Summary of Contents for Regency Fireplace Products Hampton Hi2450-2
Page 1
Hampton™ Hi2450-2 Wood Fireplace Insert Owners & Installation Manual www.regency-fire.com French Manual: https://bit.ly/3t7JcJu Manuel en Français : https://bit. ly/3t7JcJu MODEL: Hi2450-2 Tested & listed by: Installer: Please complete the details on the back cover and leave this manual with the homeowner. Homeowner: Please keep these instructions for future reference.
Page 2
Thank you for purchasing a REGENCY FIREPLACE PRODUCT. The pride of workmanship that goes into each of our products will give you years of trouble-free enjoyment. Should you have any questions about your product that are not covered in this manual, please contact the REGENCY DEALER in your area. “This wood heater has a manufacturer set minimum low burn rate that must not be altered.
table of contents Operation Safety label Operating Instructions ..........27 Draft Control ............27 Safety Label for Hi2450-2 ..........4 First Fire ..............27 Fan Operation ............28 Dimensions Ash Disposal ............28 Safety Guidelines and Warnings........28 Dimensions with Regular Faceplate ......5 Dimensions with Oversize Faceplate ......6 Maintenance Installation Maintenance ............29...
safety decal Safety Label for Hi2450-2 This is a copy of the label that accompanies your Regency Insert. We have printed a copy of the contents here for your review. NOTE: Regency units are constantly being improved. Check the label on the unit and if there is a difference, the label on the unit is the correct one.
dimensions Dimensions with Regular Faceplate " 591mm 6" (152 mm) " 800mm " " 1079mm 286mm 30" [762 mm] " " 1019mm 161mm ALL PICTURES / DIAGRAMS SHOWN THROUGHOUT THIS MANUAL ARE FOR ILLUSTRATION PURPOSES ONLY. ACTUAL PRODUCT MAY VARY DUE TO PRODUCT ENHANCEMENTS. Regency Hi2450-2...
installation Masonry Fireplace Clearances The minimum required clearances to combustible materials when installed into a masonry fireplace are listed below. Unit Adjacent Mantle ** Side Minimum Minimum Minimum To Top of From Side of Faceplate Width Side Wall (to Top of Facing Facing Hearth...
installation How to Determine if Alternate Floor Protection Materials are Acceptable All floor protection must be noncombustible (i.e. metals, brick, stone, mineral fiber boards, concrete board etc.). The noncombustible floor protection specified includes some form of thermal designation such as R-value (thermal resistance) or k-factor (thermal conductivity). Thermal Resistance: R Value The R value is a measure of a material’s resistance to heat transfer.
installation Installation into a Masonry Chimney Specifications Draft Fireplace Before installing, check and clean your chimney Draft is the force which moves air from the system thoroughly. If in doubt about its condition, appliance up through the chimney. The amount Regency Inserts are constructed with the highest seek professional advice.
installation STOP! PLEASE READ CAREFULLY. WARNING DO NOT LIFT OR PUSH THE UNIT FROM THE CAST COMPONENTS ARE VERY FRAGILE. ASHLIP, LEFT SIDE CAST or RIGHT SIDE CAST. USE EXTREME CARE WHEN HANDLING. THE CASTING WILL CHIP OR BREAK. Installing Your Insert Your insert is very heavy and will require two or three people to move it into position.
installation Stainless Steel Smoke Deflector Installation The stainless smoke deflector is located in the upper front area of the firebox. The deflector is held in place with 2 bolts Prior to the first fire, ensure deflector is seated properly and secured with 2 hand tightened bolts. Smoke deflector installed with 2 bolts.
installation CAST FACEPLATE Standard Cast Faceplate Installation INSTALLATION HI300 Secure the Left and Right Side Faceplate to the fi rebox by align- FACEPLATE CONTENTS LIST ing the Mounting Holes with the Side Mounting Brackets taking Description care to align vertically while each side rests on the hearth. Secure using 1 bolt per bracket.
Page 13
CAST FACEPLATE INSTALLATION installation HI300 Slowly slide the Mantel Top forward until it stops. Retainer Top Faceplate Slide Mantel Mounting Plates Mount the Top Faceplate by carefully sliding the Mounting Plates on the Left and Right Side Faceplate thru the Retainers in the Top Faceplate.
