- Page 1 GENESIS MOVE LED-MS50A User Guide Professional Entertainment Technology...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety Instruction Technical Specification How To Set The Unit How To Control The Unit Troubleshooting Fixture Cleaning... -
Page 3: Safety Instruction
1. Safety Instruction Please read carefully the instruction, which includes important information about the installation, usage and maintenance. WARNING Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. Unpack and check carefully there is no transportation damage before using the unit. - Page 4 3 operation modes: DMX, Master/Slave, Sound Activation. Great built-in lighting programs under master/slave mode triggered by music. Optional CA-8 easy controller or CA-9 RTX (wireless easy control kit) for instant lighting shows. Rotating gobo wheel with 7 gobos plus white, fixed gobo wheel with 8 gobos plus open. Color wheel with 7 colors plus white.
-
Page 5: How To Set The Unit
3. How To Set The Unit 3.1 Control panel Display To show the various menus and the selected functions DMX input present MASTER Master Mode SLAVE Slave Mode SOUND Flashing Sound activation Button MENU To select the programming functions DOWN To go backward in the selected functions To go forward in the selected functions ENTER... - Page 7 DMX Address Select DMX Address, press ENTER button to confirm, the present address will blink on the display. Use UP and DOWN button to adjust the address from 1 to 512. Once the address has been selected, press the ENTER button to setup, to go back to the functions without any change press the MENU button again. Hold and press the MENU button about one second or wait for one minute to exit the menu mode.
- Page 8 Sound Sense Select Sound Sense, press ENTER button to confirm, present mode will blink on the display. Use DOWN and UP button to select the 0 …100 mode. Once the mode has been selected, press the ENTER button to setup, to go back to the functions without any change press the MENU button again. Hold and press the MENU button about one second or wait for one minute to exit the menu mode.
- Page 9 MENU button again. Hold and press the MENU button about one second or wait for one minute to exit the menu mode. Auto-Test Press the MENU button up to when the Auto-Test is blinking on the display. Pressing ENTER button and the unit will run self-test by built-in program.
- Page 10 Pan Inverse Tilt Inverse Back Light 3S Delay Function Delay AUTO Defaults: Mostly automatic mode, for non professional users, detailed explanation as followings: 15 Chan Channel Mode Split Color Mode Slave 1 Slave Mode Black Out Sound State Sound Sense Pan Inverse Tilt Inverse Back Light...
-
Page 11: How To Control The Unit
blink. Use DOWN and UP button to adjust the home position of the Pan, Tilt, color, Gobo1, R-Gobo, Gobo2, Prism, R-Prism, or Focus. Once the position has been selected, press the ENTER button to setup, to go back to the functions without any change press the MENU button again. Hold and press the MENU button about one second or wait for one minute to exit the menu mode. - Page 12 the MENU button again. Hold and press the MENU button about one second or wait for one minute to exit the menu mode. Please refer to the following diagram to address your DMX512 channel for the first 4 units： Unit 1 Unit 2 Unit 3 Unit 4...
- Page 14 16 channel modes：...
- Page 15 4.5 DMX512 Connection COMMON DMX + DMX INPUT DMX OUTPUT DMX - Termination reduces signal error and avoids signal transmission problems and interference. It is always advisable to connect a DMX terminal. (Resistance 120 ohm 1/4W)between pin2(DMX-)and pin3(DMX+) of the last fixture. 1.
-
Page 16: Troubleshooting
Inadequate or damaged cables, soldered joints or corroded connectors can easily distort the signal and shut down the system. 4. The DMX output and input connectors are pass-through to maintain the DMX circuit, when one of the units’ power is disconnected. 5. -
Page 17: Fixture Cleaning
6. Fixture Cleaning The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to optimize light output. Cleaning frequency depends on the environment in which the fixture operates: damp, smoky or particularly dirty surrounding can cause greater accumulation of dirt on the unit’s optics. Clean with soft cloth using normal glass cleaning fluid.
