Cascades™ Series
Owners &
Installation Manual
Freestanding Woodstove
www.regency-fire.com
MODEL: F1150-1
Tested by:
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
0219WS035S
920-844
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
02.19.25
Advertisement
Table of Contents
Related Manuals for Regency Fireplace Products Cascades F1150-1
Summary of Contents for Regency Fireplace Products Cascades F1150-1
- Page 1 Cascades™ Series Owners & Installation Manual Freestanding Woodstove www.regency-fire.com MODEL: F1150-1 Tested by: Installer: Please complete the details on the back cover and leave this manual with the homeowner. Homeowner: Please keep these instructions for future reference. 0219WS035S 920-844 FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4 02.19.25...
- Page 2 Thank you for purchasing a REGENCY FIREPLACE PRODUCT. The pride of workmanship that goes into each of our products will give you years of trouble-free enjoyment. Should you have any questions about your product that are not covered in this manual, please contact the REGENCY DEALER in your area. “This wood heater has a manufacturer set minimum low burn rate that must not be altered.
-
Page 3: Table Of Contents
table of contents OPERATION SAFETY DECAL Seasoned Firewood ..........27 Safety Label for F1150-1 ..........4 Operating Instructions ..........27 DIMENSIONS Draft Control ............27 Air Operating Handle ..........27 Unit Dimensions ............5 First Fire ..............28 Outside Air Dimensions ..........5 Fan Operation ............29 INSTALLATION Ash Disposal ............29 Safety Precautions ...........29 Room Air - Important ..........6 Ash Drawer Operating Guidelines ......29... -
Page 4: Safety Decal
safety decal This is a copy of the label that accompanies each NOTE: Regency units are constantly being Regency Freestanding Woodstove (F1150-1). We improved. Check the label on the unit and if there is have printed a copy of the contents here for your a difference, the label on the unit is the correct one. -
Page 5: Dimensions
dimensions Unit Dimensions 6" (152 mm) 6" (152 mm) Unit with legs Unit with stacker 20" 508mm 17 3/8" [441mm] 24" 6 1/2" 610mm 6" (152 mm) [165mm] 6" (152 mm) 6" [152mm] Unit with pedestal " 540mm Outside Air Dimensions 4-9/16"... -
Page 6: Installation
installation 11. For residential installations 6" (152 mm) (single 1. Please read this entire manual before you install 7. Mark the location of the pedestal base or legs wall OK) double wall chimney, the chimney and use your new woodstove. Failure to follow on the floor, then move the stove aside and connector must be at least 24 gauge steel. -
Page 7: Modular Installation Options
installation Modular Installation Options - WARNING: ONLY USE SPECIFIED COMPONENTS. The following items are required when assembling your Regency Stove. F1150-1 unit - the Rear Heat Deflector is supplied with the stove, but if you choose not to use it you must use the Airmate instead Modular Part See the Minimum Clearance to Combustible Materials chart in the Installation section of this manual. -
Page 8: Stove Assembly Prior To Installation
installation Stove Assembly Prior to Airmate Assembly for F1150-1 Rear Heat Deflector Installation Assembly for F1150-1 1. The airmate sits on top of the stove with the The F1150-1 unit requires the pedestal/wood The rear heat deflector is supplied with the stove slots in the sides fitting over the curved deflector stacker or heat shield and legs to be attached and must be installed unless the optional airmate... -
Page 9: Pedestal Assembly Installation
installation Pedestal Assembly Installation Bottom Heat Shield and Legs Note: Any paint touch up should be done prior to placing logo on pedestal. Installation 1. For easier assembly, tip the stove on its back 2. If not using ash drawer, then the front cover (onto a soft surface to prevent scratching) and must remain in place. -
Page 10: Room Air - Important
