Page 1: User Manual
LED BARREL LED-BR10 User Manual Широкий ассортимент оборудования ACME Professional Entertainment Technology на www.maxlight.ru... -
Page 2: Table Of Contents
1. Safety Instruction Please read the instruction carefully which including important information about the installation, operation and maintenance. TABLE OF CONTENTS WARNING Please keep this User Manual for future consultation. If you sell the unit to another 1. Safety Instruction user, be sure that they also receive this instruction booklet. -
Page 3: Technical Specification
4. How To Control The Unit For power supply, do not connect in series much more than 20 units, use 4.1 Control Panel another mains supply for next 20 units. 2. Technical Specification It can be operated by DMX512 control or can be used as an individual unit without controller. -
Page 4: Easy Controller
5. DMX 512 Configuration 4.3 Easy Controller (by CA-8/CA-9/CA-9RTX) DMX Configuration The easy remote control is used only in master/slave mode. By 5 Channel mode connecting to the 4-pin jack of the first unit, you will find that the remote controller on the first unit will control all the other units for Barrel Strobe Color... -
Page 5: Troubleshooting
1. If you using a controller with 5 pins DMX output, you need to use a 5 to 3 pin of the fixture or the previous one. adapter-cable. 4. Try to use another DMX controller. 2. At last unit, the DMX cable has to be terminated with a terminator. Solder a 120 5. - Page 6 EC - Declaration of Conformity We declare that our products (lighting equipments) comply with the following specification and bears CE mark in accordance with the provision of the Electromagnetic Compatibility (EMC) Directive 89/336/EEC. EN55014-2: 1997 A1: 2001, EN61000-4-2: 1995; EN61000-4-3: 2002; EN61000-4-4: 1995;...