Page 14
CAST FACEPLATE INSTALLATION installation HI300 RECOMMENDED MEASUREMENTS Location of Insulation: FOR SETTING SIDE CASTS Place 1 piece of Insulation behind the Mantel Top. Stop! Read Carefully. Cut the second piece of Insulation in half, then install behind both the Left and Right Sides as shown. Enamel &...
installation HI300 Oversize Cast Faceplate Installation OVERSIZE CAST FACEPLATE INSTALLATION Stop! Read Carefully. Enamel & Cast components are very fragile. Use extreme care when handling. 2) Secure the Left and Right Side Faceplate to the fi rebox by aligning FACEPLATE CONTENTS LIST the Mounting Holes with the Side Mounting Brackets taking care to align vertically while each side rests on the hearth.
Page 16
HI300 installation 5) Slowly slide the Mantel Top forward until it stops. 8) Carefully slide the Mantel Top back into position. Slide Mantel Top Slide Mantel Top back. 6) Place supplied gasket to bottom edge of top faceplate - continue gasket up each side at a 45°...
Page 17
HI300 installation SIDE CAST ADJUSTMENTS RECOMMENDED MEASUREMENTS FOR SETTING SIDE CASTS If unable to align side faceplate to unit and top Stop! Read Carefully. faceplate further adjustments need to be made, complete one Enamel & Cast components are very fragile. side at a time.
HI300 installation CAST GRILL HI300 Cast Grill Installation (300-981 Cast Black) / (300-985 Enamel Brown) GLASS REMOVAL TO INSTALL OPTIONAL DOOR CAST GRILL 1. To remove the glass, loosen the two 7/16" bottom retainer bolts but do not remove. 2. Remove the sides and top retainer and bolts highlighted in the diagram and carefully remove glass, it will fall towards you at the top.
installation Fan Installation Installer: Please record unit serial number here before installing blower. Serial No.______________________________ Your fan should only be installed once the unit is in place in order to IMPORTANT prevent any damage to the fan. Ensure that the Left and Right Side Fan Facia do not 1.
installation POWER OUTLET CONVERSION Power Outlet Conversion HI300 1) Remove the Phillips screw, located on the top of the 5) Raising the fan defl ector, pull the wire harness, switch fan housing, which attaches the fan defl ector to the plate, ground wire and thermodisc assembly from main fan body.
Page 21
POWER OUTLET CONVERSION installation HI300 9) Remove the wires one at a time from the existing switch plate, and attach each wire to the new switch plate, each wire in the same position as it was on the old switch plate (see wiring diagram). Discard the old switch plate.
installation Flue Collar Removal and Installation List of Tools required: 6. Take a ½” ratchet and remove the two bolts at back inside of the firebox. - Pull rod (supplied with unit) These bolts are used to secure the flue collar. Keep these and washers - 1/2"...
Page 23
installation 11. Slide the unit back until the flue adaptor is slightly engaged. At this point it is recommended to level the unit. This will keep the adaptor from binding. 12. Insert the provided pull rod through the hole in the top center of the unit.
installation Floor Protection 3. Tilt the left baffle up on top of the side channel and it will leave enough room to position the Please check to ensure that your floor protection right baffle in the same manner as Step 1) above.
installation Brick Installation Firebrick is included to extend the life of your stove and radiate heat more evenly. Check to see that all firebricks are in their correct positions and have not become misaligned during shipping. Install all firebricks (if bricks were removed at install) per the diagram below and place in their correct positions. Do not use a grate.
installation Seasoned Wood Whether you burn wood in a fireplace, stove or insert, good quality firewood is the key to convenience, efficiency and safety. Wet wood and pieces that are not the right size and shape for your wood burner can be frustrating, burn inefficiently and deposit creosote that can fuel a dangerous chimney fire.
operating instructions Operating First Fire 7. The next step is to create a pre-burn load. This step is necessary to bring the stove temperature Instructions to an equilibrium and to create a hot coal bed When your installation is completed and inspected you are ready for your first fire.
operating instructions 10. Some cracking and popping noises may be Fan Operation 5. Do not overfire heater. If the chimney connector, experienced during the heating up process. flue baffle or the stove top begin to glow, you These noises will be minimal when your unit are over firing.
operating instructions Maintenance 5) The chimney and chimney connector should be inspected at least once every two months during the heating season to determine is a creosote It is very important to carefully maintain your buildup has occurred. fireplace stove, including burning seasoned wood and maintaining a clean stove and chimney system.
