- Page 1 Phantom BA06 - BA04 Installation manual READ AND FOLLOW ALL INSTRUCTIONS...
- Page 2 The installation of this spa is simple and immediate, however we advise you to read this manual carefully before installing it.
-
Page 3: Table Of Contents
Contents Safety instructions __________________________________________4 EXPLANATION OF PICTOGRAMS _________________________________________________________________ 7 Preliminary operations ______________________________________8 PREPARATIONS AND CHOICE OF POSITION _________________________________________ 8 CHECKING SPA INTEGRITY _________________________________________________________ 8 Transport and position ______________________________________9 MOVING _________________________________________________________________________ 9 POSITIONING _____________________________________________________________________ 10 TEMPORARY POSITIONING _________________________________________________________________ 10 POSITIONING IN THE PLANNED LOCATION __________________________________________________ 10 Installation _________________________________________________11 DESCRIPTION OF MAIN COMPONENTS _____________________________________________ 11 QUALIFICATIONS OF THE INSTALLER _______________________________________________ 11... -
Page 4: Safety Instructions
Safety instructions Phantom IMPORTANT SAFETY 7. DANGER – Risk of Electric Shock. Do not permit any electric appliance, such as a light, INSTRUCTIONS telephone, radio, or television, within 5 feet (1.5 m) of a spa. 8. WARNING – To reduce the risk of injury: READ AND FOLLOW ALL INSTRUCTIONS. - Page 5 Safety instructions Phantom WARNING: CHILDREN SHOULD NOT USE AV E R T I S S E M E N T : P O U R É V I T E R L’ÉVANOUISSEMENT ET LA NOYADE SPAS OR HOT TUBS WITHOUT ADULT SU- ÉVENTUELLE, NE PRENDRE NI DROGUE NI PERVISION AVERTISSEMENT : NE PAS LAISSER LES...
-
Page 6: Read And Follow All Instructions
Safety instructions Phantom D’APPAREIL ÉLECTRIQUE (LUMINAIRE, symbol* is located inside the supply terminal TÉLÉPHONE, RADIO, TÉLÉVISEUR, ETC) À box or compartment. To reduce the risk of MOINS DE 1.5 M DE CETTE CUVE DE RE- electric shock, this terminal must be con- LAXATION nected to the grounding means provided in the electric supply service panel with a con-... -
Page 7: Explanation Of Pictograms
Unauthorised actions, tampering or Treesse invites you to protect the environ- modifications that do not follow the ment by disposing of the material in special information provided in this manual can cause separate collection bins. -
Page 8: Preliminary Operations
Preliminary operations Phantom PREPARATIONS AND CHOICE More information OF POSITION OUTDOOR INSTALLATION The pre-installation sheet supplied at the time of purchase provides all the information neces- Preparations: in cold areas, to avoid possible damage sary for a correct preparation of the installation due to freezing, it is recommended to provide valves environments. -
Page 9: Transport And Position
Transport and position Phantom MOVING To move the spa to the place of installation a suitable lifting device (e.g., pallet jack) is required. As an alterna- tive, provide for the availability of eight people. If the installation is indoor, before moving the spa make sure that it can easily pass through the doors and hall- ways to reach the desired place of installation. -
Page 10: Positioning
Transport and position Phantom POSITIONING TEMPORARY POSITIONING The installation of the spa should be done im- mediately upon receipt. In any case, once unpacked, if it is necessary to temporarily place it on a surface awaiting the installation, it will be necessary to place level concrete slabs having a minimum thickness of 1.9 in under the entire bottom of the spa. -
Page 11: Installation
Installation Phantom DESCRIPTION OF MAIN COMPONENTS Control Panel Compensation tank P h a n t o m B A 0 6 / Paper filter BA04 Electric pump 1 Electric pump 2 (optional in BA04) Electronic control units Blower (optional in BA06 not available in BA04) Heater Ozone... -
Page 12: Connections Required
Installation Phantom CONNECTIONS REQUIRED To be used, the spa requires only two connections: Room for the electrical con- plumbing connections nections (incoming and outgoing water) electrical connection (power supply) electrical and plumbing connection to an exchanger (optional - if present) - see following page. - Page 13 Installation Phantom EXAMPLE OF INDOOR RECESSED INSTALLATION. Room for the electrical con- nections Drain Technical inspection port...
-
Page 14: Plumbing Connections
Installation Phantom PLUMBING CONNECTIONS More information WATER HARDNESS All water connection operations must be per- formed after making sure that the spa's water Water hardness (TH) is determined by the total content supply valve is CLOSED. of calcium and magnesium present in the water, coming The connection must be made by an experi- from their soluble salts. - Page 15 Installation Phantom EXAMPLE OF PRE-INSTALLATION PLUMBING FOR A SPA Connection to the spa using the 1/2 inch female hose provided. Connect the drain of the floor spa. The plumber If the spa is installed outdoors provide an adequate thermal insula- is responsible for the choice and type of materials tion of the pipes.
