Page 1: User Manual
MATRIX L ED LED-7871 User Manual Please read the instructions carefully before use... -
Page 2: Table Of Contents
1. Safety Introductions Please read the instructions carefully which includes important information about the installation, operation and maintenance. TABLE OF CONTENTS WARNING Please keep this User Manual for future consultation. If you sell the fixture to another user, be 1. -
Page 3: Technical Specifications
2. Technical Specifications 3. How To Set The Fixture 3.1 Control Panel The Matrix 4 LED features 4 high brightness red, green, blue and white LEDs clusters, cresting stunning text patterns, geometric figures, dynamic scanning, rolling and rotating effects. Great built-in lighting shows under Master/Slave operation triggered by music ... - Page 4 3.2 Main Function button and the display will blink. Use DOWN and UP button to select the (1 channel) To select any functions, press MENU button until the required one is shown on the display. (4 channels) or (256 Channels) mode. Once the mode has been Select the function by ENTER button and the display will blink.
-
Page 5: How To Control The Fixture
3. By DMX controller LED display No need to turn the unit off when you change the DMX address, as new DMX address setting will be effected at once. Every time you turn the unit on, it will show “7871” on the Press the MENU button up to when the is shown on the display. -
Page 6: Dmx512 Configuration
4.3 DMX Controller 256-CH mode: Using universal DMX controller to control the units, you have to set DMX address from 1 to 512 channel so that the units can receive DMX signal. Press the MENU button up to when the is showing on the display. -
Page 7: Troubleshooting
The DMX output and input connectors are pass-through to maintain the DMX circuit master/ slave mode signal. when one of the units’ power is disconnected. 2. Wrong DMX address in the fixture. Set the proper address. At last fixture, the DMX cable has to be terminated with a terminator to reduce signal errors. - Page 8 EC - Declaration of Conformity We declare that our products (lighting equipments) comply with the following specification and bears CE mark in accordance with the provision of the Electromagnetic Compatibility (EMC) Directive 89/336/EEC. EN55014-2: 1997 A1: 2001, EN61000-4-2: 1995; EN61000-4-3: 2002; EN61000-4-4: 1995;...
