Bill Of Materials; Table 7-1. Tpsm8282Xevm-080 Bill Of Materials - Texas Instruments TPSM82821EVM-080 User Manual

www.ti.com

7.2 Bill of Materials

Section 7.2 lists the BOM for this EVM.
Count
Designator
-001 -002 -003
1 1 1 C1
1 1 1 C2
1 1 1 C3
1 1 1 C4
1 1 1 R1
2 2 2 R2, R3, R4
1 0 0 U1
0 1 0 U1
0 0 1 U1
SLVUBR5C – AUGUST 2019 – REVISED APRIL 2021
Submit Document Feedback

Table 7-1. TPSM8282xEVM-080 Bill of Materials

Value Description
CAP, CERM, 4.7 µF, 6.3 V, ±10%,
4.7 µF
X7R, 0603
CAP, CERM, 22 µF, 6.3V, ±20%,
22 µF
X6S, 0603
CAP, CERM, 120 pF, 50 V, +/-
120 pF
5%, C0G/NP0, 0603
CAP, CERM, 47 µF, 10 V, +/-
47 µF
20%, X7R, 1210
RES, 200 k, 1%, 0.1 W, 0603
200 k
RES, 100 k, 1%, 0.1 W, 0603
100 k
1-A Step-Down Module with 1%
Output Accuracy in 2-mm × 2.5-
mm uSip
2-A Step-Down Module with 1%
Output Accuracy in 2-mm × 2.5-
mm uSip
3-A Step-Down Module with 1%
Output Accuracy in 2-mm × 2.5-
mm uSip
Copyright © 2021 Texas Instruments Incorporated
Size Part Number
0603 JMK107BB7475MA-T
0603 JMK107BC6226MA-T
0603 06035A121JAT2A
1210 LMK325B7476MM-PR
0603 RC0603FR-07200KL
0603 RC0603FR-07100KL
2×2.5 TPSM82821SILR
mm
2×2.5 TPSM82822SILR
mm
2×2.5 TPSM82823SILR
mm
TPSM82821EVM-080, TPSM82822EVM-080 and TPSM82823EVM-080
Schematic and Bill of Materials
Manufacturer
Taiyo Yuden
Taiyo Yuden
AVX
Taiyo Yuden
Yageo
Yageo
Texas Instruments
Texas Instruments
Texas Instruments
7
Evaluation Module
