Access & Power Integration
Trove2HN2
- Trove2 enclosure with Altronix/Honeywell NetAXS backplane (THN2)
THN2
- Altronix/Honeywell NetAXS backplane only
Installation Guide
All registered trademarks are property of their respective owners.
Rev. THN052518
Installing Company: _________________________ Service Rep. Name: __________________________________________
Address: _________________________________________________________ Phone #: _________________________
SIGNALING
More than just power.™
Advertisement
Related Manuals for Altronix TROVE Trove2HN2
Summary of Contents for Altronix TROVE Trove2HN2
- Page 1 SIGNALING Access & Power Integration Trove2HN2 - Trove2 enclosure with Altronix/Honeywell NetAXS backplane (THN2) THN2 - Altronix/Honeywell NetAXS backplane only Installation Guide More than just power.™ All registered trademarks are property of their respective owners. Rev. THN052518 Installing Company: _________________________ Service Rep. Name: __________________________________________...
-
Page 2: Specifications
Overview: Trove2HN2 accommodates various combinations of Honeywell NetAXS boards with or without Altronix power supplies and accessories for access systems. Specifications: Trove2HN2 Trove2 enclosure with THN2 Altronix/Honeywell backplane. • Includes: tamper switch, cam lock, mounting hardware. • 16 Gauge enclosure with ample knockouts for convenient access. - Page 3 Installation Instructions for Altronix Power Supplies and Sub-Assemblies to THN2: 1. Fasten spacers (provided) into pem configuration (A) or (B) of backplane (Fig. 2, pg. 3). 2. Mount boards to spacers utilizing 5/16” pan head screws (provided) (Fig. 2a, pg. 3).
- Page 4 Installation Instructions for Honeywell NX4PCB to THN2: 1. Fasten spacers (provided) to appropriate pems on backplane (Fig. 3, pg. 4). Fig. 3a 2. Mount boards to spacers utilizing 5/16” pan head screws (provided) (Fig. 3a, pg. 4). Note: Honeywell NX4PCB modules have one (1) RJ45 jack each. Please make sure that they are mounted correctly, as shown in Fig.
- Page 5 Installation Instructions for Honeywell NetAXS-123 with/without NXD1/NXD2 to THN2: 1. Fasten spacers (provided) to appropriate pems on backplane (Fig. 4, pg. 5). Fig. 4a 2. Mount boards to spacers utilizing 5/16” pan head screws (provided) (Fig. 4a, pg. 5). Note: Honeywell NetAXS-123 modules have one (1) RJ45 jack each. Please make sure that they are mounted correctly, as shown in Fig.
- Page 6 Installation Instructions for Honeywell NX4IN or NX4OUT to THN2: 1. Fasten spacers (provided) to appropriate pems on backplane (Fig. 5, pg. 6). 2. Mount boards to spacers utilizing 5/16” pan head screws (provided) (Fig. 5a, pg. 6). Fig. 5a 3. Mount backplane to enclosure with hardware. Spacer Honeywell Backplane...
- Page 7 THN2 Dimensions (H x W x D): 25.375” x 19.375” x 0.3125” (644.6mm x 492.1mm x 7.9mm) 19.375” (492.1mm) 2.2” (55.9mm) 2.2” (55.9mm) 0.156” ( 3.96mm) 1.0” (25.4mm) 1.0” (25.4mm) 7.5” (190.5mm) 7.5” (190.5mm) 9.2” (233.7mm) 9.2” (233.7mm) Trove2HN2 / THN2 Installation Guide - 7 -...
- Page 8 2.00” (50.8mm) 5.25” (133.4mm) 7.00” (177.8mm) 5.25” (133.4mm) Altronix is not responsible for any typographical errors. –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 web site: www.altronix.com | e-mail: info@altronix.com IITrove2HN2 / THN2...
