5. Press the button once more and a display similar to Figure 11
appears. Use the or buttons to adjust the deadband.
O
N
L
Figure 11: Deadband Display
6. If you have completed adjusting Setpoint 1 parameters, pressing the
button will take you to Setpoint 2. When finished with Setpoint 2, if used,
pressing again takes you to the 4-20mA output setup indicator display.
To return to the temperature/value display, press the
temperature/value display appears.
Note: The deadband is the temperature/value band (±) about a setpoint, wherein an
alarm output or relay cannot change state.
18 Thermalert GP Series Operator's Manual
www.calcert.com
15
10 20
5 25
0 30
Thermalert GP
C
F
button until the
