CONNECTING SENSOR HEADS AND INPUT DEVICES

Table B-2 shows wiring connections for the GPR/GPS and GPM sensing
heads to the monitor.
Table B-2: Wiring GPR/GPS and GPM Sensing Heads
Thermalert GPR/GPS
TERMINAL
WIRE COLOR
NUMBER
6 Black
7 Green
8
Bare
9 Red
10 White
For wiring connections for sensing heads or other input devices with 0 to 5
volt and 4 to 20 mA outputs to the monitor, refer to Section 2.3.2.
WARNING
Incorrect wiring can damage the monitor, sensor, and/or input
device and void the warranty.
34 Thermalert GP Series Operator's Manual
www.calcert.com
15
10 20
5 25
0 30
Thermalert GPM
TERMINAL
WIRE COLOR
NUMBER
4
Green
5 Yellow
6 White
7 Brown
8
Bare