installation Room Air - Important For installation using room air for combustion, remove knockout from the pedestal or wood stacker, and/or from the bottom if using a heat shield. Mobile home installations require the use of outside air. On pedestal units there are two locations where outside air may be adapted to the unit. -
Page 11: Minimum Clearance To Combustible Materials
installation Minimum Clearance to Combustible Materials Please read the section below carefully as clearances depend on whether single wall or double wall pipe is installed on the stove. Measurements "From Unit" are from the side heat shields of the stove to a side wall or to a corner, and from the rear heat shield to a back wall. Clearances may only be reduced by means approved by the regulatory authority. -
Page 12: Minimum Alcove Clearance And Clearance To Combustible Materials
installation Minimum Alcove Clearance and Clearance to Combustible Materials The Regency Freestanding models have been alcove approved and must be installed with a listed double wall connector to the ceiling level. Single wall pipe (C Vent) is not approved for alcoves. Note: Minimum alcove ceiling height - 83"... -
Page 13: Floor Protection (Corner Installation)
installation Floor Protection (Corner Installation) (Ember Protection Only Required) A combustible floor must be protected by non-combustible material (like tile, concrete board, or certified to UL-1618 Type 1 (or as defined by local codes) extending beneath the heater and a minimum of 8" (203mm) from each side and minimum 16"... -
Page 14: Step-By-Step Chimney And Connector Installation
installation Step-by-Step This stove may be connected to a lined masonry 8. If you are using a horizontal connector, chimney or a listed factory built chimney suitable the chimney connector should be as high Chimney and for use with solid fuels and conforming to ULC629 as possible while still maintaining the 18"... -
Page 15: Masonry Chimney
installation Masonry Chimney Ensure that a masonry chimney meets the minimum standards of the National Fire Protection Association (NFPA) by having it inspected by a professional. Make sure there are no cracks, loose mortar or other signs of deterioration and blockage. Have the chimney cleaned before the stove is installed and operated. -
Page 16: Combustible Wall Chimney Connector Pass-Throughs
installation Combustible Wall Chimney Connector Pass-throughs Minimum chimney clearance to brick Method A: 12" (304.8 mm) Clearance to Combustible Wall Member: and combustibles 2 in. (50.8mm) Using a minimum thickness 3.5" (89 mm) brick and a 5/8" (15.9 mm) minimum wall thickness clay liner, construct a wall pass-through. The Minimum clearance clay liner must conform to ASTM C315 (Standard Specification for 12 in. -
Page 17: Mobile Home Installation (Usa Only)
installation Mobile Home Installation (USA Only) In addition to standard installation instructions the For USA Installations: see Outside Air Kit following requirements are mandatory for installation - Part # 846-502. in a mobile home. 1. The stove must be permanently bolted to the floor of the Mobile Home using the floor screws provided. -
Page 18: Minimum Recommended Flue Heights
installation TABLE 1 Draft is the force which MINIMUM RECOMMENDED FLUE HEIGHTS IN FEET moves air from the appliance (Measured from the top of the unit) up through the chimney. # OF ELBOWS The amount of draft in ELEVATION (FT) your chimney depends on the length of the chimney, ABOVE SEA LEVEL... -
Page 19: Optional Outside Air Kit
installation Optional Outside Air Kit The Outside Air Kit is an option for Freestanding Stoves. Outside air for combustion can be brought in either through the bottom of the pedestal or through the rear plate of the pedestal. If using the wood stacker, outside air may be installed from the rear only. When using the bottom heat shield & legs may only be installed from the bottom. -
Page 20: Brick Installation
installation Brick Installation Firebrick is included to extend the life of your stove and radiate heat more evenly. Check to see that all firebricks are in their correct positions and have not become misaligned during shipping. Install all firebricks (if bricks were removed at install) per the diagram below and place in their correct positions. Do not use a grate. -
