Model
Maximum Cordwood BTU's
Emissions (grams/hr) EPA Certified
Efficiency (EPA HHV)*
Efficiency (EPA LHV)
Flue Size
US Biomass Tax Rebate Eligible
Maximum Log Size
Firebox Size
NOTE: Available in metallic black or timberline brown enamel finish.
*US Biomass Tax Rebate eligibility is based on the HHV value being greater than
or equal to 75%.
30"
[762 mm]
Hampton
™
Hi2450-2
75,000 BTU's
1.6 grams/hr
70.3%
76%
6" (152mm)
No
18" (457mm)
2.3 cu.ft.
DIMENSIONS WITH REGULAR FACEPLATE
1
23
"
4
591mm
6" (152 mm)
1
31
"
2
800mm
1
42
"
2
1079mm
1
40
"
8
1019mm
Hi2450-2 Wood Insert
1
11
"
4
286mm
3
6
"
8
161mm
Hi2450-2 Hampton
Wood Insert |
™
1
Advertisement
Related Manuals for Regency Fireplace Products Hampton Hi2450-2
Summary of Contents for Regency Fireplace Products Hampton Hi2450-2
- Page 1 Hampton Hi2450-2 Wood Insert ™ Model Hi2450-2 Maximum Cordwood BTU’s 75,000 BTU’s Emissions (grams/hr) EPA Certified 1.6 grams/hr Efficiency (EPA HHV)* 70.3% Efficiency (EPA LHV) Flue Size 6" (152mm) US Biomass Tax Rebate Eligible Maximum Log Size 18” (457mm) Firebox Size 2.3 cu.ft.
- Page 2 DIMENSIONS WITH OVERSIZE FACEPLATE " 591mm 6" (152 mm) " 800mm " " 1318mm 257mm " " 1229mm 186mm | Hi2450-2 Hampton Wood Insert ™...
- Page 3 CLEARANCES MASONRY FIREPLACE CLEARANCES The minimum required clearances to combustible materials when installed into a masonry fireplace are listed below. Unit Adjacent Mantle ** Side Minimum Minimum Minimum To Top of From Side Faceplate Width Side Wall (to Top of Facing Facing Hearth...
- Page 4 INSTALLATION INTO A MA- CHIMNEY SPECIFICATIONS DRAFT SONRY FIREPLACE Before installing, check and clean your chimney Draft is the force which moves air from the system thoroughly. If in doubt about its condition, Regency Inserts are constructed with the highest appliance up through the chimney.
