LAUNCH
6 OK button
7 Return button
OBD-16 diagnostic
1
connector
2 Mode indicator
1.4 Specifications
Operating system
Processor
Creader Professional MOT III English User Manual
Press OK button to confirm options or
selections
Press to return to the previous screen.
VCI connector
To connect on vehicle‟s OBD II DLC.
 Red light on indicates that the VCI connector
is connected to the vehicle‟s DLC.
 Blue light on indicates the VCI connector is
working in wireless (BT) communication
mode.
Android 7.0
Quad core 1.5 GHz
8