-
Page 16: Electrical Connections
Installation Phantom ELECTRICAL CONNECTIONS The Treesse spas are built in compliance with UL laws (XXXXXXXX) and are tested during production to ensure the safety of the installer and user. The connection must be made by an experienced, qualified electrician. READ AND FOLLOW ALL INSTRUCTIONS b) A green coloured terminal or a terminal marked G, GR, Ground, Grounding, or the sym- bol* is located inside the supply terminal box or compartment. - Page 17 Installation Phantom WARNING – This product is provided with a ground-fault circuit-interrupter (give location). The GFCI must be tested before each use. With the product operating, open the service door. When the product stops operating, this merely indicates that the door is equipped with an electrical interlock.
-
Page 18: Safety Zone
Installation Phantom SAFETY ZONE Local regulations prohibit any electrical installation (plug sockets, switches, lamps, etc.) in the area surround- ing the spa for a distance of at least 23.6 in and a height of 90.5 in. TESTING AFTER INSTALLATION √ MAKE SURE THAT... -
Page 19: First Run Ba06
First run Phantom BA06 Room for the electrical FILLING THE SPA connections Perform a preliminary cleaning of the spa using a bit of water and a mild detergent. Do not use cloths or cleaners that are abrasive, aggressive or that contain solvents because they could irreparably damage the surface of the spa. -
Page 20: Alarms Ba06
Phantom BA06 Alarms If any alarms appear during initial startup, read the instructions provided in the following table. If the solution is not possible, immediately contact the Manufacturer to request technical support. In the meantime, do not try to repair or use the spa but rather disconnect it from the electricity and water supplies. - Page 21 Phantom BA06 Alarms MESSAGES CONNECTED DESCRIPTION OF SIGNALS AND POSSIBLE SOLUTIONS TO WATER HEATING Problem description: there may not be enough water flow through the heater to carry the heat away from the heating element. The heater will restart in about 1 minute. See the "Water Reduced flow in flow problems"...
- Page 22 Phantom BA06 Alarms MESSAGES CONNECTED DESCRIPTION OF SIGNALS AND POSSIBLE SOLUTIONS TO THE SEN- SORS Problem description: the sensors connected to the temperature measurement could be out of calibration by 3 °F. Call technical service if the message does not disappear within a few minutes.
- Page 23 Phantom BA06 Alarms SYSTEM MES- DESCRIPTION OF SIGNALS AND POSSIBLE SOLUTIONS SAGES Problem description: at power-up, the system has failed the program checksum test. This indicates a problem with the firmware (operation program) and requires a service call. Memory fault -...
-
Page 24: First Run Ba04
Phantom BA04 First run FILLING THE SPA Room for the electrical connections Perform a preliminary cleaning of the spa using a bit of water and a mild detergent. Do not use cloths or cleaners that are abrasive, aggressive or that contain solvents because they could irreparably damage the surface of the spa. -
Page 25: Exiting Priming Mode
Phantom BA04 First run to prime. pumps, cycle power to the spa. Follow these steps to prime a two-speed pump: IMPORTANT: A pump should not be allowed to run without priming for more than 2 minutes. Under NO circumstances should a pump be allowed to run wi- Press the button (JETS 1, JETS 2, etc.) for that pump once thout priming beyond the end of the 4 minute Priming to turn it On at low speed. -
Page 26: Panel Messages
Phantom BA04 Alarms PANEL MESSAGES HEATER-RELATED MESSAGES This chapter lists all of the Panel Messages and explains each one. Some Panel Messages have corresponding Message Codes. If so, the Message Code appears below The water flow is low the Panel Message. Message Code: M016 * MESSAGE CODES There may not be enough water flow through the heater... -
Page 27: Sensor-Related Messages
Phantom BA04 Alarms The heater is too hot** SENSOR-RELATED MESSAGES Message Code: M030 * Sensors are out of sync One of the water temp sensors has detected 118°F (about 48°C) in the heater and the spa is shut down. You must Message Code: M015 * reset the message* when water is below 108°F (about The temperature sensors may be out of sync by 3°F. -
Page 28: Reminder Messages
Phantom BA04 Alarms The GFCI test failed REMINDER MESSAGES (System Could Not Test the GFCI) Reminder messages can be reset from the panel. Press Message Code: M036 * the Clear Icon to reset the Reminder message. (North America Only) May indicate an unsafe installation. Contact your dealer or service organization. -
Page 29: Miscellaneous Messages
Phantom BA04 Alarms Clean the filter MISCELLANEOUS MESSAGES Set the Time-of-Day May appear on a regular schedule, i.e. every 30 days. Clean the filter media as instructed by the manufacturer. When a control system that displays this message is powered On, its time-of-day is initialized to 12:00 PM. Test the GFCI (or RCD) Setting the proper time-of-day is important for deter- mining filtration times and other background features. -
Page 30: Decorative Panels
Decorative panels Phantom Mount the wood or laminate resin panels as shown in the figures below. -
Page 31: Covering
Under these conditions or when not used, advise the owner to use a fixed or mobile cover to protect the spa (we recommend the optional Treesse covers). In addition to preserving the surfaces, the cover will keep the water hot and protected against falling leaves and other outdoor debris. - Page 32 www.gruppotreesse.it GRUPPO TRE S s.p.a. 01036 Nepi (VT) - Italy S.S. Cassia km. 36.400 Settevene industrial area tel. (+39) 0761 527242 fax (+39) 0761 527223 info@gruppotres.it...