maintenance DO NOT BURN: CAUTION: DO NOT BURN GARBAGE • Treated wood OR FLAMMABLE LIQUIDS SUCH • Coal AS GASOLINE, NAPTHA OR • Garbage ENGINE OIL. SOME FUELS COULD • Cardboard GENERATE CARBON MONOXIDE • Solvents AND ARE VERY DANGEROUS. •...
maintenance Glass Door Gasket Handle Replacement Replacement If the door gasket requires replacement, 7/8" diameter material must be used. A proper high 1) Open door. 1) Remove handle by unscrewing it from the latch. temperature gasket adhesive is required. A gasket repair kit, Part # 846-570 is available from your 2) To replace the glass remove the 8 screws 2) Fit new door handle over latch and screw it in...
maintenance Latch Adjustment The door latch may require adjustment as the door gasket material compresses after a few fires. Removal of spacers will allow the latch to be moved closer to the door frame, causing a tighter seal. 1) Remove the Latch Assembly from the unit by undoing the outer 2 3) Remove necessary amount of spacers sitting on the Mounting Bracket.
maintenance Annual Maintenance Completely clean out entire unit Annually Inspect air tube and bricks Replace any damaged parts. Adjust door catch assembly If unable to obtain a tight seal on the door - replace door gasket seal. Readjust door catch after new gasket installed. Inspect condition and seal of: Glass Gasket Door Gasket...
parts list Main Assembly 41) 021-022 Firebox Floor Gasket Part # Description 21) 948-179 Wooden Handle Black 42) 181-632/P Flue Adaptor 942-681* Right Side Cast parts list 22) 300-551 Door Latch 846-686 8 mm Soft Fibre Black Gasket Not Shown in the drawing: Tape (8') (936-238) 23) 940-370/P Door Glass 846-570...
parts list Standard Cast Faceplate Part # Description 300-921 Cast Faceplate - Metallic Black 300-925 Cast Faceplate - Timberline Brown 200) * Top Faceplate 201) * Left Side Faceplate 202) * Right Side Faceplate * Not available as a replacement part. Regency Hi2450-2...
parts list Oversize Cast Faceplate Part # Description 300-971 Oversize Cast Faceplate - Metallic Black 300-975 Cast Faceplate - Timberline Brown 300) * Top Faceplate 301) * Left Side Faceplate 302) * Right Side Faceplate 303) 300-060 Mounting Plate LH 305) 300-061 Mounting Plate RH Not Shown in the Drawing...
parts list Brick Panels - Hi2450-2 Part # Description 180-960 Firebrick - Complete Set 70) 902-111 Brick Regular Full Size: 1-1/4" x 4-1/2" x 9" 75) * Brick Partial: 1-1/4 x 4-1/2" x 2" 76) * Brick Partial: 1-1/4" x 2" x 9" Regency Hi2450-2...
warranty Indoor Wood Product Warranty Limited Lifetime Warranty FPI Fireplace Products International Ltd. (for Canadian customers) and Fireplace Products U S, Inc. (for US customers) (collectively referred to herein as “FPI”) extends this Limited Lifetime Warranty to the original purchaser of this Appliance provided the product remains in the original place of installation.
Page 39
warranty The authorized selling dealer, or an alternative authorized FPI dealer if pre-approved by FPI, is responsible for all in- field diagnosis and service work related to all warranty claims. FPI is not responsible for results or costs of workmanship of unauthorized FPI dealers or agents in the negligence of their service work. At all times, FPI reserves the right to inspect reported in the field/on location complaints of products claimed to be defective before processing or authorizing any claim.
Page 40
warranty FPI has no obligation to enhance or modify any Appliance once manufactured (i.e. as products evolve, field modifications or upgrades will not be performed on existing Appliances). Any Appliance showing signs of neglect or misuse will not be covered under the terms of this warranty policy and may void this warranty, including Appliances with rusted or corroded fireboxes that have not been reported as rusted or corroded within three (3) months of installation/purchase.
warranty Warranty Registration Card Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form found on our Web Site under Customer Care within ninety (90) days of purchase.
Page 42
recycling PRODUCT LIFE CYCLE: By recycling your used appliances, you divert waste from your local landfills and help the environment. You also reduce the need for raw materials to manufacture new products. Contact your local municipality for appliance recycling services, local recycling programs, or appliance removal services to ensure your Regency appliance components, and packaging are properly recycled.
