2.4.1

Display/Key Pad

Before turning on the power, make sure all wiring connections are secure.
Table 5 shows the factory-set default values.
Note that all controls can be adjusted while the power is on without damag-
ing sensor or electronics.
Table 5: Factory-set Default Values
DEFAULT
PARAMETERS SETTING RANGE
VALUES
Emissivity 0.95 0.10 - 1.09
in 0.01 increments
Sensing Head/Device H001 H001 - H006
Number
Display Resolution 0
Setpoints (SP1, SP2) off According to sensing
head/device type
Peak Hold 0 0 - 998 seconds
999 = infinite hold
Valley Hold 0 0 - 998 seconds
999 = infinite hold
Averaging 0 0 - 60 seconds
Ambient Temperature 0 -18 to 1200°C
Compensation (t-amb) (0 to 2200°F)
Offset 0 -50 to 50°C
(-99 to 99°F)
10 Thermalert GP Series Operator's Manual
www.calcert.com
15
10 20
5 25
0 30
REMARKS
For 0 - 5V and 4 - 20 mA &
thermocouple input,
is not functional
See Section 2.4.2
0 - 4
See Sections 2.4.2 and 2.4.4
Infinite reset by hardware
Infinite reset by hardware
