PRODUCT DETAILS:
Part Number:
ECU Number:
Tail Harness Length Required:
TBM/Lug Part Number:
Wiring Part Number:
FITTING DETAILS:
Towbar Installation Time:
Wiring Installation Time:
Total Installation Time:
Bumper Cut Required:
49-75 Pacific Drive Keysborough, VIC 3173
Phone: 1800 812 017
Email: info@haymanreese.com.au
Rev:
B
03340RW
Maximum Towing Braked:
WLE70019
Maximum Towing Unbraked:
1800 mm
Maximum Static Ball Load:
21201
WLL90018
145 Mins.
Hayman Reese SmartCODE Solution Required:
45 Mins.
RPA Disable/Other:
190 Mins.
Note:
Yes
Page
INSTALLATION INSTRUCTIONS
PART NUMBER
Electric Brake = Brake Prep Connector
1
TOWBAR
03340RW
BMW X2 F39 CL4
2000
kg
750
kg
75
kg
NO
YES
Issue Date:
31-08-2021
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Hayman Reese 03340RW
Summary of Contents for Hayman Reese 03340RW
- Page 1 Maximum Static Ball Load: TBM/Lug Part Number: 21201 Wiring Part Number: WLL90018 FITTING DETAILS: Towbar Installation Time: 145 Mins. Hayman Reese SmartCODE Solution Required: Wiring Installation Time: 45 Mins. RPA Disable/Other: Total Installation Time: 190 Mins. Note: Electric Brake = Brake Prep Connector...
-
Page 2: Installation Instructions
WARNING: Do not, drill, cut, weld or otherwise modify the towbar. FOR TOWING PURPOSES ONLY - This towbar is designed and tested by Hayman Reese to adhere to ADR 62/02 which provides only for the expected load demands of towing. - Page 3 BMW X2 F39 CL4 TOWBAR ASSEMBLY DIAGRAM ITEM DESCRIPTION BMW X2 WELDED ASSEMBLY TRAILER BALL MOUNT TOWBALL 50mm HAYMAN REESE LOGO STICKER "D" SHACKLE 10mm SMART PIN GOLD HITCH BOX COLLAR COVER COMPLIANCE LABEL LOAD RATING LABEL CAN MODULE WARNING LABEL NUT NYLOC HEX HD M4X0.7P G8...
- Page 4 TOWBAR INSTALLATION INSTRUCTIONS PART NUMBER 03340RW BMW X2 F39 CL4 WIRING ASSEMBLY DIAGRAM 49-75 Pacific Drive Keysborough, VIC 3173 Phone: 1800 812 017 Email: info@haymanreese.com.au Rev: Page Issue Date: 31-08-2021...
- Page 5 TOWBAR INSTALLATION INSTRUCTIONS PART NUMBER 03340RW BMW X2 F39 CL4 ITEM DESCRIPTION Main Harness Trailer module -> WLE70019 CAN 3-pin housing Brake controller 2-pin housing Brake controller plug pin - small Bake controller plug pin - large Cable tie 300mm...
- Page 6 TOWBAR INSTALLATION INSTRUCTIONS PART NUMBER 03340RW BMW X2 F39 CL4 1. Open the tailgate. Remove taillight covers Remove 2x nuts. Repeat for the other side. 2. Remove 6x screws from under bumper. 3. Remove 3 x plastic rivets from wheel arch.
- Page 7 TOWBAR INSTALLATION INSTRUCTIONS PART NUMBER 03340RW BMW X2 F39 CL4 4. Peel back wheel arch Remove 2x screws on the side and 1x screw underneath. Repeat for the other side. 5. Slowly remove bumper, disconnect 4x sensor plugs, 1x number plate lights plug and 1x camera plug.
- Page 8 TOWBAR INSTALLATION INSTRUCTIONS PART NUMBER 03340RW BMW X2 F39 CL4 7. Loosely fit towbar to vehicle with 4x nuts from impact beam. Adjust the towbar to the center of the vehicle and then torque the nuts Torque specification. M12 – 120 Nm...
- Page 9 TOWBAR INSTALLATION INSTRUCTIONS PART NUMBER 03340RW BMW X2 F39 CL4 10. Remove the boot sill trim by firstly removing the 3x scrivet. 11. Remove the 2x anchor points. 12. Remove the boot light out and disconnect. 13. Locate the RHS rear cargo net and dislodge the lower frame from the plastic storage tub.
- Page 10 TOWBAR INSTALLATION INSTRUCTIONS PART NUMBER 03340RW BMW X2 F39 CL4 Remove the rear RHS passenger sill trim. Dislodge the C-pillar trim and move to the side. 17. Dislodge the rear RHS boot trim by pulling outward from the bottom towards the centre of the vehicle...
- Page 11 TOWBAR INSTALLATION INSTRUCTIONS PART NUMBER 03340RW BMW X2 F39 CL4 19. Drill out the hole to ∅30mm. 20. From outside route the tail (1800mm) along the 30 mm towbar and feed the tail blue connector through the previously drilled hole.
- Page 12 TOWBAR INSTALLATION INSTRUCTIONS PART NUMBER 03340RW BMW X2 F39 CL4 23. Locate the vehicle the 10 pin CAN connector with a jeweller’s screwdriver release the secondary lock tab, press down on the terminal locking tang to release the terminal and remove the following...
- Page 13 TOWBAR INSTALLATION INSTRUCTIONS PART NUMBER 03340RW BMW X2 F39 CL4 29. Secure harness using cables ties (not supplied). 30. Refit all removed parts in the reverse order of removal. 31. Test the trailer function using a trailer board. 32. Place fitting instructions in glovebox.
- Page 14 TOWBAR INSTALLATION INSTRUCTIONS PART NUMBER 03340RW BMW X2 F39 CL4 BRAKE Trailer Brake Preparation CONTROLLER PREPARED 49-75 Pacific Drive Keysborough, VIC 3173 Phone: 1800 812 017 Email: info@haymanreese.com.au Rev: Page Issue Date: 31-08-2021...
-
Page 15: Customer Information
TOWBAR MAINTENANCE AND CARE: 1. Hayman Reese recommend that the towbar LUG or TBM (tow ball Mount) Pull Pin and R-clip are removed and stored when not in use. Removal of LUG or TBM (tow ball mount) is advisable when not in use to assist with any of the following. - Page 16 VEHICLE’S GLOVEBOX AFTER INSTALLATION HAYMAN REESE SMART PIN Your Hayman Reese towbar is equipped with Smart Pin technology to help reduce towbar tongue rattle in most driving conditions. Please ensure below instructions are understood and routine maintenance is carried out to ensure best towing experience.
