LAUNCH
3. Choose one of the two ways to obtain power from:
A. Power adaptor: Connect one end of the included power adaptor to
charging port of the tablet, and the other end to AC outlet.
B. Internal battery pack
For non-OBDII vehicle, proceed as follows:
1. Locate vehicle‟s DLC socket.
2. Select the corresponding non-16pin connector.
3. Plug the non-16pin end of the connector into the DLC socket, then connect
the other end to the OBD I adaptor, and then tighten the captive screws.
4. Connect the other end of the adaptor to the included VCI connector.
5. To supply power to OBD I adaptor from:
A. Cigarette Lighter cable (optional): Connect one end of the cigarette lighter
cable to vehicle‟s cigarette lighter receptacle, and the other end to the power
jack of OBD I adaptor.
B. Battery Clamps Cable (optional): Connect one end of the battery clamps
cable to vehicle‟s battery, and the other end to the power jack of OBD I
adaptor.
4.4 Bluetooth Setting
Enter the Bluetooth setting screen (Settings -> Bluetooth), slide the Bluetooth
switch to ON and the tablet starts searching for all available Bluetooth device,
tap the desired connector to pair.
By default, the Bluetooth name is 98********00 (where ***** stands for 8 digits.).
Note: In case no Bluetooth setting is done before diagnostic software is launched,
you can also configure it while using the software. For details on Bluetooth connection,
please refer to Chapter 5 Start diagnostics.