Page 21: Baffle Installation
installation Baffle Installation tooltip Note: unit in images may not be identical to the F1150-1 — they depict the 5. Install the front air tube removed in step 2. process. Note: If air tube is locked into place correctly there should be slight movement when moving the air tube back and forth. -
Page 22: Removing Wooden Handle
installation Removing Wooden Glass Installation Handle Your Regency stove is supplied with 5 mm Neoceram ceramic glass that will withstand the highest heat that your unit will produce. In the event that you break your glass by impact, purchase your replacement from an authorized 1. -
Page 23: Wood Door & Handle Assembly (Arched Door)
installation WOOD STOVES & INSERTS Wood Door & Handle Assembly (Arched Door) WOOD DOOR & HANDLE ASSEMBLY Place the door onto the hinges and then place the door handle through the opening on the door, as shown in In preparation of installing the door handle, the nuts, Diagram 2. -
Page 24: Square Door Installation (Part #850-161)
F1150-1/I1150-1 installation Square Door Installation (Part #850-161) SQUARE DOOR INSTALLATION - PART #850-161 LATCH ADJUSTMENT Note: Unit may not be exactly as shown but depicts the process. Each door handle may require 4 washers between the cam and door spacer. When assembling the stove with pedestal, stacker or legs - install the tool (2 washers are included as spares if required) holder for the door handle storage. -
Page 25: Fan Installation
installation F1500 Fan Installation Fan assembly for use only with the room heater marked to indicate such use. FAN INSTALLATION FAN OPERATION (120V FAN) The fan is controlled by a rheostat which allows control of the heat 1. Remove the two screws from the top of the fan housing. output. -
Page 26: Stainless Steel Smoke Deflector Installation
installation Stainless Steel Smoke Deflector Installation The stainless smoke deflector is located in the upper front area of the firebox. The deflector is held in place with 2 bolts. Prior to the first fire, ensure deflector is seated properly and secured with 2 hand tightened bolts which are accessible from behind the smoke deflector. Smoke deflector Smoke deflector is installed through the door opening in location shown in Diagram... -
Page 27: Seasoned Firewood
operating instructions Seasoned Firewood Operating Air Operating Instructions Handle The F1150-1 is supplied with an air operating handle. Whether you burn wood in a fireplace, stove or insert, With your unit now correctly installed and safety The handle is used to adjust the air control for the good quality firewood is the key to convenience, ef- inspected by your local authority, you are now ficiency and safety. -
Page 28: First Fire
operating instructions First Fire 6. Once this has burned down, open the door, and 12. Green or wet wood is not recommended for rake the coals to create a uniform charcoal bed. your unit. If you must add wet or green fuel, Load 5 pieces of 17”... -
Page 29: Fan Operation
operating instructions Safety Guidelines Fan Operation Ash Drawer Operating Guidelines and Warnings Automatic 1. Only clean ashes out of the stove when the To operate the fan - turn on the rheostat. unit has cooled down. Remove the plug by CAUTION: Do not use chemicals for lifting on the handle using the tool provided. -
Page 30: Maintenance
maintenance WARNING: Do not operate without CAUTION: DO NOT BURN GARBAGE either the Ash Plug properly seated OR FLAMMABLE LIQUIDS SUCH or the Ash Dump Plates screwed in AS GASOLINE, NAPTHA, OR place, excessive temperatures will ENGINE OIL. SOME FUELS COULD result. -
Page 31: Creosote
maintenance Maintenance Creosote Door Gasket It is very important to carefully maintain your When wood is burned slowly, it produces tar and If the door gasket requires replacement 7/8" diameter fireplace stove, including burning seasoned wood other organic vapours combine with moisture to material must be used. -
Page 32: Secondary Air Tube Removal/Installation
