... - Page 12 058-063 Sound Change Color 064-127 Color Wheel Indexing Open Open+Red Red+Orange Orange Orange+Aquamarine Aquamarine Aquamarine+Green Green Green+Light Green Light Green Light Green+Magenta Magenta Magenta+Cyan Cyan Cyan+Light Yellow Light Yellow Light Yellow+6000K 6000K 6000K+UV 84-127 128-189 Counter-Clockwise Rotation, Fast to Slow 190-193 Stop 194-255...
- Page 13 GOBO 2 000-003 Open 004-007 Gobo 1 008-011 Gobo 2 012-015 Gobo 3 016-095 Gobo 1 Rotating, Slow to Fast 096-175 Gobo 2 Rotating, Slow to Fast 176-255 Gobo 3 Rotating, Slow to Fast PRISM 000-007 Close 008-255 Open R-PRISM 000-127 Index 0°360°...
- Page 14 160-199 Null 200-209 Reset All 210-219 Dimmer Speed Fast 220-229 Dimmer Speed Smooth 230-239 Null 240-245 Null 246-251 Null 252-255 Null RDM FUNCTIONS Select the MANUFACTURER menu to display the manufacturer of the fixture. Select the SOFTWARE VERSION menu and the program version number of the fixture will be displayed.
-
Page 15: Error Information
7. Error Information 1. CPU-B Error Check whether the 485 (DATA) leads on the PCB board are installed in place or disconnected. Check whether the related 485 (DATA) signal circuit on the PCB board is damaged. 2. Pan Reset Error Check whether the position of the pan where the magnet is installed falls off or is damaged. - Page 16 7. Tilt Encode Error Check whether the encoder on the tilt is damaged. Check whether the lead connecting the encoder on the tilt and the PCB board is in poor contact or disconnected. 8. Tilt Encode Not Find Check whether the lead connecting the encoder on the tilt and the PCB board is in poor contact or disconnected.
- Page 17 12. Prism Error Check whether the position of the prism where the magnet is installed falls off or is damaged. Check whether there are obstacles in the prism operating range. Check whether the Hall element on the prism is damaged. Check whether the lead connecting the Hall element on the prism and the PCB board is in poor contact or disconnected.
- Page 18 17. BaseFan1 Too Slow Check whether the fan is out of order. Check whether there are obstacles in the fan operating range. 18. BaseFan1 Too Fast Check whether the fan is out of order. Check whether the fan circuit on the motherboard breaks down. 19.
-
Page 19: Troubleshooting
The position of each fan of the fixture: 8. Troubleshooting Following are a few common problems that may occur during operation. Here are some suggestions for troubleshooting: A. The unit does not work, no light and the fan does not work 1. -
Page 20: Fixture Cleaning
9. Fixture Cleaning It is absolutely essential that the fixture is kept clean to ensure the maximum light-output and allow the fixture to function reliably throughout its life. The fixture must be cleaned regularly to avoid dust, dirt and smoke-fluid residues building up on or within the fixture. The cleaning frequency depends on the application environment. - Page 24 Innovation, Quality, Performance...
