APPENDIX A QUICK REFERENCE
On the following pages are Quick Reference charts for setting up the
Thermalert GP Monitor with sensing head and input devices and for adjust-
ing the monitor's normal and advanced functions.
WARNING
Make sure the device attached to the monitor is wired correctly
or damage to the monitor and attached units could occur. Refer
to the appropriate Sensing Head and Input Device wiring chart
in Section 2.3.2, and the appropriate Power Connections wiring
chart in Section 2.3.3 before continuing.
Figure A-1 shows you how to set up the Thermalert GP monitor for your
particular sensing head or for your 0–5 volt, 4–20mA, or thermocouple input
device.
Figure A-2 explains how to cycle through the monitor's normal sensor
adjustments when the appropriate sensing head is attached to it.
Figure A-3 shows how to cycle through the monitor's advanced sensor
adjustments when the appropriate sensing head is attached to it.
For a detailed explanation of each function, refer to the appropriate section in
the manual.