maintenance 3. Grasp secondary air tube firmly with vise grips, using a hammer tap vise Secondary Air Tube Removal/Installation grips to the left until air tube is released from the air channel on the right- hand side. Remove. 1. Allow the stove to burn out and cool down, until cool to touch. 4. -
Page 33: Vertical Stainless Deflector Replacement
maintenance Vertical Stainless Deflector Replacement 7/16" Nuts 7/16" Bolts Slide right + down to remove. Reverse to replace Remove 2 front air tubes 1. Remove 2 front secondary air tubes / baffles (see manual for details). 2. Loosen the two 7/16'' bolts + nuts to remove / replace vertical baffle. 3. -
Page 34: Annual Maintenance
maintenance Annual Maintenance Completely clean out entire unit Annually Inspect air tube and bricks Replace any damaged parts. Adjust door catch assembly If unable to obtain a tight seal on the door - replace door gasket seal. Readjust door catch after new gasket installed. Inspect condition and seal of: Glass Gasket Door Gasket... -
Page 35: Parts List
parts list Main Assembly Part # Description 075-070 Left Side Heat Shield 075-071 Right Side Heat Shield 075-040 Side Baffle Cover (Each) 173-031 Primary Air Deflector 173-023 Draft Control Rod 815-557 Rear Air Deflector 075-955 Baffle Complete Set (Center + Sides) 033-953 3/4 OD x 19-1/4 Airtube 033-954... - Page 36 parts list Main Assembly | F1150-1 Regency Freestanding Woodstove...
-
Page 37: Bottom Shield And Legs
parts list Bottom Shield and Legs Part # Description 075-941 Bottom heat Shield 850-126 Black Cast legs (Set Of 4) 850-128 Nickel Cast legs (Set Of 4) 075-914 Ashdrawer Bottom Heat Shield 942-110 Ashplug 820-249 Ashplug Tool 075-326 Blanking Plate 905-008 5/16"... -
Page 38: Wood Stacker
parts list F1150-1 Wood Stacker Part # Description 075-946 Wood StackerComplete 075-312 Backing Plate 948-055 Levelling Legs 173-960 F1150-1 Complete Brick Kit Fire bricks Size 8-3/8" x 4-3/8" 9" x 4-1/4" 9" x 4-1/2" 9" x 2-3/8" 3-1/2" x 4-1/2" (AD) 7-3/4"... - Page 39 notes F1150-1 Regency Freestanding Woodstove |...
-
Page 40: Warranty
warranty Indoor Wood Product Warranty Limited Lifetime Warranty FPI Fireplace Products International Ltd. (for Canadian customers) and Fireplace Products U S, Inc. (for US customers) (collectively referred to herein as “FPI”) extends this Limited Lifetime Warranty to the original purchaser of this Appliance provided the product remains in the original place of installation. - Page 41 warranty The authorized selling dealer, or an alternative authorized FPI dealer if pre-approved by FPI, is responsible for all in- field diagnosis and service work related to all warranty claims. FPI is not responsible for results or costs of workmanship of unauthorized FPI dealers or agents in the negligence of their service work. At all times, FPI reserves the right to inspect reported in the field/on location complaints of products claimed to be defective before processing or authorizing any claim.
- Page 42 warranty FPI has no obligation to enhance or modify any Appliance once manufactured (i.e. as products evolve, field modifications or upgrades will not be performed on existing Appliances). Any Appliance showing signs of neglect or misuse will not be covered under the terms of this warranty policy and may void this warranty, including Appliances with rusted or corroded fireboxes that have not been reported as rusted or corroded within three (3) months of installation/purchase.
-
Page 43: Warranty Registration Card
warranty Warranty Registration Card Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form found on our Web Site under Customer Care within ninety (90) days of purchase. -
Page 44: Recycling
recycling PRODUCT LIFE CYCLE: By recycling your used appliances, you divert waste from your local landfills and help the environment. You also reduce the need for raw materials to manufacture new products. Contact your local municipality for appliance recycling services, local recycling programs, or appliance removal services to ensure your Regency appliance components, and packaging are properly recycled. - Page 45 notes F1150-1 Regency Freestanding Woodstove |...
